Ford Ranger Ignition Switch Replacement Guide for 2018-2023 Models
If your Ranger won't start or the electronics are acting up, the ignition switch could be the cause.
- Ignition switch failure is not a common, widespread problem on the 2018-2023 Ranger.
- Symptoms like 'no-start' often have simpler causes, such as a weak vehicle battery or key fob battery.
- Standard Ignition is a reputable aftermarket brand, but the OEM Ford part is also affordable and proven reliable.
- Replacement is straightforward for a DIYer and can be done in about an hour with basic tools.
Is Your Ranger's Ignition Switch Failing?
The ignition switch on the 2018-2023 Ford Ranger is a generally reliable component. Widespread failures are not commonly reported in owner forums or technical service bulletins. However, like any electrical part, it can wear out. Symptoms of a bad ignition switch often mimic other problems, like a weak battery or a faulty starter, so it's important to diagnose the issue correctly. If you're experiencing intermittent starting problems or strange electrical behavior, the ignition switch is a potential culprit.
Symptoms of a Bad Ignition Switch
🎬 Watch: 8 common symptoms of a failing ignition switch- No Crank, No Start: You turn the key or press the button, and nothing happens. The starter motor is silent, even though the battery is good.
- Starts and Stalls: The engine fires up but immediately shuts down once you release the key from the 'start' position. This indicates the switch isn't maintaining power to the ignition system in the 'on' position.
- Intermittent Electrical Problems: Your radio, power windows, or dashboard lights may flicker or stop working randomly. Wiggling the key in the ignition might cause these systems to cut in and out, which strongly points to a worn switch.
- Key is Hard to Turn: While this can also be the lock cylinder itself, binding or stiffness can be a sign of a failing internal switch mechanism.
Check the Simple Things First
🎬 See this troubleshooting guide for a Ranger that won't startMany starting issues on the 2019-2023 Ranger are traced back to a weak main vehicle battery or a dead battery in the key fob for push-button start models. Always test your battery and check its connections before assuming the ignition switch has failed.
Choosing the Right Aftermarket Part
When replacing your Ranger's ignition switch, you have the choice between an OEM part from Ford and an aftermarket part. For this generation of Ranger, the OEM switch is not a common failure point, suggesting it is a quality component. However, if you need a replacement, aftermarket options can provide good value.
- OEM (Original Equipment Manufacturer): This is the same part that was installed at the factory. It guarantees a perfect fit and function. Surprisingly, for the Ranger, some OEM ignition components can be found for a lower price than aftermarket versions.
- Standard Ignition (Aftermarket): Standard Motor Products (SMP) is a well-known aftermarket brand that produces replacement parts. Their products are generally considered a reliable, cost-effective alternative to OEM. They are built to meet or exceed original specifications and are a common choice in repair shops.
Given that the OEM part is not known for widespread issues and is competitively priced, it's a very safe choice. However, a switch from a reputable brand like Standard Ignition is a perfectly acceptable replacement if it is more readily available or if you prefer to use aftermarket parts.
Replacement Cost
The cost to replace the ignition switch depends on the part you choose and whether you do the work yourself. The job is within reach for a DIYer with basic tools.
| Item | Estimated Cost |
|---|---|
| New OEM Part | $28 - $46 |
| New Aftermarket Part (Standard Ignition) | $47 - $55 |
| Used OEM Part | $65 - $70 |
| Shop Labor | $75 - $150 |
| Total (Shop Installed) | $103 - $205 |
Frequently Asked Questions
Are there any recalls for the 2018-2023 Ranger ignition switch?
No, as of early 2026, there are no specific recalls or widespread Technical Service Bulletins (TSBs) from Ford or NHTSA for ignition switch failure on the 2019-2023 North American Ford Ranger.
Can I replace the ignition switch myself?
Yes, this is a DIY-friendly job for most people with basic hand tools. The process typically involves removing the plastic shrouds around the steering column to access the switch, which is usually held in place with a couple of screws and an electrical connector. Always disconnect the battery's negative terminal before starting any electrical work.
Does this apply to push-button start models? 🎬 Watch: How to start your Ranger with a dead key fob
The symptoms can be similar, but the components are different. Push-button start models do not have a traditional ignition switch. Instead, they use a start-stop button that communicates with the vehicle's computer. No-start issues on these models are often related to the key fob battery, the vehicle battery, or the brake pedal sensor.
My truck is completely dead, even the remote doesn't work. Is it the ignition switch?
While possible, a completely dead vehicle more often points to a dead battery or a bad main battery connection. Some owners have reported that disconnecting and reconnecting the battery can resolve mysterious no-start electrical issues. Try this simple reset before replacing parts.
Helpful Videos
![Ford Ranger Not Starting? [FIXED] - Troubleshooting & Repair Guide](https://img.youtube.com/vi/89All4wZhbQ/mqdefault.jpg)
Technical Specifications
OEM Part Numbers: SW-8335 H1BZ-11572-A DS7T-15607-BB
Applies to both conventional key-start and push-button start systems, although the physical parts differ. The switch is responsible for powering the vehicle's main electrical circuits in stages (Accessory, On, Start).
