| Attribute | Value |
|---|---|
| ABS Tone Ring Included | No |
| Assy/Disassy By Qualified Personnel Required! | . |
| Balancing Type | Mill Balancing |
| Bearings Included | No |
| Bolt Hole Circle Ø [in] | 4.25 |
| Bolt Hole Circle Ø [mm] | 108 |
| Brake Disc Thickness [in] | 1.10 |
| Brake Disc Thickness [mm] | 28 |
| Brake Disc Type | Internally Vented |
| California Proposition 65 Required | No |
| Center Hole Diameter | 130.0 |
| Construction | Full Cast |
| Directional Or Non Directional Brake Surface | Non-directional |
| Disc Finish | Coated |
| Discard Thickness | 25.5 |
| Grade Type | Standard Replacement |
| Hat Finish | Coated |
| Height [in] | 1.89 |
| Hole Arrangement / Number | 05/06 |
| Hole Arrangement/Number | 05/06 |
| Inner Diameter [in] | 5.55 |
| Inside Diameter | 63.5 |
| Machining | High-carbon |
| Material | Gray Cast Iron |
| Minimum Thickness [mm] | 25,5, 25.5 |
| Mounting Bolt Hole Circle Diameter | 108.0 |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 28.0 |
| Outer Diameter [in] | 12.68 |
| Overall Height | 48.0 |
| Rust Resistant Coating | Yes |
| Solid Or Vented Type Rotor | Vented |
| Surface | Coated |
| Surface Type | Smooth |
| Technical Information Number | 55874pro_hc |
| Weight [kg] | 9,8, 9.8 |
| Wheel Bolt Bore Diameter [mm] | 15.8 |
| Wheel Bolt Bore Ø [mm] | 15.8 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| B6 Inscription | Sedan | 2022 | L4 2.0L MILD HYBRID EV-GAS (MHEV) Turbo/Supercharged | AWD Automatic |
| B6 Momentum | Sedan | 2022 | L4 2.0L MILD HYBRID EV-GAS (MHEV) Turbo/Supercharged | AWD Automatic |
| B6 Plus | Sedan | 2023 - 2024 | L4 2.0L MILD HYBRID EV-GAS (MHEV) Turbo/Supercharged | AWD Automatic |
| B6 R-Design | Sedan | 2022 | L4 2.0L MILD HYBRID EV-GAS (MHEV) Turbo/Supercharged | AWD Automatic |
| B6 Ultimate | Sedan | 2023 - 2024 | L4 2.0L MILD HYBRID EV-GAS (MHEV) Turbo/Supercharged | AWD Automatic |
| T5 Inscription | Sedan | 2017 | L4 2.0L Turbo | FWD Automatic |
| T5 Momentum | Sedan | 2018 - 2019 | L4 2.0L Turbo | AWD Automatic |
| T5 Momentum | Sedan | 2017 - 2019 | L4 2.0L Turbo | FWD Automatic |
| T6 Inscription | Sedan | 2017 - 2021 | L4 2.0L Turbo/Supercharged | AWD Automatic |
| T6 Momentum | Sedan | 2017 - 2021 | L4 2.0L Turbo/Supercharged | AWD Automatic |
| T6 R-Design | Sedan | 2020 - 2021 | L4 2.0L Turbo/Supercharged | AWD Automatic |
| T8 Inscription | Sedan | 2018 - 2020 | L4 2.0L PLUG-IN HYBRID EV-GAS (PHEV) Turbo/Supercharged | AWD Automatic |
| T8 Momentum | Sedan | 2018 - 2019 | L4 2.0L PLUG-IN HYBRID EV-GAS (PHEV) Turbo/Supercharged | AWD Automatic |
| T8 R-Design | Sedan | 2020 | L4 2.0L PLUG-IN HYBRID EV-GAS (PHEV) Turbo/Supercharged | AWD Automatic |
| T8 Recharge Inscription | Sedan | 2021 - 2022 | L4 2.0L PLUG-IN HYBRID EV-GAS (PHEV) Turbo/Supercharged | AWD Automatic |
| T8 Recharge Plus | Sedan | 2023 - 2024 | L4 2.0L PLUG-IN HYBRID EV-GAS (PHEV) Turbo/Supercharged | AWD Automatic |
| T8 Recharge R-Design | Sedan | 2021 - 2022 | L4 2.0L PLUG-IN HYBRID EV-GAS (PHEV) Turbo/Supercharged | AWD Automatic |
| T8 Recharge Ultimate | Sedan | 2023 - 2024 | L4 2.0L PLUG-IN HYBRID EV-GAS (PHEV) Turbo/Supercharged | AWD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| ATE | 24012803131 |
| Blue Print | ADF124365 |
| Borg & Beck | BBD6148S |
| Bosch | 0986479F90 |
| Brake Engineering | DI957137 |
| Brembo | 09D25111 |
| Brembo | 09D2511E |
| Cifam | 8001888C |
| Delphi | BG9330C |
| Dynamic Friction Company | 600-27059 |
| Dynamic Friction Company | 604-27059 |
| Dynamic Friction Company | 900-27059 |
| EBC Brakes | D2080 |
| Febi-Bilstein | 106352 |
| Ferodo | DDF2693C |
| FREMAX BRAKE ROTORS AND DRUMS | BD7295 |
| Hella Pagid | 55874PROHC |
| Hella Pagid | 8DD355125471 |
| JP Group A/S | 4963102200 |
| Jurid | 563257JC |
| Jurid | 563257JC1 |
| LPR | V1033VR |
| Magneti Marelli | 3.60406E+11 |
| Magneti Marelli | 3.61302E+11 |
| Magneti Marelli | 360406180401 |
| Magneti Marelli | 361302040832 |
| METELLI | 231888C |
| MEYLE | 5835210046PD |
| Mintex | MDC2761 |
| Mintex | MDC82761C |
| Motaquip | LVBD1853 |
| National | NBD2164 |
| NK Autoparts | 314876 |
| Optimal | BS9622HC |
| PAGID Racing | 55874 |
| PAGID Racing | 55874HC |
| Quinton Hazell | BDC6176 |
| Remsa | 6212910 |
| SBS | 1815314876 |
| Textar | 98200287401 |
| TRW | DF8371S |
| Volvo | 3 142 372 4 |
| Volvo | 31423724-0 |
| Volvo | 31471413 |
| Volvo | 31471413-0 |
| Volvo | 31665446 |
| Volvo | 31665446-0 |
| Volvo | 32217561 |
| Volvo | 32217561-0 |
| Volvo | 32233185 |
| Volvo | 32233185-0 |
| Volvo | 32254356 |
| Volvo | 32254356-0 |
| Volvo | 32300122 |
| Volvo | 32300122-0 |
| Volvo | 92287405 |
| Volvo | 92287405-0 |
| Volvo Truck | 31423724 |
| Werner Metzger GmbH | 6110991 |
| Zimmermann | 610372520 |
| Zimmermann | 610372552 |
| Zimmermann | 610372553 |
Fits Years: 2017 2018 2019 2020 2021 2022 2023 2024
Fits Models: S90
