Quick Summary

The BMW 428i's turn-signal light-also called a blinker, indicator lamp, flasher, or side-repeater-uses a PY24W 24-watt halogen bulb at the front and a 7506/PY21W bulb at the rear on most 2014-2016 models. Upgrading to LED versions boosts brightness and life but can cause "hyper-flash" unless the car is coded or load resistors are added. Federal rules say front indicators must shine amber and blink 60-120 times per minute, while state laws require both sides to work or you may be ticketed. Replacing the lamp takes about 10 minutes with a screwdriver through the wheel-well hatch. Prices run \$3-\$20 for a standard bulb and \$40-\$80 for quality LED kits. Always recycle old bulbs-many contain glass and metal that shouldn't go in household trash.

---

Part Basics

* **Name & Role** - The turn-signal light warns other drivers when you plan to turn or change lanes. It sits in the head-lamp housing up front and in the tail-lamp cluster at the rear. ([Dealer eProcess])

* **Factory Bulb** - PY24W (24 W, 12 V, amber, PGU20-4 base) up front; 7506/PY21W (21 W, BAU15s base) in back. ([PartsGeek], [BulbAmerica])

* **Brightness** - About 280-300 lumens for stock halogen. ([Alibaba])

---

How It Works

When you move the stalk, a relay or body-control module pulses power to the bulb. It flashes around 90 times per minute to meet federal and SAE standards. ([eCFR], [SAE International])

---

Fit & Compatibility

The same PY24W front bulb is shared by BMW 428i, 430i, 435i, and 440i coupes (F32) built 2014-2016 and many xDrive or Gran Coupé variants. Always match the head-lamp type-cars with Xenon or LED headlights still use the same indicator socket. ([PartsGeek], [CarCareKiosk])

---

Bulb Options

| Type | Lifespan | Notes |

| ----------------- | --------- | --------------------------------------------------------------------------------------------------------------------- |

| Halogen PY24W | \~500 h | Cheap, plug-in. ([BulbAmerica]) |

| Long-life Halogen | \~1 000 h | Thicker filament, lower brightness. ([AutoZone.com]) |

| LED Retrofit | 20 000 h+ | Up to 4× brighter, draws <6 W, runs cooler. Requires CAN-bus friendly design. ([Diode Dynamics], [Bimmerpost]) |

---

LED Upgrades

Modern LED "switchbacks" swap amber blinking with white running-light mode but must still flash amber to stay legal under FMVSS 108. ([eCFR])

Hyper-flash (rapid blinking) happens because LEDs draw less current; fix it by:

1. Coding the body control module (dealer or specialist). ([E90Post])

2. Adding 6-ohm load resistors in parallel (one per bulb). ([BMW Sport Touring], [Diode Dynamics])

Mount resistors on metal-they reach 200 °F.

---

Common Problems

* **Burned-out filament** - Most frequent, causes fast flash on dash. ([CarCareKiosk])

* **Moisture in housing** - Fogged lens can corrode the socket.

* **Socket melt** - Over-watt bulbs overheat plastic.

* **Wiring break** - Look for broken ground wire if both sides fail.

---

Diagnosis

1. Turn hazards on; walk around the car. The dark side pinpoints the failed lamp. ([CarCareKiosk])

2. Swap the suspect bulb left↔right. If the problem follows the bulb, replace it.

3. Check for a "bulb out" i-Drive warning.

4. Measure voltage at the socket (should read battery voltage with stalk active).

---

Replacement Steps

*Front bulb* (F32/F36):

1. Turn wheel inward for room.

2. Remove three 8 mm screws on the fender-liner door.

3. Pull the liner flap back to see the round bulb holder.

4. Twist holder counter-clockwise ⅛ turn, pull out. ([Bimmerpost])

5. Tug bulb straight out (no twist).

6. Push new PY24W in firmly-avoid touching glass.

7. Re-install holder, liner, screws. Test flash.

The process takes \~10 minutes and no special tools. A **video tutorial** is available on [CarCareKiosk](https://www.carcarekiosk.com/video/2016_BMW_428i_xDrive_Gran_Coupe_2.0L_4_Cyl._Turbo_Hatchback_%284_Door%29/lights/turn_signal_front) for visual reference. ([CarCareKiosk])

---

Legal Rules

* Front indicators must shine **amber/yellow**; rear may be amber or red. ([eCFR], [eCFR])

* Minimum mounting height is 15 inches (381 mm) from the ground. ([eCFR])

* Flash rate must stay between 60-120 per minute. ([eCFR])

* Check open recalls by VIN on the [NHTSA Recall Lookup](https://www.nhtsa.gov/recalls) site. ([NHTSA])

---

Safety Tips

* Replace bulbs in pairs-old ones dim before failing. ([CarCareKiosk])

* Wear gloves; oils on skin shorten bulb life.

* After install, test hazards, brakes, and running lights to be sure nothing else was disturbed.

---

Cost & Value

| Item | Typical Price (USD) |

| ----------------------------------------------------------------------------- | ------------------------------------------------------ |

| Standard PY24W bulb | \$3 - \$8 each ([PartsGeek]) |

| Premium halogen | \$15 - \$25 |

| Quality LED kit (pair) | \$40 - \$80 including resistors ([Diode Dynamics]) |

| Labor at an independent shop averages 0.3 hr, or \$45 - \$60 in most regions. | |

---

Disposal & Recycling

Never toss spent automotive bulbs in regular trash. Glass shards and trace metals harm landfills. Package them and drop off at local hazardous-waste or recycling centers, following EPA guidance. ([US EPA], [Better Homes & Gardens])

---

Frequently Asked Questions

**Q:** What bulb does a 2014-2016 BMW 428i front blinker use?

**A:** A PY24W 24-watt amber bulb with a PGU20-4 base. ([PartsGeek])

**Q:** Can I put LEDs in place of halogen?

**A:** Yes-choose a CAN-bus-safe PY24W LED and add coding or resistors to avoid hyper-flash. ([Diode Dynamics])

**Q:** Why is the indicator blinking fast?

**A:** The car detects low current from a burnt bulb or an LED without load resistors, so it speeds up the flash. ([Bimmerpost])

**Q:** Do both turn-signal lights have to work to pass inspection?

**A:** Yes. U.S. law requires functional lamps on both sides or the vehicle is deemed unsafe. ([eCFR])

**Q:** What color must the front signal be?

**A:** Amber (yellow) only. White or blue is illegal. ([eCFR])

**Q:** How long does a stock bulb last?

**A:** Roughly 500 hours of flashing-about 3-4 years for most drivers. ([BulbAmerica])

**Q:** Will installing LEDs void my warranty?

**A:** Using non-BMW bulbs can void coverage on the bulb itself but normally won't affect the full vehicle warranty unless damage occurs. Check your manual for specifics. ([Dealer eProcess])

**Q:** Is there a recall for BMW 428i turn signals?

**A:** None specific to this model year, but always verify using your VIN on the NHTSA site. ([NHTSA])

**Q:** How do I recycle dead bulbs?

**A:** Place them in a sealed box and bring to a hazardous-waste drop-off or bulb-recycling program as recommended by the EPA. ([US EPA])

**Q:** What tools do I need to change the front bulb?

**A:** A flat screwdriver or 8 mm socket and gloves-nothing else. ([Bimmerpost])

---

```
