| Attribute | Value |
|---|---|
| 112.00 | |
| ABS Tone Ring Included | No |
| Assy/Disassy By Qualified Personnel Required! | . |
| Balancing Type | Mill Balancing |
| Bearings Included | No |
| Bolt Hole Circle Ø [in] | 4.41 |
| Bolt Hole Circle Ø [mm] | 112 |
| Bolt Hole Quantity | 6 |
| Brake Disc Thickness [mm] | 14,8, 14.8 |
| Brake Disc Type | Solid |
| California Proposition 65 Required | No |
| Center Hole Diameter | 112.0 |
| Centering Diameter [in] | 2.64 |
| Color | Silver |
| Colour | Silver |
| Construction | Full Cast |
| Directional Or Non Directional Brake Surface | Non-directional |
| Disc Finish | Coated |
| Discard Thickness | 13.00 |
| Grade Type | Standard Replacement |
| Hat Finish | Coated |
| Hole Arrangement / Number | 05/06 |
| Hole Arrangement/Number | 05/06 |
| Inner Diameter [in] | 7.24 |
| Inside Diameter | 67.0 |
| Machining | High-carbon |
| Material | Gray Cast Iron |
| Minimum Thickness [in] | 0.51 |
| Minimum Thickness [mm] | 13 |
| Mounting Bolt Hole Circle Diameter | 112.00 |
| Mounting Bolt Hole Quantity | 6 |
| Nominal Thickness | 15.00 |
| Number Of Bolts/screws | 1 |
| Outer Diameter [in] | 11.22 |
| Overall Height | 55.50 |
| Rust Resistant Coating | Yes |
| Solid Or Vented Type Rotor | Solid |
| Surface | Coated |
| Surface Type | Smooth |
| Technical Information Number | 52168pro_hc_na |
| Weight [kg] | 6,1, 6.1 |
| Wheel Bolt Bore Diameter [mm] | 14.4 |
| Wheel Bolt Bore Ø [mm] | 14.4 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | SUV | 1998 - 2003 | V6 3.2L | 4WD Automatic |
| Base | SUV | 1998 - 2002 | V6 3.2L | AWD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| Akebono | BN0502 |
| Akebono | BN0502E |
| ATE | 24011501111 |
| ATE | 415111 |
| Bendix | 520739 |
| Bendix | 562100B |
| Bendix | 562100BC |
| Blue Print | ADU174343 |
| Borg & Beck | BBD4193 |
| Bosch | 0986478469 |
| Brake Engineering | DI955820 |
| Brembo | 08793610 |
| Brembo | 08793611 |
| Brembo | 08793614 |
| Cifam | 800769C |
| Delphi | BG3398 |
| Dynamic Friction Company | 600-63123 |
| Dynamic Friction Company | 604-63123 |
| Dynamic Friction Company | 900-63123 |
| EBC Brakes | D990 |
| EBC Brakes | GD990 |
| EBC Brakes | USR990 |
| Febi-Bilstein | 21923 |
| Ferodo | DDF1037 |
| Ferodo | DDF10371 |
| Ferodo | DDF1037C |
| FREMAX BRAKE ROTORS AND DRUMS | BD4230 |
| FTE | 9072479 |
| FTE | BS5058 |
| FTE | BS5058B |
| Girling | 6041954 |
| Hella Pagid | 52168PROHCNA |
| Hella Pagid | 8DD355105852 |
| Japan Parts | DP0522 |
| Japan Parts | DP0522C |
| Jurid | 562100J1 |
| Jurid | 562100JC |
| LPR | M2014P |
| Mapco | 25811C |
| Mercedes-Benz | 163 423 01 12 |
| Mercedes-Benz | 1634230112 |
| Mercedes-Benz | A 163 421 01 12 |
| Mercedes-Benz | A 163 423 01 12 |
| Mercedes-Benz | AA1634210112 |
| Mercedes-Benz | AA1634230112 |
| METELLI | 230769C |
| MEYLE | 0155230025PD |
| Mintex | MDC1360 |
| NK Autoparts | 203354 |
| NK Autoparts | 313354 |
| NK Autoparts | 343354 |
| Optimal | BS7060 |
| Optimal | BS7060C |
| PAGID Racing | 52168 |
| PAGID Racing | 52168PRO |
| Quinton Hazell | BDC5058 |
| Remsa | 679900 |
| SBS | 1815203354 |
| SBS | 1815313354 |
| SBS | 1815343354 |
| Textar | 92090000 |
| Textar | 92090003 |
| Textar | 92090005 |
| Textar | 98200090001 |
| Trucktec | 0235078 |
| TRW | DF4195 |
| Valeo | 186753 |
| Valeo | 207002 |
| Zimmermann | 400360400 |
| Zimmermann | 400360420 |
| Zimmermann | 400360453 |
| Zimmermann | 400360470 |
| Zimmermann | 400360472 |
| Zimmermann | 400360475 |
Fits Years: 1998 1999 2000 2001 2002 2003
Fits Models: ML320
