2020-2025 Hyundai Palisade Key Fob: Smart Park vs. Standard & Programming Guide

Key Variants: The Most Important Difference

The single most important factor when replacing a 2020-2025 Hyundai Palisade key fob is identifying which version your vehicle requires. There are two primary types, and they are not interchangeable. Installing the wrong one will result in a key that cannot be programmed to your vehicle.

1. Standard 5-Button Smart Key

This is the most common key fob for Palisade models. It features five buttons: Lock, Unlock, Remote Start, Power Liftgate, and Panic. This key is for vehicles equipped with a standard push-to-start ignition and power liftgate but without the advanced parking feature.

• Part Numbers May Include: 95440-S8060, 95440-S8010
• FCC ID May Include: TQ8-FOB-4F29, TQ8-FOB-4F33

2. 7-Button Smart Key with Remote Smart Parking Assist (RSPA)

This key is for Palisade models equipped with the Remote Smart Parking Assist (RSPA) feature. In addition to the standard five buttons, it has two extra buttons for moving the vehicle forward and backward remotely. If your original 🎬 Watch: See the 7-button remote and parking assist in action. key does not have these two extra buttons, this key will not work with your vehicle.

• Part Numbers May Include: 95440-S8600, 95440-S8590
• FCC ID May Include: TQ8-FOB-4F28

Symptoms of a Failing Key Fob

Before assuming the key fob has failed, always perform the simplest fix first: replace the internal battery. Most issues are caused by a weak or dead CR2032 battery. If a new 🎬 See this walkthrough on how to replace your fob battery. battery doesn't solve the problem, you may be experiencing a true fob failure.

• "Key Not Detected" Message: The most common symptom. The dashboard displays a warning that the key is not inside the vehicle, even when it is. This may prevent the car from starting.
• Reduced Operating Range: You have to be much closer to the vehicle for the lock, unlock, or remote start functions to work.
• Intermittent or No Response: The buttons only work sporadically or have stopped working altogether. This can be due to worn-out internal contacts or a complete failure of the transmitter's circuit board.
• Inability to Start the Vehicle: Even when holding the fob against the start button (the emergency start procedure), the car does not recognize the key and will not start.

Known Issues, TSBs, and Recalls

As of early 2026, there are no widespread recalls specifically for the keyless entry transmitter on the 2020-2025 Hyundai Palisade. However, some related issues and service bulletins exist:

• Anti-Theft Software Updates: Hyundai has issued several Technical Service Bulletins (TSBs) and campaigns for anti-theft software logic improvements, though these primarily target models without push-button start and immobilizers, which does not include the Palisade.
• General Recalls: The 2020-2025 Palisade has been subject to other recalls, such as for third-row side curtain airbags (NHTSA Recall 26V034) and seat belt buckle assemblies. These are not related to the key fob but are important for owners to be aware of.
• "Key Not Detected" Issues: While not a formal recall, owners have reported issues with the "Key Not Detected" message, which can sometimes be related to vehicle software, not just the fob battery. In some cases, a dealer visit for a Body Control Module (BCM) software update may be necessary.

Buying a Used Keyless Entry Transmitter

Purchasing a used OEM key fob can be a cost-effective alternative to a new one from the dealership, but careful verification is essential.

• Verify Part Numbers and FCC ID: This is the most critical step. Match the part number and FCC ID from your original remote to the used one you plan to buy. The FCC ID is usually printed on the back of the fob case.
• Inspect for Physical Damage: Check for cracks in the casing, which could indicate drop damage or water intrusion. Ensure the buttons are not excessively worn and still have a tactile click.
• Beware of "Locked" Remotes: Once a smart key is programmed to a vehicle, it becomes "locked" to that vehicle's VIN. Some dealerships and even some locksmiths may have difficulty reprogramming a previously used key. Always confirm with your chosen locksmith or dealer that they are willing and able to program a used key that you provide.
• Why Used OEM is a Good Choice: Used original equipment (OEM) fobs are manufactured to Hyundai's quality standards. They often have more reliable radio transmitters and more durable casings than cheap aftermarket clones, which can have a shorter range and lifespan.

Programming and Installation

1. Who Can Program It: You must use either a Hyundai dealership or a qualified automotive locksmith who has the proper computer equipment.
2. What is Required: You must have the vehicle present for programming. Crucially, you must also bring ALL existing and new keys for the vehicle to the appointment. During the programming process, any keys not present will be de-registered from the vehicle and will no longer work.
3. Losing All Keys: If you have lost all your keys, the process is more complex and expensive. A locksmith or dealer will need to access the vehicle's security system to generate a new key from scratch.

Cost Comparison

The cost to replace a Palisade key fob can vary significantly based on the source of the part and the labor for programming.

Frequently Asked Questions (FAQ)
