2018-2020 Ford F-150 Timing Cover: Leaks, Rattles, and Engine-Specific Issues

Symptoms of a Failing Timing Cover

The most common sign of a problem is a leak, but noises from the front of the engine are also a critical warning sign, often pointing to issues with the components behind the cover.

Oil or Coolant Leaks

An oil leak is the most frequent symptom of a timing cover issue. This is usually caused by a failed gasket or a bad front crankshaft seal. You may notice:

• Visible Drips: Puddles of oil on the ground under the front of the engine.
• Oil Stains: Oily residue on the front of the engine block, often collecting dirt and grime.
• Low Oil Level: You may find yourself needing to top off the engine oil between changes, or the low oil pressure warning light might illuminate.

Some F-150 engines have coolant passages running through the timing cover for the water pump. A failed gasket in this area can cause a coolant leak, which is often more serious than a small oil leak.

Engine Noises (Rattles, Chirps, Ticking)

While the cover itself rarely makes noise unless it has come loose, sounds from this area are a major red flag for the timing components it protects. These repairs all require removing the timing cover.

• Cold Start Rattle (3.5L EcoBoost): A loud ticking, tapping, or rattling noise for 2-5 seconds after a cold start is a classic symptom of failing VCT phasers. This is documented in Ford's Technical Service Bulletin (TSB) 23-2143.
🎬 Watch: Hear the 3.5L EcoBoost cold start rattle and VCT symptoms.
• Warm Idle Chirp (5.0L V8): A rhythmic, bird-like chirp at warm idle can be caused by a vibrating timing chain tensioner. This is addressed in TSB 19-2140 for trucks built before April 30, 2019.
• Deceleration Rattle (5.0L V8): Some 2018 5.0L engines may exhibit a rattle when the engine decelerates. TSB 18-2354 was an early attempt to fix this with a software update, but the noise often points to VCT solenoid issues.

Known Issues for 2018-2020 F-150 Engines

Failures are often specific to the engine in your truck. It is critical to identify your engine before diagnosing the problem.

3.5L EcoBoost V6

This engine is well-known for issues with its Variable Camshaft Timing (VCT) system. The primary symptom is a loud rattle on cold starts. While Ford has issued multiple customer satisfaction programs (like 21N03) and TSBs over the years, the root cause is often worn VCT phasers. The repair involves replacing all four phasers, a job that requires full removal of the timing cover and has a book time of nearly 10 hours. Additionally, the driver's side valve cover on 2017-2018 models is known to crack and leak oil, which can sometimes be mistaken for a timing cover leak.

5.0L V8 "Coyote"

The 5.0L V8 is generally robust but has specific, well-documented noise issues. TSB 19-2140 addresses a high-pitched chirp at warm idle caused by the primary timing chain tensioners. TSB 18-2354 addresses a rattle during deceleration. 🎬 See how to fix the 5.0L Coyote deceleration rattle noise. Both fixes require accessing components behind the timing cover. On earlier 5.0L engines, a common failure was the idler pulley seizing and breaking its mounting boss off the timing cover, creating a hole. While the cover design was updated to strengthen this area, it's a critical point to inspect on any used cover.

2.7L EcoBoost V6

The 2.7L V6 appears to be less susceptible to the specific, widespread timing component issues seen in the 3.5L and 5.0L engines. Most reported problems relate to standard oil leaks from the timing cover gasket or front crankshaft seal due to age and mileage. The repair is still just as labor-intensive, as the cover must be removed to replace the gaskets.

Buying a Used Engine Timing Cover

A recycled OEM timing cover is an excellent alternative to an expensive new part, especially since most failures are due to gaskets or the components behind the cover, not the cover itself. Here’s what to inspect before buying:

• Check for Cracks: Meticulously inspect the entire cover for hairline cracks, especially around bolt holes and any mounting bosses for pulleys or accessories. A cracked cover is useless.
• Inspect Mating Surfaces: Run your finger and a straight edge along all gasket surfaces where the cover meets the engine block and cylinder heads. Look for deep scratches, corrosion, or pitting that could prevent a good seal.
• Verify Part Number and Engine: The timing covers for the 2.7L, 3.5L, and 5.0L are completely different and not interchangeable. Match the part number from the used cover to your original, or confirm it came from an identical engine.
• Look at Pulley Mounts: For 5.0L covers, pay special attention to the idler pulley mounting boss. Ensure it is intact and shows no signs of stress fractures.
• Condition vs. Mileage: The physical condition of the cover is more important than the mileage of the donor vehicle. A clean, corrosion-free cover from a 100,000-mile vehicle is better than a damaged one from a 30,000-mile wreck.

Cost to Replace an F-150 Timing Cover

Replacing the timing cover is a labor-intensive job, which makes up the majority of the cost. The TSBs for related jobs list labor times between 8.5 and 9.8 hours. Expect a professional shop to charge for 9-12 hours of labor.

Note: Costs are estimates and will vary by location and shop. This does not include the cost of replacing timing chains, phasers, or tensioners, which is often done at the same time.
