P0711 on 2016 Fiat 500: Transmission Temperature Sensor Causes and Fixes

What's Unique About the 2016-2016 Fiat 500

For the 2016 Fiat 500 with the 6-speed automatic transmission, this code is very frequently a software issue rather than a hardware failure. Fiat has issued multiple Technical Service Bulletins (TSBs) acknowledging that the original TCM software can misinterpret sensor data, leading to a false P0711 code. Before any parts are replaced, the first diagnostic step should always be to check if a TCM software update is available and has been performed. This pattern of software-driven faults is also seen in its platform mates like the Fiat 500X, though they use a different (ZF 9-speed) transmission.

Diagnostic Flowchart

Tap your situation to follow the diagnostic path that matches what you're seeing on this vehicle.

Symptoms You May Notice

• Check Engine Light (Malfunction Indicator Lamp) is on.
• Harsh, erratic, or delayed gear shifts.
• Vehicle may enter "limp mode," getting stuck in a single gear.
• Transmission-related warning messages on the dashboard.
• Abnormal torque converter clutch operation.
• A burnt smell from the transmission if the condition causes actual overheating.

Most Likely Causes

1. Outdated Transmission Control Module (TCM) Software 🔴 High Probability → Shop Transmission Assembly Fiat has issued multiple TSBs (e.g., #21-024-15 REV-B, #21-044-15) for this exact issue, indicating a known logic problem in the original software that falsely triggers the code.
   How to confirm: A Fiat dealer or a qualified shop using a wiTECH scan tool 🎬 See how to use a VCI tool to program the TCM. can check the current software calibration ID against the latest version available from the manufacturer for your vehicle's VIN.
   Typical fix: Reprogramming (flashing) the TCM with the latest software version. The TSBs often recommend updating the Powertrain Control Module (PCM) 🎬 Watch: Step-by-step guide for updating your engine computer software. at the same time to ensure compatibility.
   Est. part cost: $0
2. Faulty Transmission Fluid Temperature (TFT) Sensor ⚪ Low Probability → Shop Transmission Assembly While the sensor can fail, it is far less common than the software issue on this platform. The sensor is typically integrated into the valve body's internal wiring harness, which can degrade over time but should only be suspected after software is ruled out.
   How to confirm: Use a scan tool to monitor live TFT sensor data. Compare the cold reading to the ambient and engine coolant temperatures; they should be similar. If the reading is stuck (e.g., -40°F), erratic, or doesn't rise as the car warms up, the sensor/harness is likely faulty.
   Typical fix: Replace the entire valve body wiring harness which contains the integrated sensor. This requires draining the fluid and removing the transmission oil pan.
   Est. part cost: $70-$150
3. Low or Degraded Transmission Fluid ⚪ Low Probability → Shop Transmission Assembly
   How to confirm: Check the transmission fluid level and condition according to the manufacturer's procedure. The fluid should be at the correct level and not appear dark, burnt, or contain debris.
   Typical fix: Perform a transmission fluid drain and fill using the correct specification fluid (e.g., Mopar ZF 8&9 Speed ATF was for the ZF trans, this car requires fluid meeting its own 6-speed spec).
   Est. part cost: $50-$150
4. Damaged Wiring or Connectors ⚪ Low Probability
   How to confirm: Visually inspect the main external transmission wiring harness and its connector for any signs of chafing, corrosion, or damage. A bad ground can also cause erratic sensor readings.
   Typical fix: Repair the damaged section of the wiring harness or clean/replace the corroded connector.
   Est. part cost: $10-$100

Rare But Worth Checking

• Faulty Transmission Control Module (TCM): → Shop Transmission Assembly This is a rare cause. A hardware failure of the TCM should only be considered after all software updates have been performed and wiring/sensor issues have been ruled out.

Diagnosis Steps

1. Check for Technical Service Bulletins (TSBs). For a 2016 Fiat 500, TSBs #21-024-15 REV-B and #21-044-15 are highly relevant and suggest a software update is the primary fix. A dealer can check for applicability to your VIN.
2. Scan for all stored DTCs to see if P0711 is accompanied by other codes like P1CC9, P1D98, or U0401, which reinforces the likelihood of a software issue.
3. Use a professional scan tool (like wiTECH) to check the current software version of the TCM and compare it to the latest available version from Fiat.
4. If software is outdated, perform the TCM (and likely PCM) reflash. This resolves the issue in the vast majority of cases.
5. If software is current, use the scan tool to monitor the live data from the Transmission Fluid Temperature sensor.
6. Observe the sensor reading with the engine cold (it should match ambient temperature) and during a test drive. The temperature should rise steadily and logically.
7. If the sensor data is illogical, inspect the external transmission wiring harness and connector for damage or corrosion.
8. Check the transmission fluid level and condition. Low or burnt fluid can cause overheating issues that might trigger a performance code.
9. If the sensor is still suspected, proceed with testing and potential replacement of the internal transmission harness that contains the sensor.

