2021-2025 Model S & Model X Fender Trim: Guide to Side Cameras, Paint Matching & Replacement

Symptoms of a Failing Exterior Trim Panel or Side Camera

Because this trim panel is directly integrated with the side camera, problems can be either physical or electronic. Here are the most common signs of failure:

• Physical Damage: The most obvious symptom is visible damage like cracks, deep scratches, or scuffs from a collision or impact. The panel may also become loose or detached from the fender.
• Camera Malfunction or Blockage Warnings: You may see an alert on your touchscreen that a camera is blocked, unavailable, or has limited function. This can disable Autopilot and other driver-assistance features. The on-screen display for the blind spot may appear black or distorted.
• Condensation Inside the Camera Housing: Moisture can get inside the camera enclosure, causing a foggy or blurry image, especially in cold or wet weather. Tesla has stated that the cameras are not hermetically sealed by design, and recommends preconditioning the cabin to help dry out condensation. However, persistent moisture can lead to permanent camera failure.
• Wind Noise: A trim panel that is not properly seated or has broken clips can create a whistling or rushing sound at higher speeds.
• Poor Paint or Finish: The clear coat may begin to peel, or the paint may fade or discolor, creating a mismatch with the rest of the vehicle's body.

Known Issues, TSBs, and Recalls

While there are no major recalls specifically for the 2021-2025 Model S and Model X fender trim panel itself, there are related issues and service actions worth noting:

• Camera Condensation: As mentioned, condensation inside the side repeater camera housing is a widely reported issue among owners. Tesla service has often described this as normal behavior, advising owners to use the climate control to dry the enclosures. If the issue persists and impacts camera function, a camera replacement may be necessary.
🎬 Watch: How replacing a camera can fix Autopilot system errors.
• Faulty Autopilot Cameras (Internal Service Bulletin): In late 2021, reports emerged that Tesla issued an internal service bulletin to replace faulty Autopilot cameras in the front fenders of some Model 3, S, and X vehicles due to defective printed circuit boards. This was not an official NHTSA recall but was handled by service centers, often free of charge for affected vehicles. Symptoms included Autopilot being limited and a blank box appearing on the blind spot display.
• Side Repeater Glare: After a 2021 software update introduced the blind spot camera feature, some owners experienced significant glare from the side repeater's turn signal light, making the camera feed difficult to see at night. Tesla initially addressed this with a tape fix, but later began replacing some cameras for free to resolve the issue.

Buying a Used Exterior Trim Panel: What to Inspect

Purchasing a used OEM trim panel is an excellent way to save money, especially if you can find one in the correct color. However, careful inspection is critical.

Why Used OEM is Often Better

Original Equipment Manufacturer (OEM) parts are made by Tesla and are guaranteed to fit perfectly. High-quality aftermarket panels can be a good alternative and may be more readily available, but quality can vary. Cheaper aftermarket parts may have issues with fitment, material quality, and durability, and may not be crash-tested. For a part that houses a critical safety camera, sticking with a used OEM part is generally the safest bet.

Inspection Checklist:

1. Check All Mounting Tabs: This is the most important check. Carefully inspect the back of the panel. There are numerous plastic clips and tabs that secure it to the fender. If even one is broken, the panel may not sit flush and could cause wind noise or eventually come loose.
2. Inspect the Camera and Lens: Many used panels are sold with the camera still installed. Check the camera lens for deep scratches, hazing, or any signs of internal moisture damage. If the camera is included, it adds significant value.
3. Verify Paint and Clear Coat Condition: Look at the panel under bright, direct light. Check for deep scratches, rock chips, or peeling clear coat. Minor scuffs can often be polished out, but major defects will require a repaint.
4. Look for Signs of Previous Repair: Check for any signs of body filler (Bondo) or repainting. Look for uneven texture, paint overspray on the back, or a color that doesn't quite match from edge to edge. A small magnet can help detect filler, as it won't stick as strongly as it does to the metal fender.

Paint Code and Color Matching

Finding a used part that perfectly matches your car's paint is ideal, as it saves you hundreds of dollars in refinishing costs.

How to Find Your Tesla's Paint Code

The paint code on all Tesla models, including the 2021-2025 Model S and Model X, is located on the Vehicle Identification Number (VIN) tag in the driver's side door jamb. 🎬 See this quick guide on locating your Tesla paint code. The paint code is typically a four-character code, often starting with a 'P', such as 'PPMR' for Red Multicoat or 'PBCW' for Catalina White.

Replacement Procedure Overview

Replacing the fender trim panel is a feasible DIY project for those with patience and the right tools. The process generally involves carefully prying the old panel off, disconnecting the camera, and installing the new one.

1. Gather Tools: You will need plastic trim removal tools to avoid scratching the paint, and possibly a Torx T8 bit to remove the camera from the housing if you are transferring it.
2. Power Off the Vehicle: For safety, power off the car through the touchscreen menu before disconnecting any electronics.
3. Remove the Old Panel: Open the front door for better access. Carefully use a plastic pry tool to release the clips holding the panel to the fender. There are approximately 11 clips and 3 datums (alignment posts). Be gentle, as the camera harness is very short.
4. Disconnect and Transfer the Camera: Once the panel is loose, disconnect the camera's electrical connector. If your replacement panel does not include a camera, you will need to remove the two T8 Torx screws holding the camera in the old housing and transfer it to the new one.
5. Install the New Panel: Connect the camera harness, align the new panel's clips and datums with the holes in the fender, and press firmly and evenly to snap it into place.
6. Camera Calibration: After replacing a camera or disconnecting it, a calibration may be required. The vehicle may prompt you to clear the calibration via the service menu. The car will then self-calibrate as you drive, which can take up to 100 miles. During this time, Autopilot features may be unavailable.

Cost Breakdown

The cost to repair or replace this part can vary significantly based on whether you do it yourself, the condition of the part, and paint requirements.
