2015-2026 Equinox & Terrain Door Mirror: A Guide to Generations & Options

A Critical Note on Vehicle Generations

Before purchasing a replacement door mirror for your Chevrolet Equinox or GMC Terrain, it's essential to identify your vehicle's generation. The initial year range of 2015-2026 covers two distinct platforms, and the parts are not interchangeable between them.

• Second Generation: 2015, 2016, and 2017 model years.
• Third Generation: 2018 model year and newer.

This guide is broken down by generation. Ensure you are reading the correct section for your vehicle's model year to guarantee compatibility.

2015-2017 Chevrolet Equinox & GMC Terrain Door Mirrors

The second-generation Equinox and Terrain share the same door mirror assemblies, making them interchangeable between the two models, provided the options match. Styling is the main differentiator between the two vehicles, but the underlying mirror components are identical.

Symptoms of Failure

When a door mirror begins to fail, you may experience one or more of the following symptoms:

• Mirror Glass Won't Adjust: The most common failure. The internal electric motor may have burned out, or the control switch on the door is faulty. If neither mirror adjusts, the switch is the most likely culprit.
• Heated Mirror Ineffective: The heating element embedded in the glass fails, preventing it from clearing frost or fog. This is often an issue with the element itself, requiring glass or full assembly replacement.
• Loose or Vibrating Mirror: The entire housing may become loose from an impact, or the glass itself may vibrate excessively while driving. This can be due to a worn-out internal mechanism or a damaged mounting point.
• Features Not Working: Functions like the blind spot indicator or integrated turn signal may stop working due to internal wiring faults or failed LED components.

Buying a Used 2015-2017 Mirror: What to Check

Purchasing a used OEM mirror is a cost-effective way to get a quality part. However, careful verification is key. Aftermarket mirrors, while cheaper, can have issues with fitment, connector compatibility, and the quality of the glass and motors.

1. Verify Your Options: This is the most critical step. A mirror from a base model will not work correctly on a fully-loaded vehicle. Check your vehicle for these features and ensure the replacement part has the exact same ones:
   • Heated Glass: Essential for cold climates.
   • Memory Function: Usually paired with power seats.
   • Blind Spot Alert: An indicator light on the mirror glass.
   • Turn Signal Indicator: A light on the mirror housing or glass.
   • Finish: Basic textured black, chrome, or a paint-to-match cap.
2. Inspect the Connector: Ask the seller for a clear photo of the electrical connector. Count the pins and compare the plug shape to your original mirror. Different features require different numbers of pins. A mismatch means some functions won't work.
3. Check for Physical Damage: Examine the housing for cracks or deep scuffs. Check the mirror glass for scratches or discoloration. Gently press on the glass to ensure it isn't loose in its housing.

2018-2026 Chevrolet Equinox & GMC Terrain Door Mirrors

Starting in 2018, the Equinox and Terrain moved to a new platform. While they remain sister vehicles with many shared components, the door mirrors are specific to this generation and are not compatible with earlier models. The core functions and failure symptoms are similar to the previous generation, but the technology within them can be more advanced.

Known Issues and Recalls

While there are no widespread recalls specifically for the door mirrors on these models, some issues have been noted:

• Fuse Location: For the 2018+ Terrain, the power mirrors fuse (F19, 7.5A) is in the interior fuse box under the steering wheel. 🎬 See this video to locate the power mirror fuse. The heated mirror fuse (F30, 7.5A) is in the under-hood fuse box. The Side Blind Zone Alert fuse (F7, 7.5A) is in the rear luggage compartment fuse box.
• Distorted Glass (Equinox EV): A preliminary information bulletin (PIT6380) was issued for the 2024-2025 Equinox EV, noting that accessory blackout mirror caps could cause the glass to be re-installed improperly, leading to a distorted view.
• General Recalls: While no mirror-specific recalls exist, GM has issued recalls for other issues on these vehicles, such as for window glass that may not be properly tempered on some 2018 Equinox models (GM recall 18136). Always check your VIN on the NHTSA website for any open recalls.

Buying a Used 2018+ Mirror: What to Check

The process is similar to the earlier generation, but with added complexity due to newer technology.

1. Confirm All Features: In addition to heat, memory, and blind spot monitoring, some higher trims may include a camera for the 360-degree surround-view system. A mirror with a camera is not interchangeable with one without. You must match this feature exactly.
2. Connector and Wiring: The electrical connectors are even more critical on this generation. A mismatch can lead to error codes and disabled safety systems. Verify the connector shape and pin count before purchase.
3. Physical and Functional Inspection: Check for damage to the housing, glass, and any camera lenses. If possible, confirm that power-folding functions work, as the motors can fail.

Cost to Replace a Door Mirror (All Generations)

Replacement Overview & Difficulty

• Difficulty Rating: 2/5 (DIY Feasible)
• Estimated Time: 1 hour

Replacing the door mirror on both generations of the Equinox and Terrain is a straightforward process for a DIYer with basic tools. The general steps are similar for both generations:

1. Remove Interior Trim: Carefully pry off a small triangular trim piece on the inside of the door where the mirror mounts.
2. Remove Door Panel: To access the wiring harness, you must remove the interior door panel. This involves removing a few screws (typically 7mm, 8mm, or 10mm) located behind small covers in the door pull and handle area, and then carefully prying the panel off to release its clips.
3. Disconnect Wiring: Unplug the mirror's electrical connector from the door module.
4. Unbolt the Mirror: Remove the three 10mm nuts that secure the mirror assembly to the door. Be sure to hold the mirror from the outside as you remove the last nut to prevent it from falling.
5. Installation: Installation is the reverse of removal. Feed the new mirror's wiring through the door, tighten the nuts, reconnect the harness, and test all functions before reinstalling the door panel.
