| Attribute | Value |
|---|---|
| Active Or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Damping | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
| Air Adjustable | No |
| Air Ride Suspension | No |
| Bearing Plate Included | No |
| Bladder Heavy Duty Crimping Rings Included | No |
| Bladder Sleeve(s) Included | No |
| Bladder(s) Included | No |
| Body Color | Black |
| Body Diameter | 1.97 |
| Body Material | Steel |
| Boot Included | No |
| Coil Over Springs Included | No |
| Coil Spring Insulator(s) Included | No |
| Compressed Length | 15.83, 402.1 |
| Cylinder Color | Black |
| Cylinder Finish | Painted |
| Cylinder Material | Steel |
| Cylinder Outside Diameter | 1.97 |
| Dust Shield Included | No |
| Extended Length | 23.78, 604 |
| Gas Charged | Yes |
| Grade Type | Performance |
| Hydraulic Lockout | No |
| Includes Bump Stop | No |
| Internal Construction Type | Single Tube |
| Internal Rebound Bumper | Yes |
| Internal Rebound Spring | No |
| Lower Mount Code | Ls47 |
| Lower Mount Type | Loop Bushing And Sleeve Mount - 9/16" Sleeve Id X 1.5/8" Sleeve Oal |
| Maximum Ride Height Lowering Distance | 0 |
| Maximum Ride Height Raising Distance | 0 |
| Mounting Hardware Included | No |
| Parts Pack(s) | None |
| Remote Reservoir | No |
| Rod Diameter | 0.5511811023622047, 14 |
| Self Leveling | No |
| Shaft Material | Chromed |
| Shock Absorber Body End Measuring Point | Center Of Loop |
| Shock Absorber Bore Size | 1.8110236220472442, 46 |
| Shock Absorber Rod End Measuring Point | Center Of Loop |
| Shock Stroke | 201.9, 7.95 |
| Spring Included | No |
| Spring Isolators Included | No |
| Spring Seat Included | No |
| Strut Mount Insulator(s) Included | No |
| Travel Length | 201.9, 7.95 |
| Upper Mount Code | Ls47 |
| Upper Mount Type | Loop Bushing And Sleeve Mount - 9/16" Sleeve Id X 1.5/8" Sleeve Oal |
| Valving Type | Progressive |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | Crew Cab Pickup | 2012 - 2013 | V8 5.3L FLEX | AWD Automatic |
| Base | Crew Cab Pickup | 2007 - 2011 | V8 5.3L FLEX | 4WD Automatic |
| Base | Crew Cab Pickup | 2007 | V8 5.3L FLEX | RWD Automatic |
| Black Diamond LS | Crew Cab Pickup | 2013 | V8 5.3L FLEX | RWD/4WD Automatic |
| Black Diamond LT | Crew Cab Pickup | 2013 | V8 5.3L FLEX | RWD/4WD Automatic |
| Black Diamond LTZ | Crew Cab Pickup | 2013 | V8 5.3L FLEX | RWD/4WD Automatic |
| LS | Crew Cab Pickup | 2007 - 2009 | V8 5.3L | RWD/4WD Automatic |
| LS | Crew Cab Pickup | 2007 - 2012 | V8 5.3L FLEX | RWD/4WD Automatic |
| LT | Crew Cab Pickup | 2007 - 2009 | V8 5.3L | RWD/4WD Automatic |
| LT | Crew Cab Pickup | 2007 - 2012 | V8 5.3L FLEX | RWD/4WD Automatic |
| LT | Crew Cab Pickup | 2007 - 2009 | V8 6.0L | RWD/4WD Automatic |
| LTZ | Crew Cab Pickup | 2007 - 2009 | V8 5.3L | RWD/4WD Automatic |
| LTZ | Crew Cab Pickup | 2007 - 2012 | V8 5.3L FLEX | RWD/4WD Automatic |
| LTZ | Crew Cab Pickup | 2007 - 2009 | V8 6.0L | RWD/4WD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| Bilstein | 24029032 |
| Bilstein | 24184922 |
| Bilstein | 24185677 |
| Bilstein | 24186834 |
| Bilstein | 24186933 |
| Bilstein | 24251761 |
| Bilstein | 24253246 |
| FOX Offroad Shocks | 98524032 |
| General Motors | 20955408 |
| General Motors | 20955409 |
| General Motors | 20955430 |
| General Motors | 22811845 |
| General Motors | 22811846 |
| General Motors | 22811847 |
| General Motors | 23183849 |
| General Motors | 23183851 |
| General Motors | 23425614 |
| General Motors | 23425615 |
| General Motors | 84082039 |
| General Motors | 84082041 |
| General Motors | 84082042 |
| General Motors | 84082043 |
| Monroe Shocks & Struts | 911506 |
Fits Years: 2007 2008 2009 2010 2011 2012 2013
