C0569 on 2010-2014 GMC Terrain: 'Service StabiliTrak' Causes and Fixes

What's Unique About the 2010-2014 Gmc TERRAIN

The first-generation GMC Terrain and its Chevy Equinox sibling have a tightly integrated electronic power steering and StabiliTrak stability control system. Unlike older vehicles, replacing a major component like the steering gear is not just a mechanical job. The new part must be electronically introduced and calibrated to the vehicle's main computer systems. The Power Steering Control Module (PSCM) learns the steering angle from the EBCM over the vehicle's network. Code C0569 is the system's way of flagging that this critical electronic 'handshake' has failed, was never performed, or the wrong part was installed.

Diagnostic Flowchart

Tap your situation to follow the diagnostic path that matches what you're seeing on this vehicle.

Symptoms You May Notice

• "Service StabiliTrak" message on the driver information center
• "Service Steering" message may appear
• StabiliTrak/Traction Control warning light is illuminated
• ABS warning light may be illuminated
• Traction control and stability control are disabled

Most Likely Causes

1. Improper Setup After Steering Gear Replacement 🔴 High Probability As documented in GM Technical Service Bulletin #PIT5063D, replacing the steering gear assembly without performing the necessary electronic setup procedure will cause this code to set. The Power Steering Control Module (PSCM) in the new gear must be programmed via GM's Service Programming System (SPS) and then have its end-stops and sensor data learned. Failure to do so results in a configuration mismatch with the EBCM.
   How to confirm: Confirm if the code appeared immediately after the steering rack or another major steering component was replaced. A professional scan tool will show a configuration or calibration status error in the EBCM or PSCM.
   Typical fix: Perform the 'Power Steering Control Module Setup' and 'Steering Angle Sensor Calibration' procedures using a GM-compatible scan tool with access to TIS2WEB. In some cases where too much time has passed since the un-programmed part was installed, the steering gear may need to be replaced again to accept programming.
   Est. part cost: $0
2. Faulty or Uncalibrated Steering Angle Sensor (SAS) 🟡 Medium Probability → Shop Steering Angle Sensor The EBCM relies on the SAS to know the driver's intent. If the sensor's signal is missing or irrational (often flagged by code C0710), the EBCM cannot configure itself and will set C0569. This sensor provides the steering wheel position data that the PSCM and EBCM both rely on.
   How to confirm: Scan for other codes, specifically C0710. TSB PIT5063D 🎬 See this easy fix for the C0710 steering angle code. explicitly states C0710 must be diagnosed and fixed first. Use a scan tool to view live data from the steering angle sensor while turning the wheel. The reading should be smooth and logical.
   Typical fix: First, attempt to recalibrate the sensor using a scan tool. If calibration fails or the sensor data is erratic, inspect wiring (including the known problematic X411 connector) before replacing the steering angle sensor and performing the calibration.
   Est. part cost: $60-$150
3. Faulty Electronic Brake Control Module (EBCM) ⚪ Low Probability → Shop ABS Control Module While less common, the module itself can fail internally, preventing it from storing calibration data or communicating properly with the PSCM.
   How to confirm: This is a process of elimination. If all related sensors, wiring, and the PSCM are confirmed good and the module repeatedly fails to accept or retain calibration, the EBCM is likely faulty.
   Typical fix: Replace the Electronic Brake Control Module. 🎬 Watch: How to remove and install the EBCM module. The new module will require programming and configuration with a professional scan tool.
   Est. part cost: $300-$700

