2022-2025 Lucid Air Fender Liner: Diagnosing Noises and Verifying Fitment

Symptoms of a Failing Fender Liner

A damaged fender liner usually makes its presence known through distinct sounds and visual cues. Because the Lucid Air is exceptionally quiet, these noises can be more noticeable than in a traditional gasoline-powered car.

• Scraping or Rubbing Noises: The most common symptom is a scraping, rubbing, or flapping sound coming from a wheel well. This noise is often most prominent when turning, accelerating, or driving over bumps, as the vehicle's body moves and the tire makes contact with the loose liner.
• Visible Damage: A quick visual inspection may reveal the problem. Look for a liner that is hanging down, cracked, torn, or has holes in it. In some cases, it may be dragging on the ground.
• Increased Road Noise: Since the liner helps dampen sound, a missing or severely damaged one can lead to a noticeable increase in road and tire noise inside the cabin.
• Debris in Engine Bay or Undercarriage: If you notice an unusual accumulation of mud, water, or dirt in the engine compartment or on underbody components, it could be a sign that a fender liner is compromised and no longer providing protection.

Known Issues, Recalls, and Service Bulletins

As of early 2026, there are no specific recalls or Technical Service Bulletins (TSBs) from Lucid Motors or the NHTSA that directly address the fender liners on the 2022-2025 Lucid Air.

However, owners should be aware of a few related items:

• Build Quality Checks: Some early owners have reported minor fit and finish issues on new vehicles, including fender liner trim that was not perfectly seated from the factory. It is always wise to inspect the liners to ensure they are secure.
• Suspension Recall (2022 Models): Lucid issued a recall (NHTSA ID: 22V090) for some 2022 Air models due to a front strut damper snap ring that may have been installed incorrectly. This could cause a sudden loss of ground clearance. A drop in the suspension could force the tire into the fender liner, causing significant damage.
• Misdiagnosed Noises: Some owners on forums have reported loud metallic rattling from the front end, suspecting a major failure. In several cases, this was traced to a loose bolt on the anti-roll bar (sway bar) link, which is a known minor issue. Before assuming a noise is from a fender liner, it's worth checking for this possibility.
🎬 See how to isolate wheel noises from other suspension components.

Buying a Used 2022-2025 Lucid Air Fender Liner

Since new aftermarket fender liners for the Lucid Air are generally not available, a quality used OEM part is an excellent, cost-effective option. Because these vehicles are relatively new, a used liner is likely to be in very good condition. When inspecting a used part, pay close attention to the following:

• Check for Cracks and Tears: Carefully inspect the entire surface, especially around the edges and curves, for any cracks, splits, or holes. Minor scuffs are cosmetic, but any crack will compromise the part's integrity.
• Verify All Mounting Points: This is the most critical inspection point. Check every hole where a screw or plastic retainer clip would pass through. Ensure the plastic is not cracked or broken off at these points. A liner with damaged mounting holes will not install securely and will eventually come loose.
• Material Condition: The liner should still be flexible. If the plastic feels unusually brittle or stiff, it may have been exposed to extreme heat or chemicals. Avoid parts that show any signs of melting or warping.
• Confirm the Part Number: The surest way to guarantee fitment is to match the part number on the replacement liner to your old one. If you can't read your old part number, provide your vehicle's VIN to the seller to confirm compatibility.

Cost of Replacement

Replacing a Lucid Air fender liner is an affordable repair, especially when using a recycled OEM part.

OEM Part Numbers

This list contains known OEM part numbers for the 2022-2025 Lucid Air. The 'L' in a part number typically indicates the Left (Driver's) side, and 'R' indicates the Right (Passenger's) side. Always confirm the exact part number for your vehicle's specific location (front/rear) and side.

• P11-E720L0-02 (Front Left)
• P11-E720R0-02 (Front Right)
• P11-1011510-00-A (Rear)
• P11-E725R0 / P11E725R0 (Rear Right)
• P11E725L0 (Rear Left)
• P11-E725R0-03 (Rear Right)
• P11-E725R0-05 / P11E725R005 (Rear Right)

Step-by-Step Replacement Overview

Replacing a fender liner is a straightforward job that most DIYers can complete in under an hour.

1. Safety First: Park on a level surface and engage the parking brake.
2. Lift the Vehicle & Remove Wheel: For the best access, loosen the lug nuts on the appropriate wheel, then use a jack to lift that corner of the vehicle and secure it with a jack stand. Remove the wheel.
3. Remove Fasteners: Locate and remove all the plastic retainer clips and screws holding the old liner in place. A trim removal tool or a flathead screwdriver is useful for prying out the clips. Be aware that old clips can be brittle and may break during removal; it's a good idea to have new ones on hand.
🎬 Check out this video for a look at Lucid's underbody fasteners.
4. Remove the Old Liner: Once all fasteners are out, carefully bend and maneuver the old liner out of the wheel well.
5. Install the New Liner: Position the new liner inside the wheel well, ensuring it lines up with all the mounting holes on the fender and bumper.
6. Secure the New Liner: Insert and secure all the screws and retainer clips, starting from one end and working your way around. Ensure the liner is tucked properly behind the fender lip and any underbody panels.
7. Reinstall Wheel: Put the wheel back on, hand-tighten the lug nuts, lower the vehicle, and then torque the lug nuts to the manufacturer's specification.

Frequently Asked Questions (FAQ)
