2012-2016 Nissan GT-R Console Guide: Black Edition vs. Premium Color Matching
This guide clarifies the critical differences between the overhead and center console panels, focusing on trim-specific color matching and common wear items.
- The biggest mistake is buying the wrong color overhead console. Black Edition/NISMO models require a dark grey/black console, while Premium/Pure models use light grey.
- Issues with the center console are almost always cosmetic, such as scratches and scuffs. Inspect photos of used parts carefully.
- Failure of the overhead console is typically minor and electrical (bad bulbs/switches). The widespread issue of consoles falling down on other Nissans is not common on the GT-R.
- Replacement for both the overhead and center console is DIY-friendly, with the overhead unit being a very simple 15-minute job.
Understanding GT-R Console Panels: Overhead vs. Center
When replacing a console panel on a 2012-2016 Nissan GT-R, it's crucial to identify which part you need. The term is used for both the overhead map light assembly in the headliner and the various trim pieces that make up the center console around the shifter. This guide covers both, with a special focus on common issues and compatibility problems.
Overhead Console (Map Light Assembly)
This unit contains your interior reading lights and the microphone for your Bluetooth system. Failure is typically electrical, but the most important factor when buying a used one is getting the correct color for your trim level.
Symptoms of a Failing Overhead Console
- Inoperative Map Lights: Bulbs may burn out, but the switch contacts or internal circuit board can also fail, preventing the lights from turning on. LED upgrade kits are a popular modification.
- Rattling Noises: Loose internal components or, more commonly, broken mounting clips can cause rattling or buzzing from the headliner area, especially over bumps.
- Poor Bluetooth Call Quality: A failing integrated microphone can cause others to not hear you clearly during hands-free calls.
Warning: While some other Nissan models are known for the entire overhead console assembly falling down due to brittle clips, this is not a widely reported systemic issue for the R35 GT-R. Failures are almost always electrical or cosmetic.
Variant Differences: The Black Edition Color Trap
The single most important check before buying a used overhead console is color matching. Nissan used different colored headliners for different GT-R trims, and the console must match.
- Premium / Pure Trims: These models typically have a light grey headliner and a matching light grey overhead console.
- Black Edition / NISMO Trims: These models feature a dark grey or black headliner and a matching dark console to create a uniform, sportier look.
Installing a grey console in a Black Edition will result in a mismatched interior. Always verify the part number or the color from the seller. Part number 26430-KB51B is specifically associated with the black console for Black Edition and NISMO models.
Center Console (Shifter Surround & Trim)
The center console area is comprised of several trim pieces that are prone to cosmetic wear from regular use. Unlike the overhead console, issues here are rarely electrical.
Common Center Console Issues
- Scratches and Scuffs: The plastic finisher panel around the shifter and the side panels are susceptible to scratches from keys, phones, or general wear.
- Worn or Peeling Buttons: The red Engine Start button and the silver finish on the infotainment control knob can wear down over time, exposing the plastic underneath.
- Cracked or Broken Trim: Damage can occur from improper removal or from an impact.
Because these issues are so common, a large aftermarket of carbon fiber overlays and full replacement panels exists for owners looking to upgrade or restore their interior.
Buying a Used GT-R Console Panel: What to Check
For a used part, careful inspection is key to getting a good value and avoiding installation headaches.
Checklist for a Used Overhead Console:
- Confirm the Color: This is the most critical step. Get a clear photo in good lighting to verify it's the light grey for a Premium or the dark grey/black for a Black Edition/NISMO.
- Inspect Mounting Tabs: Ask the seller for pictures of the top of the unit. Ensure all plastic mounting clips and tabs are intact and free of stress cracks. A console with broken tabs will not sit securely in the headliner.
- Check the Lens Covers: Make sure the clear plastic lenses for the map lights are not cracked, hazed, or missing.
Checklist for a Used Center Console:
- Analyze Surface Condition: Scrutinize photos for deep scratches, peeling clear coat, or significant scuffs. Minor surface swirls may be acceptable, but deep gouges will be very noticeable.
- Check Button Graphics: Look closely at the lettering and symbols on the Engine Start button and infotainment controls to ensure they aren't worn away.
- Verify All Mounting Points: Flip the part over (in photos) and check that all screw bosses and clip receivers on the underside are intact.