Rare But Worth Checking

• Internal Transfer Case Failure (AWD Models): → Shop Transfer Case Motor

Diagnosis Steps

1. Connect a professional-grade scan tool (e.g., GM MDI, Tech 2, Autel) capable of reading chassis codes and performing bidirectional controls.
2. Scan all vehicle modules for any Diagnostic Trouble Codes (DTCs).
3. If DTC C0710 is present, diagnose and resolve it first, as per GM TSB PIT5063D. This may involve checking the X411 connector for corrosion or replacing the SAS.
4. If the code appeared after a recent repair (especially to the steering system), proceed directly to the module setup/calibration function on the scan tool.
5. Access the special functions for both the Electronic Brake Control Module (EBCM) and the Power Steering Control Module (PSCM).
6. In the PSCM menu, perform the 'Power Steering Control Module Setup' or similar SPS programming function first, if a new steering gear was installed.
7. In the EBCM menu, perform the 'Steering Angle Sensor Calibration' procedure. Follow the on-screen prompts precisely, which typically involve centering the steering wheel and turning lock-to-lock.
8. Clear all DTCs and perform a test drive to see if the code returns.
9. If calibration fails or the code returns immediately, use the scan tool to monitor live data from the steering angle sensor. Check for smooth, continuous data as you turn the steering wheel lock-to-lock.
10. If sensor data is erratic or absent, inspect the wiring and connectors between the sensor and the EBCM before condemning the sensor.
11. If all wiring and sensor operations appear correct but calibration fails repeatedly, the EBCM may be faulty.

Parts You'll Likely Need

• Steering Angle Sensor (OEM #13589991) — This sensor can fail or lose its calibration, which is a direct cause for the EBCM to set a C0569 configuration error. This part number supersedes several previous numbers like 13513905 and 20959922. Always verify with VIN.
  Trusted brands: ACDelco, Dorman
  OEM price range: $100-$180
  Aftermarket price range: $60-$120
• Electronic Brake Control Module (EBCM) (OEM #22754644, 84342062) — In rare cases where calibration fails and all inputs are verified as good, the module itself is the point of failure. Part numbers are highly dependent on specific options (like collision avoidance) and VIN. For example, 22754644 is listed for 2012 models, while 84342062 is for later models with collision avoidance.
  Trusted brands: ACDelco
  OEM price range: $450-$700
  Aftermarket price range: $300-$550

Related Codes That Often Appear With This One

• C056E — This code indicates a VIN mismatch or 'Calibration Data Set Not Programmed' error, which is directly related to C0569. GM TSB #PIT5063D mentions them appearing together after a steering gear replacement.
• C0710 — This code points to a fault with the Steering Angle Sensor signal. TSB #PIT5063D explicitly states that if C0710 is present, it must be diagnosed and fixed *before* addressing the C0569, as it is likely the root cause.

Technical Service Bulletins (TSBs) & Recalls

• PIT5063D: Warns that a C0569 may set after a new steering

Platform-Specific Known Issues

• GM Technical Service Bulletin #PIT5063D directly addresses an issue where installing a new steering gear assembly can cause codes C0569 and C056E to set. This confirms that the issue is a known software/configuration problem on this platform.
• Owner experiences confirm that the primary fix is a software calibration. One user on Reddit noted that after a DIY rack and pinion replacement, a Firestone service center performed the alignment and sensor calibration for around $80.
• On AWD models, C0569 can be misleading. A technician on a professional forum described a 2008 Silverado where C0569 was caused by a broken internal shift rail in the transfer case, which prevented the TCCM from completing its learn procedure.

Mechanic-Grade Diagnostic Values

• Battery Voltage (Key On, Engine Off) — expected: >12.4V. Failure: Voltage below 12.4V can cause various module communication and configuration errors. Low voltage is a common cause for random electronic faults.
• Charging System Voltage (Engine Running) — expected: 13.7V - 14.7V. Failure: Voltage outside this range indicates an alternator or battery issue, which can lead to module malfunctions and set codes like C0569.

Hidden / Shadow Codes Worth Checking

• C0569 Sym 3A: This specific symptom byte indicates 'System Configuration Error - Invalid Data'. It is typically set by the EBCM when data from a related module (like the PSCM) is missing or incorrect, often after a component replacement without proper programming. (see via A professional GM-specific scan tool like a Tech 2 or GDS2 is required to view symptom bytes.)
• C056E Sym 42: This code for 'Calibration Data Set Not Programmed' often accompanies C0569. It specifically points to the Power Steering Control Module (PSCM) not having the correct software/calibration file loaded via the Service Programming System (SPS). (see via A professional GM-specific scan tool like a Tech 2 or GDS2.)
• C0569 Sym 4B: On some GM trucks, this symptom byte means 'Calibration Not Learned'. It is commonly associated with the Transfer Case Control Module (TCCM) failing its relearn procedure due to an internal mechanical or electrical fault. (see via A professional GM-specific scan tool.)

