| Attribute | Value |
|---|---|
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.83, 71.9 |
| Conventional Or Drum In Hat Type Rotor | Drum-in-hat |
| Directional Or Non Directional Brake Surface | Non-directional |
| Discard Thickness | 0.63, 16 |
| Harmonize Code | 8708.30.5030 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 114.3, 4.5 |
| Mounting Bolt Hole Diameter | 0.546, 13.85 |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.709, 18 |
| Overall Height | 2.22, 56.4 |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Limited | SUV | 2008 - 2010 | V6 3.5L | AWD/FWD Automatic |
| SE | SUV | 2007 - 2010 | V6 3.5L | AWD/FWD Automatic |
| SEL | SUV | 2007 - 2010 | V6 3.5L | AWD/FWD Automatic |
| SEL Plus | SUV | 2007 | V6 3.5L | AWD/FWD Automatic |
| Sport | SUV | 2009 - 2010 | V6 3.5L | AWD/FWD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| Advance Auto Parts | YH145703 |
| Advance Auto Parts | YH145703C |
| Advance Auto Parts | YH145703P |
| Autopartsource | 492875 |
| Autoxtra | AX900300 |
| AutoZone | 42256DG |
| Bendix | PRT5703 |
| Bosch | 20010513 |
| Bosch | 20011509 |
| BrakeBest | 680546 |
| BrakeBest | 680546FZN |
| BrakeBest | 680546R |
| BrakeBest | 680546RGS |
| Brembo | 09.B541.10 |
| Casting Numbers | 326362 |
| Casting Numbers | 7T432C203A |
| Centric Parts | 120.61091 |
| Centric Parts | 120.61091CRY |
| Centric Parts | 121.61091 |
| Centric Parts | 126.61091CSL |
| Centric Parts | 126.61091CSR |
| Centric Parts | 126.61091SL |
| Centric Parts | 126.61091SR |
| Centric Parts | 127.61091L |
| Centric Parts | 127.61091R |
| Centric Parts | 128.61091CL |
| Centric Parts | 128.61091CR |
| Centric Parts | 128.61091L |
| Centric Parts | 128.61091R |
| Centric Parts | 320.61091 |
| Centric Parts | 321.61091 |
| Dura Corp | BR54156 |
| Dura Corp | BR900300 |
| Dura Corp | BR90030002 |
| DuraGo | 60355 |
| DuraGo | 900300 |
| DuraGo | BR60355 |
| Motorcraft | BRR153 |
| Motorcraft | NBRR30 |
| Motorcraft | NBRR31 |
| Newtek Automotive USA | 54156 |
| PowerStop | AR8191EVC |
| Promax | 14-54156 |
| Promax | 20-54156 |
| Qualis | 42256 |
| UAP | 2054156 |
| Ultra Brake | MA-889 |
| WABCO - Archived | PS126430 |
| Wagner Brake | BD126430 |
| Wagner Brake | BD126484 |
| Winhere | 6620790 |
Fits Years: 2007 2008 2009 2010
Fits Models: Edge
