| Attribute | Value |
|---|---|
| Amperage (A) | 8.1 |
| Attachment Method | In Tank |
| Average Current Draw | 8.5 |
| Average Flow Rating | 165 |
| Bracket Included | No |
| Connector Color | Black/white |
| Connector Gender | Female |
| Connector Shape | Rectangular |
| Electric Or Mechanical | Electrical |
| Fill Vapor Valve Included | No |
| Flow Rate (gph) | 47.5 |
| Fuel Filter Included | No |
| Fuel Level Sensor Assembly Included | Yes |
| Fuel Level Vent Valve (FLVV) Included | No |
| Fuel Pressure Regulator Included | No |
| Fuel Sending Unit Included | Yes |
| Fuel Static Pressure (psi) | Na |
| Fuel Tank Pressure Sensor Included | Yes |
| Fuel Type | Gas |
| Gasket Or Seal Included | Yes |
| Gasket Or Seal Material | Nbr |
| Grade Type | Regular |
| Housing Length | 121 |
| Housing Width | 121 |
| In Line Pump | No |
| Inlet Attachment Method | Hose |
| Inlet Diameter (In) | .31 |
| Inlet Fitting Size (In) | Na |
| Inlet Fitting Thread Size | Na |
| Inlet Fitting Type | Hose |
| Inlet Outside Diameter | 7.9 |
| Inlet Quantity | 1 |
| Inlet Thread Diameter | Na |
| Internal Or External Strainer | Internal |
| Lock Ring Included | No |
| Manufacturer | Uro |
| Maximum Flow Rate (gph) | Na |
| Maximum Flow Rating | Na |
| Maximum Pressure | Na |
| Minimum Flow Rate (gph) | Na |
| Minimum Flow Rating | Na |
| Minimum Free Flow Rate | Na |
| Minimum Pressure | Na |
| Module Included | Yes |
| Mounting Hardware Included | No |
| Negative Ground | Yes |
| OE Part/Casting Number | 19299717 |
| Outlet Diameter (In) | 0.31 |
| Outlet Fitting Size (In) | Na |
| Outlet Fitting Thread Size | Na |
| Outlet Fitting Type | Hose |
| Outlet Outside Diameter | 9.5 |
| Outlet Quantity | 1 |
| Outlet Thread Diameter | Na |
| Pump Design | Na |
| Pump Type | Electric |
| Regulator Included | No |
| Resistance Ohms Empty | 254 |
| Resistance Ohms Full | 43.4 |
| Rollover Valve Included | No |
| Strainer Included | Yes |
| Tank Seal Included | Yes |
| Terminal Gender | Male |
| Terminal Quantity | 7 |
| Terminal Type | Blade |
| Thermistor Low Fuel Indicator Included | No |
| Top Mount Diameter | 128.6 |
| Vapor Pressure Sensor Included | Yes |
| Vapor Vent Line Included | No |
| Wire Gauge Measurement | Na |
| Wire Harness Included | No |
| Wire Quantity | Na |
| Wiring Harness Length | Na |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | SUV | 2011 - 2012 | V8 6.2L FLEX | AWD Automatic |
| Base | SUV | 2008 - 2009 | V8 5.3L | RWD Automatic |
| Denali | SUV | 2009 - 2014 | V8 6.2L FLEX | AWD/RWD Automatic |
| Denali | SUV | 2008 | V8 6.2L | AWD/RWD Automatic |
| Denali Hybrid | SUV | 2010 - 2013 | V8 6.0L FULL HYBRID EV-FLEX (FHEV) | RWD/4WD Automatic |
| Hybrid | SUV | 2010 - 2013 | V8 6.0L FULL HYBRID EV-FLEX (FHEV) | RWD/4WD Automatic |
| Hybrid | SUV | 2008 - 2009 | V8 6.0L FULL HYBRID EV-GAS (FHEV) | RWD/4WD Automatic |
| SLE | SUV | 2008 - 2009 | V8 4.8L | RWD/4WD Automatic |
| SLE | SUV | 2008 - 2009 | V8 5.3L | RWD/4WD Automatic |
| SLE | SUV | 2008 - 2014 | V8 5.3L FLEX | RWD/4WD Automatic |
| SLT | SUV | 2008 - 2009 | V8 5.3L | RWD/4WD Automatic |
| SLT | SUV | 2008 - 2014 | V8 5.3L FLEX | RWD/4WD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| ACDelco | M100095 |
| Airtex | E3768M |
| Autotecnica | GM0517277 |
| Carter | P76297M |
| Delphi | FG1054 |
| General Motors | 19179868 |
| General Motors | 19179869 |
| General Motors | 19179870 |
| General Motors | 19206650 |
| General Motors | 19257104 |
| General Motors | 19259393 |
| General Motors | 19299717 |
| General Motors | 19299718 |
| GMB | 530-2490 |
| Spectra Premium | SP6107M |
| TYC | 150234 |
| TYC | 150234-A |
| VDO | FP22052S |
Fits Years: 2008 2009 2010 2011 2012 2013 2014
Fits Models: Yukon