Known Issues, TSBs, and Recalls
There are no active recalls or common Technical Service Bulletins (TSBs) from Nissan specifically addressing failures of the overhead or center console panels for the 2012-2016 GT-R. Most issues are related to normal cosmetic wear and tear or isolated electrical faults.
Cost of Replacement
Prices can vary based on condition and source. Buying used OEM is often the most cost-effective solution for a perfect fit and finish.
| Part Type | New OEM | Used OEM | Shop Labor |
|---|---|---|---|
| Overhead Console Assembly | $300 - $450 | $150 - $250 | $50 - $100 |
| Center Console Finisher Panel | $250 - $400 | $100 - $200 | $125 - $250 |
Installation Guide & Difficulty
Overhead Console Replacement (Difficulty: 1/5)
This is a simple DIY task that usually takes less than 15 minutes.
🎬 See how to access the overhead console and remove the headliner.- Using a plastic trim removal tool, gently pry around the edges of the overhead console assembly.
- The console is held in by metal pressure clips. It will pop downwards.
- Support the console and disconnect the single electrical connector on the back.
- To install the new unit, simply plug in the connector, align the console with the opening in the headliner, and press firmly upwards until it clicks securely into place.
Center Console Replacement (Difficulty: 3/5)
Replacing the center console trim is more involved but manageable for a DIYer. It requires removing multiple pieces in the correct order.
🎬 Watch this step-by-step walkthrough for removing the center console trim.- Use a plastic pry tool to carefully remove the long side trim panels on both sides of the center console. They are held by clips.
- Once the side panels are off, you will have access to the clips and screws holding the main shifter surround finisher.
- Carefully lift the shifter surround. You will need to disconnect the electrical connectors for the shifter indicator, hazard switch, and vehicle dynamics switches before you can fully remove it.
- Installation is the reverse of removal. Be sure to reconnect all electrical harnesses before clipping the panels back into place.
Pro Tip: When removing the center console, use a plastic spoon or a dedicated trim tool to press down on the edge of the CD player slot. This can give you the leverage needed to pop the first clips without scratching the trim.
OEM Part Numbers
The initial part numbers provided cover a range of console components. This table helps clarify what they are. Always verify the exact part number with a dealer or seller for your specific VIN and trim.
| Part Number | Description | Common Trims |
|---|---|---|
| 26430-KB51B | Overhead Map Lamp Assembly | Black Edition / NISMO (Black Color) |
| 26430-KB51A | Overhead Map Lamp Assembly | Premium / Pure (Grey Color) |
| 26431-JF00A / 26432-JF00A | Map Lamp Lenses (Right/Left) | All Trims |
| 68961-JF00A | Center Console Finisher / Coin Pocket | All Trims |
| 96910-KB60B | Center Console Box Assembly | All Trims |
Frequently Asked Questions (FAQ)
Can I just replace the bulbs in my overhead console?
Yes. The map lights use standard incandescent bulbs that can be replaced. Many owners choose to upgrade to brighter, longer-lasting LED bulbs, which are available in kits from various aftermarket suppliers.
How can I fix a scratched center console?
For minor scratches, a high-quality plastic polish like Meguiar's PlastX may reduce their appearance. For deeper scratches, the most effective solutions are to either cover the panel with a vinyl wrap or a carbon fiber overlay, or to replace the panel entirely with a new or used part.
Will a console from a 2010 GT-R fit my 2014 GT-R?
For the overhead console, yes, as long as the color matches your trim. For the center console, there were minor changes to button layout and finishes between the early CBA (2009-2011) and later DBA (2012+) models. While they may physically fit, the electronics and appearance might not be a perfect match. It is always best to use a part from the correct year range (2012-2016).
I heard GT-R dashboards melt. Is this related to the console?
This is a separate issue. A class-action lawsuit was filed regarding some Nissan dashboards, including the GT-R, becoming sticky or 'melting' in high heat and sun, which created a reflective glare on the windshield. This affects the main upper dashboard pad, not the harder plastic of the center or overhead console panels. If you are experiencing this, the solution is to replace the entire upper dashboard assembly.
Helpful Videos
Technical Specifications
OEM Part Numbers: 26430-JF00A 26430-JF01A 26430-KB51B 26430KB51A 68961-JF00A 96910KB60B 96941KB51A 26431-JF00A 26432-JF00A
Key variants include Light Grey (for Premium/Pure trims) and Dark Grey/Black (for Black Edition/NISMO trims).
