Honda CR-V Door Lock Actuator Guide for 2002-2006 Models
Having trouble with your door locks? Here is what you need to know about fixing the common door lock actuator problem in your CR-V.
- A single door failing to lock or unlock with the power switch is the primary symptom of a bad actuator.
- This is a common DIY repair that requires basic tools and about 1-2 hours per door.
- Aftermarket actuators are a cost-effective and popular choice for this repair on a 2002-2006 CR-V.
- Ensure the separate, but critical, safety recall for the driver's power window switch has been completed on your vehicle.
Is Your CR-V's Door Lock Acting Up?
If one of your 2002-2006 Honda CR-V's power door locks has stopped working, a failed door lock actuator is the most likely cause. This is a common issue as vehicles age. The symptoms are usually easy to spot and point directly to a problem inside the door.
Common Symptoms of a Bad Door Lock Actuator
- Door Fails to Lock/Unlock: The most obvious sign is a door that doesn't respond to the key fob or the master lock switch. 🎬 Watch: Step-by-step driver door lock actuator replacement guide. You'll have to use the manual lock tab on the door itself.
- Strange Noises: A buzzing, grinding, or clicking sound from inside the door when you try to use the power locks indicates the actuator's motor is struggling or its internal gears are stripped.
- Erratic Behavior: Sometimes, a failing actuator will cause the lock to cycle repeatedly, locking and unlocking on its own. This can happen while driving as the auto-lock feature engages.
Important Safety Recall Information
All 2002-2006 Honda CR-V models were part of a significant safety recall for the driver's side master power window switch, not the door lock actuator itself. Moisture could enter the switch, creating a fire risk. Honda issued an updated recall (NHTSA Campaign ID: 20V768) to replace the switch entirely, as the previous fix was insufficient. While this is a separate part, it's located in the same area and is a critical safety issue. Verify with a Honda dealer or on the NHTSA website that this recall has been performed on your vehicle.
Choosing the Right Aftermarket Actuator
When replacing a failed actuator, you don't have to buy an expensive part from the dealer. Aftermarket parts offer a cost-effective solution. For an older vehicle like the 2002-2006 CR-V, many owners choose aftermarket brands for the significant savings. The brands available in our inventory provide reliable, budget-friendly options.
- Replacement Brand: These are value-oriented parts that meet original specifications and provide a low-cost fix to get your locks working again.
- Skyward: Another affordable option, offering a balance of price and performance for daily driving needs.
- Standard Ignition (SMP): A well-known aftermarket manufacturer, often considered a step up in quality from basic replacement parts, offering robust construction and performance.
For this specific repair, the general consensus among owners is that a quality aftermarket part provides the best value. Since the original part has failed, an aftermarket replacement is a very common and accepted repair.
Pro Tip: Door lock actuators are specific to each door (Front Left, Front Right, Rear Left, Rear Right). They are not interchangeable. Double-check that you are ordering the correct actuator 🎬 See how to replace the front door lock actuators. for the door you need to repair.
Cost of Replacing a Door Lock Actuator on a 2002-2006 Honda CR-V
| Part Type | Estimated Cost |
|---|---|
| New Aftermarket Actuator | $13.55 - $68.41 |
| Shop Labor | $100 - $150 |
| Total Estimated Cost (DIY) | $13.55 - $68.41 |
| Total Estimated Cost (Shop) | $115 - $220 |
Frequently Asked Questions (FAQ)
Is replacing a door lock actuator a DIY job?
Yes, this is a very feasible DIY project for someone with basic tools and patience. The process involves removing the door panel, peeling back the plastic vapor barrier, and unbolting the latch assembly to access the actuator. Several video guides online show the step-by-step process for the 2nd generation CR-V. The most challenging part can be working in the tight space inside the door.
Do I need any special tools?
No special tools are required. You will need a Phillips head screwdriver, a 10mm socket, and a plastic trim removal tool to avoid scratching the door panel. A #3 Phillips screwdriver is recommended for the screws holding the latch assembly, as they can be very tight and a smaller screwdriver might strip them.
If one actuator fails, should I replace all of them?
Not necessarily. While it's true that the actuators are all the same age, they don't always fail at the same time. It is common to replace them one at a time 🎬 Watch this walkthrough for replacing the rear door lock actuator. as they fail. However, if you prefer to do the work only once and have the budget, replacing them in pairs (both front or both rear) can be a good preventative measure.
Does the new actuator need to be programmed?
No. On the 2002-2006 Honda CR-V, the door lock actuator is a simple electrical component and does not require any programming. It is a plug-and-play part.
Helpful Videos
Technical Specifications
OEM Part Numbers: 72155-S6A-J11 72115-S6A-J11 72655-S6A-J11 72615-S5A-003
Each actuator is specific to its door location: Front Driver, Front Passenger, Rear Driver, and Rear Passenger. The part is a direct-fit, plug-and-play electrical motor that requires no programming.
We Have This Part in Stock
The information in this article is provided for general reference and educational purposes only. Vehicle specifications, procedures, and part compatibility can vary by production date, trim level, and region. Always consult your vehicle's factory service manual and verify part numbers before purchasing or performing repairs. Safety-critical components such as airbags, seat belts, and braking systems should be installed by a qualified professional.
