Dodge Ram 1500 Tail Light Overview

The tail light assembly on a Dodge Ram 1500 serves multiple functions: it illuminates the rear of the vehicle, signals braking and turning intentions, and enhances visibility for other drivers. Over the years, the Ram 1500 has seen various tail light designs, ranging from traditional incandescent bulbs to modern LED configurations.

Tail light assemblies are typically composed of several components: the housing, lens, bulbs, and wiring. The housing protects the internal components, while the lens allows light to pass through. Bulbs emit light when powered, and the wiring connects the bulbs to the vehicle's electrical system. (YouTube)

When considering a replacement or upgrade, it's essential to ensure compatibility with your specific Ram 1500 model year and trim level. For instance, newer models may feature integrated sensors for advanced safety features, influencing the design and cost of the tail light assembly. (Amazon, Reddit)

Tail Light Bulb Specifications(Walmart.com)

Understanding the correct bulb specifications is crucial for maintenance or upgrades. The Dodge Ram 1500 utilizes various bulb types across different model years: (JustAnswer)

• 2019-2023 Models: These models commonly use the 7440 or 7443 bulb type for tail lights. (5th Gen Rams)
• 2010-2018 Models: The 3157 or 3156 bulb types are prevalent during these years. (AUXITO)
• 2009 and Older Models: Earlier models may use the 3157 or 3057 bulb types. (Ram Forum)

It's important to verify the bulb type specific to your vehicle's model year before purchasing replacements.

Tail Light Wiring Diagrams(5th Gen Rams)

For those interested in custom lighting setups or troubleshooting, understanding the tail light wiring is beneficial. For example, on the left tail light of certain Ram 1500 models, the wiring color codes are: (5th Gen Rams)

• White with Purple Stripe: Reverse lights
• White with Yellow Stripe: Left turn signal
• Black: Ground
• White with Orange Stripe: Running lights

On the right tail light, the wiring color codes are:

• White with Yellow Stripe: Right turn signal

These color codes can assist in diagnosing issues or when installing aftermarket lighting solutions.

Tail Light Installation Tips(Reddit)

Replacing or upgrading tail lights on a Ram 1500 is generally straightforward. For models from 2009 to 2018, the process typically involves: (CarParts)

1. Opening the tailgate.
2. Removing screws or bolts securing the tail light assembly.
3. Gently pulling the assembly away from the vehicle.
4. Disconnecting the wiring harness.
5. Replacing the old assembly with the new one.
6. Reattaching the screws or bolts. (, O'Reilly Auto Parts)

For a visual guide, refer to this installation video:

For 2011-2018 models, the installation process is similar, with slight variations depending on the specific year and trim.

Tail Light Replacement Costs(eBay)

The cost of replacing a tail light assembly on a Dodge Ram 1500 varies based on factors like model year, trim level, and whether the part is OEM (Original Equipment Manufacturer) or aftermarket. For instance, OEM LED tail lights with integrated sensors for advanced safety features can range from $500 to $600. (Reddit)

Aftermarket options may offer more affordable choices, with prices starting around $40, depending on the brand and features. (CarParts)

Tail Light Upgrade Options

For those looking to enhance the appearance or functionality of their Ram 1500, several upgrade options are available:

• LED Tail Lights: Offer brighter illumination and a modern look.
• Fiber Optic LED Tail Lights: Provide a sleek design with dynamic lighting effects. (Wonderful Engineering)
• Smoked Lens Tail Lights: Give a more aggressive appearance.

When considering upgrades, ensure compatibility with your vehicle's model year and trim level.

Frequently Asked Questions (FAQ)

Q: What bulb type does my 2019 Ram 1500 use for the tail light?
A: The 2019 Ram 1500 typically uses the 7440 or 7443 bulb type for the tail light. (5th Gen Rams)

Q: How do I replace the tail light bulb on a 2014 Ram 1500?
A: For the 2014 Ram 1500, the replacement process involves opening the tailgate, removing the screws securing the tail light assembly, pulling the assembly away, disconnecting the wiring harness, and replacing the bulb. (CarParts)

Q: What is the cost to replace a tail light on a 2020 Ram 1500?
A: Replacing a tail light on a 2020 Ram 1500 can cost between $500 and $600 for OEM parts, especially if the assembly includes integrated sensors. (Reddit)

Q: Can I upgrade my tail lights to LED on a 2015 Ram 1500?
A: Yes, LED tail light upgrades are available for the 2015 Ram 1500. Ensure compatibility with your vehicle's specifications before purchasing.

Q: Where can I find a wiring diagram for my 2016 Ram 1500 tail light?
A: Wiring diagrams for the 2016 Ram 1500 tail light can be found on various automotive forums and resources online.

Q: What are the wiring color codes for the tail light on a 2020 Ram 1500?
A: For the 2020 Ram 1500, the wiring color codes are:

• Left Tail Light:
  • White with Purple Stripe = Reverse Lights
  • White with Yellow Stripe = Left Turn Signal
  • Black = Ground
  • White with Orange Stripe = Running Lights (5th Gen Rams)
• Right Tail Light:
  • White with Yellow Stripe = Right Turn Signal

These codes are helpful for diagnostics or custom installations.