Scan Tool Commands That Help

• GM GDS2/Tech2 with SPS (Service Programming System): Electronic Power Steering - Prepare Control Module for Removal — This function must be used BEFORE removing the old steering gear. It copies critical data, like the worm gear wear counter, from the old module to be transferred to the new one.
• GM GDS2/Tech2 with SPS (Service Programming System): Electronic Power Steering - Programming — This is used to flash the new Power Steering Control Module (PSCM) on the replacement steering gear with the correct software and VIN for the vehicle.
• GM GDS2/Tech2 with SPS (Service Programming System): Electronic Power Steering - Setup — After programming, this function transfers the vehicle's specific data (including data saved with 'Prepare for Removal') to the new module. This is a critical step to resolve C0569.
• GM GDS2/Tech2: Steering Angle Sensor Centering / Software Endstop Learning — This is the final calibration step after programming and setup. It teaches the system the steering wheel's center position and the mechanical limits of the steering rack.
• GM GDS2/Tech2: TCCM Motor Relearn (AWD Models) — If C0569 is suspected to be from the transfer case, this command attempts to cycle the encoder motor to learn its position. A failure to complete this relearn points to a mechanical or electrical issue within the transfer case system.

Wiring & Ground Locations

• EBCM Fuses — In the underhood fuse block, located next to the brake fluid reservoir on the driver's side.. The EBCM requires power from multiple fuses. Specifically, check fuse #13 (40A, ABS Pump) and fuse #16 (20A, ABS Module). A loss of power on either circuit can cause the module to malfunction and set configuration codes.
• G305 — A major chassis ground point located on the frame rail under the driver's side door, to the rear of the B-pillar.. The EBCM is highly sensitive to its ground connection. Corrosion or looseness at this primary ground point can cause a voltage drop, leading to communication faults and codes like C0569.
• X411 Connector — Under the vehicle on the driver's side frame rail, located to the rear of the fuel tank.. This is a known trouble spot mentioned in GM TSBs. It's a large inline connector that carries data and power for various rear-body components. Corrosion here can disrupt communication on the vehicle's data bus, affecting the EBCM and other modules.
• Steering Angle Sensor (SAS) Connector — Located on the steering column, typically under the dash above the floorboards.. A loose or corroded connection at the sensor itself can cause an invalid signal, leading to code C0710, which in turn will cause C0569 to set because the EBCM cannot get a valid steering input.

Real Owner Repair Stories

• Certified Transmission / The Transletter (2008 Chevy Silverado 2500 HD (similar TCCM logic)) — No 4WD, 'Service 4x4' message, multiple codes stored in TCCM.
  ❌ Tried (didn't work) Replacing the transfer case motor (encoder)., Replacing the 4WD selector switch., Clearing codes (C0569 returned immediately)., Reprogramming the TCCM with the latest software.
  ✅ What actually fixed it The technician removed the encoder motor and found the input shaft to the transfer case was spinning freely. This indicated an internal mechanical failure (broken shift rail). Replacing the entire transfer case assembly and then performing the TCCM relearn procedure finally resolved the C0569 code.

OEM Part Supersession History

• 22754644 → Discontinued — This EBCM part number was used for 2012-2017 Equinox and Terrain models. It has since been discontinued by GM, meaning service replacements will likely be remanufactured units.
  Heads up: When replacing an EBCM, the new module must be programmed with the vehicle's specific VIN and RPO codes using a tool with access to GM's SPS. Failure to program will result in a C0569 code.

Model Year Variations Within This Range

• 2010-2014: GM issued Special Coverage Adjustment 14232A for steering that sticks or binds. For 2010-2012 models, the fix was to replace the steering gear. For 2013-2014 models, the fix was to reprogram the Power Steering Control Module (PSCM). While this program has expired, it shows a known difference in how steering issues were addressed within this generation. A 2013-2014 vehicle that never received this update might be more prone to software-related steering faults.
