A Guide to Replacing Brake Pads on the 2017-2021 Volvo V90
Address common brake issues like shudder and premature wear by choosing the right aftermarket pads for your wagon.
- Many owners replace OEM pads with aftermarket ceramic pads like Akebono to reduce brake dust and noise.
- Brake shudder is a known issue; replacing both pads and rotors is the best way to solve it.
- The rear electronic parking brake must be put in 'Service Mode' for replacement, which may require a special tool.
- Brands like Brembo, Bosch, and Akebono are reputable aftermarket choices for the V90.
Signs Your V90 Brake Pads Are Worn
Your Volvo is good at telling you when it needs attention. For brake pads, you should look out for a few key symptoms. Ignoring them can lead to more expensive repairs down the line.
- Squealing or Grinding Noises: A high-pitched squeal when you brake is often the first sign. It comes from a small metal tab called a wear indicator. If you hear a deeper grinding sound, it means the pads are completely worn away, and you are likely damaging the brake rotors.
- Brake Shudder or Vibration: Some V90 owners report a vibration or shudder through the steering wheel or brake pedal when braking. This is often caused by an uneven buildup of pad material on the rotors, a problem sometimes linked to the original equipment (OEM) pads.
- Longer Stopping Distances: If you notice your car taking longer to stop than it used to, your brake pads may be too thin to create enough friction.
- Brake Warning Light: Your dashboard may display a message like "Parking brake service required" if there's an issue with the system, which can be related to pad wear or other faults.
Known Issues and Technical Service Bulletins (TSBs)
Some Volvo owners have experienced premature wear and brake shudder with the original factory brake pads. There is a Technical Service Bulletin (TSB #TJ36202.2.0) for "Vibration/shudder while braking" on the 2017 V90, and another (TSB #TJ33506-2-0-2018) for "Squealing noise from rear brakes at low speed". These bulletins provide dealers with procedures to fix common problems. While no recalls exist for the brake pads themselves on the 2015-2021 V90, switching to a quality aftermarket pad is a common solution chosen by owners to resolve these issues.
Choosing the Right Aftermarket Brake Pads
Many V90 owners have found that aftermarket brake pads can offer better performance and value than the original Volvo pads. The main choice is between ceramic and semi-metallic compounds.
- Ceramic Pads: These are a popular choice for V90 owners. They are known for being quiet, producing very little brake dust (which keeps your wheels cleaner), and offering a good lifespan. They provide a smooth, consistent pedal feel suitable for a luxury vehicle.
- Semi-Metallic Pads: These pads offer excellent performance across a wide range of temperatures. They might have a stronger initial "bite" but tend to produce more dust than ceramic pads. They are a durable option, and some drivers prefer their performance feel.
Recommended Aftermarket Brands
Based on owner feedback and brand reputation, brake pads for your V90 can be grouped into tiers:
- Premium Ceramic (OEM Quality or Better): Brands like Akebono are highly recommended by Volvo owners for their clean, quiet operation and quality construction. They are often considered an upgrade over the stock pads, especially for reducing brake dust.
- Premium Performance: Brembo and Powerstop (Z23 series) are excellent choices if you want improved stopping power. Brembo is a well-known supplier for high-performance vehicles, while Powerstop pads are noted for reducing dust compared to OEM pads.
- Reputable OEM Suppliers: Brands like Bosch, ATE, and Pagid often manufacture parts for Volvo and other European cars. They provide a reliable, cost-effective replacement that meets or exceeds original specifications.
- Standard Aftermarket: Brands like Centric (Posi-Quiet), Raybestos, and Wagner offer a good balance of quality and affordability for daily driving.
A Note on Rear Brake Pad Replacement
The Volvo V90 has an electronic parking brake (EPB). To replace the rear brake pads, the EPB must be put into "Service Mode." This retracts the electronic caliper piston. While this traditionally required a special diagnostic tool, some owners have found a sequence of pedal and button presses that can activate service mode without a tool. 🎬 See how to enter rear brake service mode without a scanner. However, using a compatible OBD scan tool is the most reliable method. Failure to retract the EPB correctly can damage the brake calipers.
Brake Pad Replacement Costs for Volvo V90
Costs can vary based on the brand you choose and local labor rates. Below is an estimated breakdown.
| Part/Service | Estimated Cost |
|---|---|
| New Aftermarket Brake Pad Set (Front or Rear) | $34 - $250 |
| New OEM Brake Pad Set (Front or Rear) | $70 - $150+ |
| Shop Labor (Per Axle) | $150 - $250 |
Frequently Asked Questions
Do I need to replace my rotors at the same time as my pads?
It is highly recommended. Many of the shuddering issues on the V90 are related to the rotors. Installing new pads on old or warped rotors will reduce braking performance and cause the new pads to wear out unevenly and quickly. For best results, replace pads and rotors together.
What is the break-in procedure for new brake pads?
Most manufacturers recommend a process of several moderate stops from around 40 mph to bed in the new pads. This transfers an even layer of friction material to the rotor for smooth, quiet braking. Avoid heavy, sudden braking for the first couple hundred miles. Always follow the specific instructions included with your new pads.
Why are my new brakes making noise?
A little noise is normal during the break-in period. If squealing persists, it could be due to improper lubrication of contact points on the caliper or a lack of shims. High-performance pads can also be slightly noisier than standard ceramic pads.
Can I do this job myself?
Replacing the front pads is a straightforward job for a DIY mechanic 🎬 Watch this step-by-step guide for replacing front pads and rotors. with the right tools. The rear pads are more complex due to the electronic parking brake. If you are not comfortable putting the car in service mode, it is best to leave the rear brake job to a professional mechanic.
🎬 Watch a full walkthrough of the rear pad and rotor replacement.Helpful Videos
Technical Specifications
The Volvo V90 uses an electronic parking brake (EPB) that requires being put into service mode for rear pad replacement. Various pad materials are available, with ceramic and semi-metallic being the most common aftermarket choices.
