Voice or type your vehicle details and Wrenchy will confirm fitment in seconds.
| Attribute | Value |
|---|---|
| 4181 ABS Tone Ring Included | No |
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.44, 62.00 |
| Construction | Composite, Full Cast |
| Discard Thickness | 23, 23.00 |
| Grade Type | Premium |
| Material | High Carbon Cast Iron |
| Nominal Thickness | 25, 25.00 |
| Overall Height | 1.93, 49, 49.00 |
| Rust Resistant Coating | Yes |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| Weight | 6.3 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | SUV | 2004 - 2005 | L4 2.4L | AWD/FWD Automatic & Manual |
| Base | SUV | 2001 - 2003 | -- -L BATTERY EV (EV/BEV) | AWD/FWD Automatic & Manual & N/R |
| Base | SUV | 2001 - 2003 | L4 2.0L | AWD/FWD Automatic & Manual & N/R |
| L | SUV | 2005 | L4 2.4L | AWD/FWD Manual |
| L | SUV | 2004 - 2005 | L4 2.4L | AWD/FWD Automatic |
| Sport | SUV | 2005 | L4 2.4L | AWD/FWD Automatic & Manual |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| Aimco | 31295 |
| ATE | 24012501431 |
| ATE | CW25703 |
| Beck/Arnley | 083-2878 |
| Bosch | 0986479111 |
| Bosch | 0986UB1229 |
| Brembo | 25679 |
| Centric Parts | 120.44121 |
| Centric Parts | 121.44121 |
| Centric Parts | 125.44121 |
| Centric Parts | 320.44121 |
| Centric Parts | 32044118F |
| DuraGo | BR31295 |
| DuraGo | BR3129501 |
| DuraGo | BR3129502 |
| Ferodo | DDF1216C |
| NAPA Proformer | PFR 248880033 |
| PowerStop | JBR974 |
| PowerStop | JBR974EVC |
| Raybestos Brakes | 980033 |
| Raybestos Brakes | 980033FZN |
| Raybestos Brakes | 980033R |
| Textar | 92139700 |
| Toyota | 43512-42030 |
| Toyota | 43512-42031 |
| Toyota | 43512-42032 |
| Toyota | 4351242030 |
| Toyota | 4351242031 |
| Toyota | 4351242032 |
| TRW | DF4161 |
| Wagner Brake | BD126064 |
| Wagner Brake | BD126064E |
| Winhere | 442825 |
| Zimmermann | 590.2589.00 |
| Zimmermann | 590258900 |
Fits Years: 2001 2002 2003 2004 2005
Fits Models: RAV4
