Chevrolet Silverado 1500 Door Remote Mirror Switch Guide (2008-2013)
If your Silverado's power mirrors are acting up or have stopped working, the driver's door switch is a likely culprit.
- Failure is common and symptoms include no adjustment, partial adjustment, or failed power-folding.
- Before replacing, check fuses #4, #9, and #14 in the interior fuse box.
- Replacement is an easy DIY job, requiring only a trim tool and a 10mm socket, taking less than 30 minutes.
- A quality aftermarket brand like Standard Ignition provides a reliable, cost-effective alternative to OEM parts.
Is Your Silverado's Mirror Switch Failing?
When a mirror switch starts to go bad, the symptoms are usually straightforward. You might find that the mirrors only adjust in some directions but not others, or they might not respond at all. Sometimes, only one mirror will stop working while the other is fine. Before you assume the switch is bad, it's a good idea to check the fuses first. In the 2008-2013 Silverado, fuses #4, #9, and #14 in the interior fuse box (located on the driver's side of the dashboard) are related to the door modules and mirrors. However, if the fuses are good, the switch itself is the next most common point of failure.
🎬 Watch this video to diagnose why your mirrors stopped working.Check for Deeper Issues First
In some cases, a non-working mirror isn't the switch's fault. These trucks can sometimes develop broken wires inside the rubber boot between the driver's door and the truck's body. Constant opening and closing of the door can cause wires to fatigue and break over time. If other components on your driver's door, like power locks or windows, are also acting up, a broken wire in the door jamb is a strong possibility. Checking for this requires pulling back the boot and inspecting the wiring harness for any breaks.
🎬 See how to troubleshoot broken wires in the door jamb.Choosing a New Aftermarket Mirror Switch
When replacing the mirror switch, you have the choice between an original equipment manufacturer (OEM) part from a dealer or an aftermarket part. For a vehicle of this age, a quality aftermarket switch offers a good balance of price and performance.
- Standard Ignition (SMP): Standard is a well-regarded aftermarket brand that has been around for a long time. They are known for producing parts that meet or exceed original specifications. In many cases, SMP parts are made in the same factories as the original parts and are simply rebranded. For a simple electronic component like a mirror switch, Standard Ignition is a reliable choice that should restore original function without the high cost of an OEM part.
Cost of Replacing a Door Remote Mirror Switch (2008-2013 Silverado 1500)
| Part Type | Price Range |
|---|---|
| New OEM | $75 - $150 |
| New Aftermarket (Standard Ignition) | $43 - $230 |
| Shop Labor | $50 - $100 |
Pro Tip: Replacing the mirror switch is a very simple DIY job that most owners can complete in under 30 minutes with basic tools. Doing it yourself can save you the entire cost of shop labor.
Frequently Asked Questions
Is it difficult to replace the mirror switch myself?
No, it is a very easy job. You will need a trim tool and a 10mm socket. The process involves prying off a trim piece on the door pull handle, removing two 10mm bolts, and then lifting the entire window switch panel up. From there, you disconnect the wiring harnesses, release the clips holding the mirror switch in place, and swap in the new one. 🎬 Follow this step-by-step guide to replace your mirror switch. The whole process typically takes less than half an hour.
Do I need to disconnect the battery to replace the switch?
It is always a best practice to disconnect the negative battery terminal before working on any vehicle electronics to prevent accidental shorts. While the risk is low for this specific job, it's a simple step that ensures safety.
My mirrors fold but won't adjust. Is it still the switch?
Yes, it's very likely the switch. The switch has separate internal contacts for the adjustment joystick and the folding function. It's common for one function to fail while the other continues to work. If both mirrors have the same adjustment problem (e.g., neither will move left), the switch is almost certainly the cause.
Are there any recalls for the mirror switch on my Silverado?
No, there are no specific recalls for the mirror switch itself on the 2008-2013 Chevrolet Silverado 1500. There were recalls on other GM vehicles around that time for the master window switch module due to fire risk from water intrusion, but these did not specifically cover the Silverado of this generation.
Helpful Videos
Technical Specifications
OEM Part Numbers: 25881799 22881999 15889475
The switch is located in the driver's side master window switch panel. It is a self-contained unit that clips into the main panel. Different switches exist for trucks with and without the power-folding mirror option (RPO code DL3), so ordering the correct one is crucial.
