Dodge Challenger Windshield Washer Pump Replacement Guide (2008-2020)
If your Challenger's washer fluid isn't spraying, this guide will help you diagnose the problem and choose the right replacement pump.
- Before replacing the pump, listen for the motor's hum; if you hear it, the problem is likely a clogged or broken hose.
- The pump is accessed by removing the front passenger-side wheel and fender liner.
- Replacing the pump is a simple DIY task that can be completed in about an hour with basic tools.
- High-quality aftermarket brands like Trico are a cost-effective and reliable alternative to the more expensive Mopar OEM part.
Is Your Windshield Washer Pump Failing?
When your washer system stops working, the pump is a common suspect, but it's not the only possibility. Before you buy a new part, a quick diagnosis can save you time and money. 🎬 Watch this video to diagnose pump, line, and nozzle issues. The most common failure is the pump motor itself simply wearing out. You may also experience issues with clogged or broken lines, which are common on the Challenger.
Symptoms of a Bad Washer Pump
- No Spray, But Wipers Move: You pull the lever, the wipers swipe across a dry windshield, and no fluid comes out.
- No Sound from the Pump: Turn the car to the 'accessory' position (engine off) and activate the washer. You should hear a distinct humming sound from the front passenger side of the car. If it's silent, the pump motor has likely failed or isn't receiving power.
- Intermittent Spray: The pump might work sometimes and fail at other times, which is often a sign that the motor is about to fail completely.
Symptoms of Other System Problems
- Pump Hums, But No Spray: If you can hear the pump working, the problem is likely a blockage or a leak. Check the hoses under the hood for cracks, kinks, or disconnections, especially at the plastic T-connectors. 🎬 See how to fix common sprayer and hose connector problems.
- Puddle Under Car: If you see washer fluid on the ground after trying to use the sprayers, you have a leak in the reservoir, the pump's grommet, or the fluid lines.
Choosing the Right Aftermarket Pump
For a part like the windshield washer pump, you have a choice between the original factory part and an aftermarket replacement. Both are viable options for the Dodge Challenger.
Brand Tiers
- OEM (Mopar): Mopar is the original equipment manufacturer for your Challenger. Choosing a Mopar pump guarantees a perfect fit and original performance. However, this option is typically the most expensive.
- Premium Aftermarket (Trico): Brands like Trico specialize in wiper and washer systems. They design their pumps to be direct-fit, easy-to-install replacements that meet or exceed original specifications. For a simple component like a washer pump, a quality aftermarket brand offers excellent value without sacrificing reliability.
Windshield Washer Pump Replacement Cost
The cost to replace your Challenger's washer pump depends on whether you do it yourself or take it to a shop. The part itself is affordable, but professional installation adds to the total cost.
| Part Type | Estimated Cost |
|---|---|
| New Aftermarket Pump | $38.34 - $183.83 |
| New OEM (Mopar) Pump | $12 - $150 |
| Shop Labor | $122 - $179 |
Known Issues for 2005-2020 Dodge Challenger
While there are no specific recalls for the windshield washer pump, the Challenger has had two notable recalls related to the windshield system that owners should be aware of:
- Windshield Bonding Recall (NHTSA 21V516): On certain 2020-2021 models, the windshield may not have been properly bonded to the vehicle, which could allow it to detach in a crash.
- Wiper Arm Recall (NHTSA 20V-208): Some vehicles were recalled because the wiper arm head joint was not properly formed, which could cause the wipers to fail.
Frequently Asked Questions (FAQ)
How hard is it to replace a Challenger washer pump?
It's a straightforward DIY job for someone with basic tools. The main steps involve safely jacking up the car, removing the front passenger wheel and fender liner to get access, and then swapping the pump. The difficulty is about a 2 out of 5.
🎬 Follow this step-by-step guide to replace your washer pump.Where is the windshield washer pump located on a Dodge Challenger?
The pump is press-fit into the bottom of the windshield washer fluid reservoir. You can access it by removing the front passenger-side wheel and the plastic fender liner.
Can I replace just the pump or do I need the whole reservoir?
You can replace just the pump. It is sold as a separate component that pushes into a rubber grommet on the reservoir. It's a good idea to replace this grommet at the same time to prevent leaks.
My pump is running but no fluid comes out. What should I do?
If you hear the pump motor, the issue is likely a blockage or leak. Before replacing the pump, inspect the fluid lines that run from the reservoir to the hood nozzles. Look for disconnected hoses, cracks, or kinks, which are common failure points.
Helpful Videos
Technical Specifications
OEM Part Numbers: 5139113AA 68125519AA 68310928AA
Voltage: 12V, Terminal Type: 2-Pin Blade, Outlet Quantity: Dual
We Have This Part in Stock
The information in this article is provided for general reference and educational purposes only. Vehicle specifications, procedures, and part compatibility can vary by production date, trim level, and region. Always consult your vehicle's factory service manual and verify part numbers before purchasing or performing repairs. Safety-critical components such as airbags, seat belts, and braking systems should be installed by a qualified professional.
