Ford Transit-150 Ignition Switch Guide: 2015-2023 Problems and Replacement
If your Transit-150 is having trouble starting or stalling, the ignition switch could be the simple fix you need.
- A failing ignition switch can cause a dangerous stalling condition while driving; do not operate a vehicle with these symptoms.
- Symptoms often include a no-crank/no-start condition or intermittent electrical problems.
- Replacement is a simple DIY job that does not require key reprogramming.
- The OEM Motorcraft part is often priced similarly to aftermarket options, so compare prices before buying.
Is Your Transit-150 Ignition Switch Failing?
A bad ignition switch can cause problems that seem random and confusing. These issues often start small but can get worse, potentially leaving you stranded or causing the engine to shut off while driving. Recognizing the signs early can save you from a bigger headache.
Common Failure Symptoms
- No Crank, No Start: You turn the key and absolutely nothing happens. The dashboard might light up, but the engine doesn't even try to turn over. This happens when the switch fails to send power to the starter.
- Engine Cranks But Won't Start: The engine turns over but never fires up, or it starts for a second and then immediately dies. Sometimes, wiggling the key or pushing it in while turning can make it work, which is a strong sign the switch's internal contacts are worn. 🎬 See how a worn switch causes a crank-no-start condition.
- Stalling While Driving: This is the most dangerous symptom. The switch can lose connection internally, cutting power to the engine and causing it to stall. This also results in a loss of power steering and power brakes, increasing the risk of an accident.
- Flickering Lights and Accessories: You might notice the dashboard lights flicker or the radio and climate control cut out intermittently. This indicates a loose or failing connection inside the switch.
- Key Hard to Turn: If the key feels like it's binding or getting stuck, the problem could be the ignition switch mechanism or the separate lock cylinder.
No Recalls, But Known Issues
As of early 2026, there are no official recalls from Ford or the NHTSA specifically for ignition switch failure on the 2015-2023 Transit-150. However, the symptoms are widely discussed by owners in forums and repair videos, indicating it is a known point of failure.
Choosing the Right Aftermarket Ignition Switch
When replacing your ignition switch, you have several options. The good news is that even the Ford (Motorcraft) OEM part is often priced competitively with aftermarket brands. It's worth checking the price of an OEM part before deciding.
Brand Quality Tiers
- Premium Aftermarket (Standard Ignition): Standard Motor Products (SMP) is a well-regarded brand that often manufactures parts for automakers or designs them to OEM standards. They are generally considered a reliable, high-quality choice for electrical components.
- Mid-Grade / Value (Dorman): Dorman is one of the largest aftermarket parts suppliers and is known for providing affordable and widely available parts. Their quality is generally solid for a replacement part, and they sometimes engineer fixes for common OEM flaws.
- Economy Brands (Replacement, True Tech, VNE, Rostra): These brands offer a budget-friendly option. While they can provide significant savings, their long-term durability and manufacturing consistency may not be as proven as the premium or mid-grade brands. They are a viable choice if the price is your main concern.
Pro Tip: Check the Lock Cylinder First
The ignition switch and the ignition lock cylinder are two different parts. The cylinder is the mechanical tumbler your key goes into. The switch is the electrical part behind it. If your main problem is the key feeling stuck or not turning, the issue might be the cylinder, not the switch. However, if you have electrical symptoms like stalling or a no-crank start, the switch is the more likely culprit.
| Part Type | Estimated Part Cost |
|---|---|
| New OEM (Motorcraft) | $60 - $90 |
| New Aftermarket | $37 - $87 |
| Shop Labor | $105 - $160 |
*Prices are estimates and can vary based on supplier, location, and vehicle specifics. Labor costs are based on a typical 0.5-1 hour job.
Frequently Asked Questions (FAQ)
Do I need to reprogram my keys if I replace the ignition switch?
No. The ignition switch is just an electrical switch. The security information for your key is stored in other vehicle modules, not in the switch itself. You can replace the switch without needing to reprogram your keys.
My van makes a clicking noise but won't start. Is it the ignition switch?
Probably not. A rapid clicking noise usually points to a weak or dead battery. A single, loud click often indicates a problem with the starter motor or solenoid. A bad ignition switch typically results in silence (no click, no crank) when you turn the key.
🎬 Watch: Diagnosing a starting fault that looks like a battery issue.Is this a difficult part to replace myself?
For most DIYers, this is a very feasible job. It typically involves removing the plastic covers around the steering column with a Torx screwdriver, unplugging the old switch, and snapping the new one into place. The entire process can often be done in under an hour.
🎬 Watch this step-by-step walkthrough for replacing the ignition switch.What's the difference between an ignition switch and an ignition lock cylinder?
The ignition lock cylinder is the mechanical part you put your key into. The ignition switch is the electronic part connected to the back of it that actually sends power to the vehicle's systems. They are separate, replaceable parts.
Helpful Videos
Technical Specifications
OEM Part Numbers: SW-6958
This is the electrical switch component only, located on the steering column opposite the key slot. It is separate from the mechanical ignition lock cylinder.
