| Attribute | Value |
|---|---|
| 112.00 | |
| ABS Tone Ring Included | No |
| Assy/Disassy By Qualified Personnel Required! | . |
| Balancing Type | Mill Balancing |
| Bearings Included | No |
| Bolt Hole Circle Ø [in] | 4.41 |
| Bolt Hole Circle Ø [mm] | 112 |
| Bolt Hole Quantity | 6 |
| Brake Disc Thickness [in] | 1.02 |
| Brake Disc Thickness [mm] | 26 |
| Brake Disc Type | Internally Vented |
| California Proposition 65 Required | No |
| Center Hole Diameter | 112.0 |
| Color | Silver |
| Colour | Silver |
| Construction | Full Cast |
| Directional Or Non Directional Brake Surface | Non-directional |
| Disc Finish | Coated |
| Discard Thickness | 22.00 |
| Grade Type | Standard Replacement |
| Hat Finish | Coated |
| Hole Arrangement / Number | 05/06 |
| Hole Arrangement/Number | 05/06 |
| Inner Diameter [in] | 5.71 |
| Inside Diameter | 68.2 |
| Machining | High-carbon |
| Material | Gray Cast Iron |
| Minimum Thickness [in] | 0.87 |
| Mounting Bolt Hole Circle Diameter | 112.00 |
| Mounting Bolt Hole Quantity | 6 |
| Nominal Thickness | 26.00 |
| Outer Diameter [in] | 12.32 |
| Overall Height | 56.20 |
| Rust Resistant Coating | Yes |
| Solid Or Vented Type Rotor | Vented |
| Surface | Coated |
| Surface Type | Smooth |
| Technical Information Number | 50348pro_hc_na |
| Weight [kg] | 9,4, 9.4 |
| Wheel Bolt Bore Diameter [mm] | 16.5 |
| Wheel Bolt Bore Ø [mm] | 16.5 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | Mini Passenger Van | 2001 - 2003 | L5 2.5L | FWD Manual |
| GLS | Standard Passenger Van | 2001 - 2003 | V6 2.8L | FWD Automatic & Manual |
| MV | Standard Passenger Van | 2001 - 2003 | V6 2.8L | FWD Automatic & Manual |
| MV | Van Camper | 2001 - 2003 | V6 2.8L | FWD Automatic & Manual |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| Akebono | BN0037 |
| Akebono | BN0037E |
| AMC | FO2972 |
| ATE | 24012601191 |
| ATE | 24032601191 |
| ATE | 426119 |
| Bendix | 521029 |
| Bendix | 562626BC |
| Blue Print | ADV1843130 |
| Borg & Beck | BBD5121 |
| Bosch | 0986478296 |
| Brake Engineering | DI956141 |
| Brembo | 09979710 |
| Brembo | 09979711 |
| Brembo | 09979714 |
| Cifam | 800792 |
| Delphi | BG3719 |
| DON | PCD12102 |
| Dynamic Friction Company | 600-74045 |
| Dynamic Friction Company | 600-92027 |
| Febi-Bilstein | 21941 |
| Ferodo | DDF1160 |
| Ferodo | DDF11601 |
| Ferodo | DDF1160C |
| Ferodo | DDF1160C1 |
| FREMAX BRAKE ROTORS AND DRUMS | BD1530 |
| FTE | 9071125 |
| FTE | 9081104 |
| FTE | 9082558 |
| FTE | BS5264 |
| FTE | BS5264B |
| FTE | BS5264HB |
| Girling | 6043105 |
| Hella Pagid | 50348PROHCNA |
| Hella Pagid | 8DD355108102 |
| Japan Parts | DI0315 |
| Japan Parts | DI0315C |
| JP Group A/S | 1163105300 |
| Jurid | 562626JC |
| Jurid | 562626JC1 |
| LPR | V2001V |
| Magneti Marelli | 360406050900 |
| Mapco | 25843C |
| METELLI | 230792 |
| MEYLE | 1155210040 |
| MEYLE | 1155210040PD |
| MEYLE | 1155211116PD |
| Mintex | MDC1552 |
| NK Autoparts | 204783 |
| NK Autoparts | 314783 |
| NK Autoparts | 344783 |
| Optimal | BS8122 |
| Optimal | BS8122C |
| Optimal | BS8122HC |
| PAGID Racing | 50348 |
| PAGID Racing | 50348PRO |
| Remsa | 672810 |
| SBS | 1815204783 |
| SBS | 1815314783 |
| SBS | 1815344783 |
| Textar | 92109900 |
| Textar | 92109903 |
| Textar | 92109905 |
| Textar | 98200109901 |
| Topran | 110431 |
| TRW | DF4310S |
| VAICO | V1080113 |
| Valeo | 186800 |
| Valeo | 672947 |
| Volkswagen | 7M3 361 301 |
| Zimmermann | 250134700 |
| Zimmermann | 250134720 |
| Zimmermann | 250134752 |
| Zimmermann | 250134770 |
| Zimmermann | 250134772 |
| Zimmermann | 250134775 |
Fits Years: 2001 2002 2003
Fits Models: EuroVan
