2007-2013 Audi A4, S4, A5, S5 ABS Module: Decoding Failures, Programming, and Compatibility
This guide covers the critical details of replacing the ABS control module on the Audi A4, S4, A5, and S5, including the essential role of programming and verifying vehicle options.
- Programming is mandatory. A new or used module must be programmed by a dealer or specialist shop to remove 'Component Protection' and code it to your car's VIN and options.
- Compatibility is critical. You must match the OEM part number exactly AND verify the module is for the correct drivetrain (FWD vs. Quattro) and ESP option code (e.g., 1AS, 1AT).
- Driving is not recommended. A failed module disables ABS, traction control, and stability control, significantly compromising vehicle safety in emergency situations.
- Repairing your original module is a viable option. Sending your specific unit for remanufacturing can often bypass the need for costly reprogramming.
Symptoms of a Failing ABS Control Module
A failing ABS module on your 2007-2013 Audi A4, 2010-2013 Audi S4, or 2013 A5/S5 will typically make its presence known through a variety of dashboard warnings and braking irregularities. The most common sign is a 'Christmas tree' effect on your instrument cluster, where multiple warning lights illuminate simultaneously.
- ABS, ESP/Traction Control, and Brake Warning Lights: The most direct symptom is the illumination of the ABS and Electronic Stability Program (ESP) or traction control warning lights. Often, the main red brake warning light will also appear.
- Unresponsive or Spongy Brake Pedal: You might notice a change in how the brake pedal feels. It could become hard to press, feel unresponsive, or require more effort than usual to slow the vehicle down.
- Brakes Locking Up: The primary function of ABS is to prevent wheel lock-up. If your wheels lock and skid during a hard stop, it's a clear sign the system is not functioning.
- Loss of Related Systems: Because the ABS module shares data with other systems, its failure can sometimes cause the speedometer to stop working or display erratic readings.
- Diagnostic Trouble Codes (DTCs): A scan tool will likely reveal specific fault codes. Common codes point to communication errors, internal module failure, or issues with the ABS pump motor. A prevalent code in this generation is C123EF0, indicating a "Hydraulic Brake Booster Limit Value Reached".
Known Issues, TSBs, and Recalls
For certain model years, Audi and Volkswagen Group issued recalls related to the ABS control module. A significant issue was the potential for an insufficient ground connection within the module, which could cause it to fail during ABS or ESC activation. The recall (NHTSA Campaign Number 16V913) involved dealers updating the ABS module's software to better diagnose this grounding issue. If the fault was detected, the module would be replaced free of charge. Owners of affected vehicles should verify with an authorized Audi dealer if this recall action was performed on their car.
Warning: Even if a recall was performed, the module can still fail due to other reasons. The recall specifically addressed the internal grounding fault.
Programming and Installation Requirements
Replacing the ABS control module in these Audi models is not a simple plug-and-play operation. Programming is mandatory for the part to function correctly and integrate with the vehicle's other electronic systems.
🎬 Watch this DIY guide for replacing and programming the module.Component Protection
Audi vehicles are equipped with an anti-theft system called Component Protection (CP). This system links major electronic modules, including the ABS unit, to the vehicle's unique Vehicle Identification Number (VIN). If you install a new or used ABS module, the Component Protection will be active, and the module will have limited or no functionality until it is adapted to your car. Removing the Component Protection requires special diagnostic tools (like ODIS, the factory tool) that can connect to Audi's online servers to match the module to the car. This procedure must be performed by an Audi dealership or a qualified independent shop with the proper equipment and subscription.
Coding and Adaptation
Beyond Component Protection, the module must be correctly coded with your vehicle's specific equipment, such as drivetrain (FWD or Quattro), engine, and other options. Incorrect coding will result in fault codes and non-functional ABS/ESP systems.
Buying a Used ABS Control Module
Purchasing a used OEM ABS module is a cost-effective alternative to a new unit, but careful verification is essential to avoid compatibility problems.
