2010-2015 Ford Mustang Ambient Air Temperature Sensor Replacement Guide
Is the outside temperature on your Mustang's dash wrong or is your A/C acting up? Your ambient air temp sensor has likely failed.
- A bad sensor primarily causes an incorrect outside temperature display and problems with the automatic A/C.
- This is an easy and inexpensive DIY replacement; the hardest part is accessing the sensor behind the front grille.
- Always check for a disconnected plug or damaged wires before buying a new sensor.
- A failed sensor can trigger a Check Engine Light, most commonly with code P0073.
Symptoms of a Failing Sensor
When the ambient air temperature sensor on a 2010-2015 Mustang starts to go bad, the signs are usually straightforward. The most common issue is an incorrect temperature reading on the dashboard display. For example, it might show 50°F on a hot 80°F day. This incorrect reading directly affects the automatic climate control system, which may fail to cool the cabin properly because it thinks it's already cool outside. In some cases, this can prevent the A/C compressor from engaging at all.
Check Engine Light
A failed sensor can trigger a Check Engine Light. Common trouble codes include P0071, P0072, and P0073, which point to a problem in the sensor's circuit. Code P0073 is frequently reported by owners when the sensor is unplugged or has failed.
🎬 Watch: How to test and fix a P0073 trouble code.Choosing the Right Aftermarket Sensor
For a simple sensor like this, you don't always need to pay dealership prices. Several reputable aftermarket brands offer quality replacements. Your choice depends on your budget and preference for OEM-level quality versus a value-oriented part.
OEM / Premium Brands:
- Motorcraft: This is Ford's official parts brand and the original equipment (OEM) on your Mustang. It guarantees a perfect fit and performance identical to the factory part. The OEM part number is often AE5Z12A647A (Motorcraft DY-1137).
- Standard Ignition (SMP): A well-regarded aftermarket manufacturer known for producing parts that meet or exceed OEM specifications. They perform extensive testing to ensure reliability.
Quality Aftermarket Brands:
- Dorman: Dorman specializes in creating direct-fit replacement parts that are often engineered to fix common failure points of the original design. They are a reliable and widely available option.
- Holstein: This brand produces a range of sensors and is presented as a quality alternative to cheaper, unbranded parts that may fail prematurely.
Budget-Friendly Brands:
- Skyward, True Tech: These brands fall into the economy category. They offer a functional replacement at a very low cost, making them a good choice for budget-conscious repairs.
Check the Connection First!
The sensor is located in a vulnerable spot behind the front grille. Before buying a new part, check to see if the sensor is simply unplugged or if the wiring is damaged, especially if you've recently had front-end work done or hit a curb. Sometimes just reconnecting the sensor solves the problem.
Cost of Replacing the Ambient Air Temperature Sensor
| Part Type | Price Range |
|---|---|
| New OEM (Motorcraft) | $40 - $75 |
| New Aftermarket | $6.47 - $63.18 |
| Shop Labor | $50 - $150 |
Frequently Asked Questions (FAQ)
Where is the ambient air temperature sensor located on a 2010-2015 Mustang?
The sensor is typically mounted behind the front grille, often in the center or on the passenger side. 🎬 See this video to help locate the sensor on your Ford. It's a small, black plastic probe with a two-wire connector. You may need to remove the radiator cover or the lower splash shield to access it.
Can I replace this sensor myself?
Yes, this is a very DIY-friendly repair. The sensor itself just unplugs and unclips. The only challenge is accessing it, which might require removing a few plastic clips or screws holding the splash shield or grille assembly. No special tools are required beyond basic hand tools. The difficulty is low, and it should take less than an hour.
🎬 Watch: A step-by-step guide to testing and replacing the sensor.Are there any recalls for this part?
No, there are no specific recalls or widespread Technical Service Bulletins (TSBs) from Ford for the ambient air temperature sensor on the 2010-2015 Mustang. While other recalls exist for this generation, they do not pertain to this sensor.
Will the A/C work at all with a bad sensor?
It might, but not correctly. If the sensor is sending a signal that it's colder outside than it actually is, the automatic climate control won't command the A/C compressor to turn on. You may be able to get cold air by using the manual A/C settings, but the 'Auto' function will be unreliable.
Helpful Videos
Technical Specifications
OEM Part Numbers: AE5Z12A647A DY-1137
Two-terminal plastic sensor, typically mounted behind the front grille.
