| Attribute | Value |
|---|---|
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.56, 65 |
| Conventional Or Drum In Hat Type Rotor | Conventional |
| Directional Or Non Directional Brake Surface | Non-directional |
| Discard Thickness | 0.315 |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 168, 6.614 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 112, 4.409 |
| Mounting Bolt Hole Diameter | 0.477, 12.1 |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.394 |
| Overall Height | 2.02, 51.3 |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Solid |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| 100 Aniversario | Hatchback | 2010 | L4 1.8L Turbo | FWD Automatic Dual Clutch |
| Ambiente | Hatchback | 2012 - 2013 | L4 1.4L Turbo | FWD Manual |
| Ambiente | Hatchback | 2012 - 2013 | L4 1.8L Turbo | FWD Manual |
| Ambiente | Hatchback | 2010 - 2013 | L4 1.4L Turbo | FWD Manual |
| Ambiente | Hatchback | 2010 - 2013 | L4 1.8L Turbo | FWD Manual |
| Attraction | Hatchback | 2012 | L4 1.8L Turbo | FWD Manual |
| Attraction | Hatchback | 2012 | L4 2.0L Turbo | FWD Manual |
| Attraction | Hatchback | 2011 | L4 1.4L Turbo | FWD Manual |
| Attraction | Hatchback | 2010 - 2013 | L4 1.8L Turbo | FWD Manual |
| Attraction | Hatchback | 2010 - 2011 | L4 2.0L | FWD Manual |
| Attraction | Hatchback | 2010 - 2013 | L4 2.0L Turbo | FWD Manual |
| Attraction Plus | Hatchback | 2010 - 2011 | L4 2.0L | FWD Manual |
| Attraction Plus | Hatchback | 2010 - 2011 | L4 2.0L Turbo | FWD Manual |
| Base | Hatchback | 2010 - 2013 | L4 2.0L Turbo | FWD Manual & Automatic Dual Clutch |
| Cabrio | Convertible | 2010, 2012 - 2013 | L4 1.8L Turbo | FWD Manual |
| Cabrio | Convertible | 2010 | L4 2.0L | FWD Manual |
| Cabrio | Convertible | 2010, 2012 - 2013 | L4 2.0L Turbo | FWD Manual |
| S Line | Hatchback | 2013 | L4 1.8L Turbo | FWD Manual |
| S Line | Hatchback | 2010 - 2011 | L4 2.0L Turbo | FWD Manual |
| Sportback | Hatchback | 2013 | L4 2.0L DIESEL Turbo | FWD Automatic Dual Clutch |
| Sportback 100 Aniversario | Hatchback | 2010 | L4 1.8L Turbo | FWD Automatic Dual Clutch |
| TDI | Hatchback | 2010 - 2013 | L4 2.0L DIESEL Turbo | FWD Automatic Dual Clutch |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| Advance Auto Parts | YH321961 |
| Advance Auto Parts | YH321961C |
| Advance Auto Parts | YH321961P |
| Autopartsource | 416430 |
| Autoxtra | AX901124 |
| AutoZone | 45607 |
| AutoZone | 45607DG |
| Bosch | 14011492 |
| Bosch | 53011410 |
| BrakeBest | 980874 |
| BrakeBest | 980874FZN |
| BrakeBest | 980874R |
| BrakeBest | 980874RGS |
| Centric Parts | 120.33135 |
| Centric Parts | 121.33135 |
| Centric Parts | 12133135 |
| Centric Parts | 125.33131 |
| Centric Parts | 125.33135 |
| Centric Parts | 125.33135CRY |
| Centric Parts | 126.33135CSL |
| Centric Parts | 126.33135CSR |
| Centric Parts | 126.33135SL |
| Centric Parts | 126.33135SR |
| Centric Parts | 127.33135CL |
| Centric Parts | 127.33135CR |
| Centric Parts | 127.33135L |
| Centric Parts | 127.33135R |
| Centric Parts | 128.33135L |
| Centric Parts | 128.33135R |
| Centric Parts | 320.33135 |
| Dura Corp | BR34470 |
| Dura Corp | BR901124 |
| DuraGo | BR90112402 |
| Dynamic Friction Company | 604-74033 |
| NAPA BRAKES | SDK6087 |
| NAPA BRAKES | TSR9811 |
| Newtek Automotive USA | 34470 |
| PAGID Racing | 355122612 |
| PowerStop | EBR1207EVC |
| Promax | 14-34470 |
| Qualis | 45583 |
| TRW | DF4276S |
| Ultra Brake | VW-2004 |
| Volkswagen | 5C0615601 |
| Volkswagen | 5C0615601A |
| Wagner Brake | BD180522 |
| Wagner Brake | BD180522E |
| Winhere | 661970 |
| Worldparts | WS1-234470 |
Fits Years: 2010 2011 2012 2013
Fits Models: A3