- Match Part Numbers Exactly: The most critical step is to match the OEM part number from your original module to the replacement part. Part numbers are printed on a sticker on the module housing. Even a one-letter difference can signify an incompatible part.
- Verify Drivetrain and Options (PR Codes): Audi uses 3-digit Production-Relevant (PR) codes to identify vehicle options. You must ensure the replacement module comes from a vehicle with the same drivetrain (Front-Wheel Drive vs. All-Wheel Drive/Quattro) and Electronic Stability Program (ESP) option. Common PR codes for ESP on these models are 1AS and 1AT. You can find your vehicle's PR code sticker in the trunk near the spare tire or on the first page of your maintenance manual.
- Physical Inspection: When you receive the used module, inspect the electrical connector pins for any signs of corrosion or damage. Water intrusion can damage these units, so a clean connector is a good sign.
- Factor in Programming Costs: Remember that a used module will always require professional programming to remove Component Protection and code it to your vehicle. Contact local Audi specialists or the dealer beforehand to get a quote for this service.
Pro Tip: Having your original module repaired or remanufactured can be a great option. A repaired original module often does not require reprogramming, as it retains your vehicle's original coding and VIN information.
Cost Breakdown
The cost to replace an ABS control module can vary significantly based on the path you choose. Programming costs are separate from the part and installation labor.
| Item | Estimated Cost | Notes |
|---|---|---|
| New OEM Part | $2,300 - $2,800 | Purchased from an Audi dealership. |
| Remanufactured Part | $200 - $500 | Your original unit is sent out for repair. Often no reprogramming is needed. |
| Used OEM Part | $150 - $400 | Price varies by supplier and condition. Requires programming. |
| Shop Labor (Installation) | $275 - $400 | This includes physical removal/installation and bleeding the brake system. |
| Shop Labor (Programming) | $150 - $300 | Required for new and used modules to remove Component Protection and code the unit. |
Frequently Asked Questions
Do I have to replace the entire ABS pump assembly?
Not always. The electronic control module can often be separated from the hydraulic pump/valve block assembly. The module is typically held on by several Torx screws. If only the electronic module has failed, you can replace it without opening the hydraulic brake lines, which saves you from having to bleed the entire brake system. However, many used parts are sold as a complete pump and module assembly.
Can I drive my Audi with a bad ABS module?
While the vehicle may be drivable, it is not recommended. A failed ABS module means the anti-lock braking, traction control, and stability control systems are disabled. This significantly increases the risk of losing control during an emergency stop or on slippery surfaces. Your standard brakes will still function, but without the crucial safety net these systems provide.
Can an independent mechanic program a used Audi ABS module?
Yes, but only if they have the specific, authorized diagnostic tools and software (like ODIS with an online connection) required to communicate with Audi's servers for Component Protection removal. Many general repair shops do not have this capability, so you must verify with them before starting the repair. Otherwise, a trip to the dealership will be necessary.
How do I find my car's option codes like '1AS' or '1AT'?
You can find the vehicle data sticker, which lists all the three-digit PR (Production-Relevant) codes for your car's options. This sticker is typically located in the trunk, in the spare tire well. A duplicate of this sticker is also usually found on the first page of the vehicle's original maintenance booklet.
🎬 See exactly where to find your vehicle's option code sticker.Helpful Videos
![[How to] Audi Options Package Sticker Label Location A3 A4 A5 A6 A7 A8 Q3 Q5 Q7 2018](https://img.youtube.com/vi/KIZJekRobeU/mqdefault.jpg)
Technical Specifications
OEM Part Numbers: 8E0614517AM 8E0614517BG 8K0614517CG 8K0614517CL 8K0614517EB 8K0614517EK 8K0614517EL 8K0614517GM 8K0614517GN 8K0907379CK 8K0614517FN 8K0614517FL
Compatibility is determined by exact part number, drivetrain (FWD or Quattro), and specific ESP option codes (PR codes) such as 1AS or 1AT.
