2020-2025 Mazda CX-30 Driver Airbag: SRS Lights, Recalls, and Replacement Warnings

Critical Safety Warning: Professional Installation is Mandatory

Known Issues and Recalls for Mazda CX-30

While this specific driver airbag module has not been the subject of a recall, there is a critical recall for the broader SRS system on certain CX-30 models.

Recall: Airbags May Be Deactivated (NHTSA Campaign 25V357000)

Mazda issued a recall for certain 2024-2025 Mazda CX-30 and Mazda3 vehicles due to an issue where the airbags could be deactivated.

• The Problem: The issue occurs under a very specific circumstance. If the vehicle's ignition is left in the 'ON' position for two hours or more without the engine running, the 12-volt battery can become depleted. This can cause the Sophisticated Air Bag Sensor (SAS) unit to store an internal fault.
• The Consequence: After the battery is recharged and the vehicle is started, the airbag warning light will illuminate on the dashboard. When this light is on, the airbags will not deploy in a crash, increasing the risk of injury.
• The Fix: Mazda dealers will reprogram the SAS unit with improved software or replace the unit entirely, free of charge. Owner notification letters were expected to be mailed by July 28, 2025.

This recall does not apply to 2020-2023 models and is not a defect with the airbag itself, but rather the control system logic. However, it highlights how sensitive the SRS system is to battery voltage.

Symptoms of a Faulty Airbag System

The most common sign of a problem within the SRS system is the airbag warning light on your instrument cluster.

1. Solid SRS Airbag Warning Light

If the airbag warning light comes on and stays lit while you are driving, it means the onboard diagnostic system has detected a fault. The entire SRS system, including all airbags and seatbelt pretensioners, is disabled until the fault is repaired. This is a critical safety issue that requires immediate professional diagnosis.

2. Intermittent SRS Airbag Warning Light

An airbag light that turns on and off randomly can be frustrating. While it could indicate a failing component, it can also be caused by simpler issues. Some CX-30 owners have reported that a weak or dying 12-volt battery can cause an intermittent airbag light. Low voltage can create communication errors between the SRS modules. A loose connection under the seats or a faulty seat sensor can also be the culprit.

3. Steering Wheel Buttons Not Working

If your horn, cruise control, or audio buttons on the steering wheel stop working at the same time the airbag light comes on, the problem is almost certainly a failed clock spring. The clock spring is a coiled ribbon of wire inside the steering column that maintains electrical contact for all steering wheel components as it turns. When it breaks, the connection to the driver's airbag is lost, 🎬 Watch: How to replace a faulty steering wheel clock spring triggering a fault.

Buying a Used Airbag for Your Mazda CX-30

When replacing a deployed airbag, a used, non-deployed OEM unit from a reputable source is a safe and cost-effective alternative to a brand-new dealer part. There are no legitimate 'new aftermarket' airbags; any you find are likely counterfeit and extremely dangerous.

How to Inspect a Used Airbag

• Verify Part Number: Ensure the part number matches your vehicle's needs. The primary part numbers for this airbag are DGJ1-57-K00, DGJ1-57-K00A, and DGJ1-57-K00B.
• Check Compatibility: This airbag is for models with an indented, round horn pad. Visually confirm this matches your steering wheel.
• Source Vehicle History: Only purchase airbags from certified automotive recyclers who can verify the source vehicle was not in a flood or fire. Water damage can ruin the internal electronics and chemical inflator.
• Physical Inspection: Check that the plastic housing is not cracked or damaged. The electrical connectors should be clean, with no cut or spliced wires. The mounting points must be intact.
• Certification: Whenever possible, buy from a seller certified by the Automotive Recyclers Association (ARA). These sellers follow strict guidelines for harvesting, inspecting, and handling non-deployed airbags.

Replacement Information and System Reset

What's Involved in a Professional Replacement?

A technician will first disconnect the battery and wait for the system's capacitors to fully discharge. They will then unbolt the airbag module from the steering wheel, disconnect the electrical plugs, and remove it. The new airbag is then carefully mounted, torqued to the manufacturer's specification, and reconnected.

Post-Installation: Resetting the SRS Control Module

After an airbag deploys, the SRS control module stores 'crash data' or 'hard codes'. These codes cannot be cleared with a standard OBD-II scanner. The module itself must be either replaced with a new one (which then needs to be programmed to the vehicle's VIN) or sent to a specialist service that can reset it to factory condition. Resetting the original module is often the most cost-effective option as it avoids expensive dealer programming. 🎬 See how to clear crash data and reset your module A technician will perform this step after installing the new airbag to ensure the warning light goes out and the system is fully functional.

Related SRS Components

If your airbag has deployed, other parts of the system will also need to be replaced. These include:

• SRS Control Module: As mentioned, it must be reset or replaced.
• Clock Spring: Even if it wasn't the original cause of failure, it can be damaged during airbag deployment. It's often replaced as a precaution. A new clock spring for a CX-30 can cost over $500 for the part alone.
• Seat Belt Pretensioners: These use a small explosive charge to tighten the seatbelts during a crash. Once fired, they must be replaced.
• Crash Sensors: The front impact sensors may need to be replaced if they were damaged in the collision.

Cost of Replacement

Prices can vary based on your location and the specific needs of your vehicle.

Cost estimates are based on 2026 market data and can vary.

Frequently Asked Questions