Parts You'll Likely Need

• Transmission Valve Body Wiring Harness — CRITICAL CORRECTION: The part number 68197332AA, sometimes associated with this code, is for the ZF 9-speed transmission in other Fiat-Chrysler vehicles and DOES NOT FIT the 6-speed automatic in the standard 2016 Fiat 500. If the sensor fails (which is rare), the correct harness for the 6-speed auto must be sourced by VIN. The software update is the primary fix.
  Trusted brands: Mopar
  OEM price range: $150-$250
  Aftermarket price range: $70-$150
• Automatic Transmission Fluid (OEM #Varies by specific 6-speed transmission requirements) — If the transmission pan is dropped for sensor/harness inspection, the fluid must be drained and refilled. Use only the fluid type specified for the 6-speed automatic transmission, not the ZF 8&9 Speed ATF.
  Trusted brands: Mopar, Idemitsu, Valvoline
  OEM price range: $20-$30 per quart
  Aftermarket price range: $10-$20 per quart

Related Codes That Often Appear With This One

• P1CC9 — This code for 'Unable to Engage Gear' is listed alongside P0711 in Fiat TSBs #21-024-15 REV-B and #21-044-15, indicating a common software-related root cause.
• P1D98 — This code for 'Incorrect Gear Ratio Clutch B or D' is also cited with P0711 in Fiat TSBs #21-024-15 REV-B and #21-044-15, pointing to a shared transmission control fault.
• U0401 — 'Implausible Data Received From The ECM-PCM' is mentioned in TSB #21-044-15, suggesting a communication breakdown between control modules that can occur with the P0711 fault.

Technical Service Bulletins (TSBs) & Recalls

• 21-024-15 REV-B: Links P0711 with P1CC9 and P1D98, pointing to a software update for MIL illumination.
• 21-044-15: Cites P0711 along with P1CC9, P1D98, and U0401 as codes that may be resolved with a software flash.
• 21-024-15 REVA: An earlier revision of the TSB also identifying P0711 as a key code related to a software issue.

Platform-Specific Known Issues

• Fiat has released multiple TSBs (21-024-15 REV-B, 21-044-15, 21-024-15 REVA) for the 2016 model year indicating that a Malfunction Indicator Lamp (MIL) with DTC P0711 can be resolved by reprogramming the TCM.
• The issue is so prevalent as a software fault that many dealer technicians will immediately check the vehicle's software calibration ID against the latest TSBs before performing any physical diagnosis.

Mechanic-Grade Diagnostic Values

• TFT Sensor Resistance vs. Temperature (General) — expected: Resistance is inversely proportional to temperature. Common values are ~2.5 kΩ at 20°C (68°F) and ~0.3 kΩ at 80°C (176°F).. Failure: An open circuit (infinite resistance), a short circuit (near-zero resistance), or a value that does not change as fluid warms up indicates a fault.
• TFT Sensor Voltage vs. Temperature (General) — expected: Voltage decreases as temperature increases. A typical reading is ~1.5V at 20°C (68°F), dropping to ~0.5V at 80°C (176°F).. Failure: Voltage stuck high (e.g., 5V reference) or low (0V), or does not decrease as the transmission warms.
• TCM 'Range/Performance' Logic Check — expected: The TCM expects the TFT sensor to report a temperature change of more than 2°C (4°F) after the vehicle has been driven at over 5 mph for 5 minutes.. Failure: If the temperature reading remains static after the warmup period, the P0711 code will be set.
• TFT Sensor Resistance Fault Thresholds — expected: Resistance should be between 79 Ω and 156 kΩ.. Failure: If resistance is less than 79 Ω (reads as >150°C) or more than 156 kΩ (reads as -40°C), the ECM/TCM will interpret this as a hard fault (P0712/P0713).

Scan Tool Commands That Help

• wiTECH or equivalent professional scan tool: TCM Self-Test / Bidirectional Control — To verify that the TCM is capable of communicating and running internal diagnostics. A failure to complete the test can point to an internal TCM hardware fault.
• wiTECH or equivalent professional scan tool: Reset TCM / Clear Adaptive Memory / Quick Learn — After replacing transmission components or performing a software update, this function should be used to clear the old learned shift strategies and force the TCM to relearn based on the new conditions.
• wiTECH or equivalent professional scan tool: Depressurize Hydraulic System — This is a mandatory first step before performing any physical repairs on the C635 DDCT transmission's hydraulic unit or clutches to prevent injury or damage.

Wiring & Ground Locations

• Main Engine/Transmission Earth Strap — Typically follows the largest black wire from the battery's negative terminal. It connects to the car's body/chassis just below the battery tray, and then continues down to a mounting point on the transmission case.. A corroded or loose main ground for the transmission can cause a floating ground, leading to unstable voltage signals from all transmission sensors, including the TFT sensor. This can trigger erratic readings and a P0711 code even if the sensor and its direct wiring are perfectly fine.

Real Owner Repair Stories

• Reddit user on r/AskMechanics (2015 GMC Yukon Denali) — Intermittent Check Engine Light with code P0711. No noticeable transmission performance issues. The light would turn on and off periodically over a month or two.
  ❌ Tried (didn't work) The user was planning to take the vehicle in for transmission diagnosis but had not yet performed any repairs specifically for the P0711 code.
  ✅ What actually fixed it The vehicle also had a known issue with a faulty engine coolant thermostat (stuck open), causing the engine fan to run excessively. After replacing the engine coolant thermostat and sensor, the P0711 code disappeared and did not return. The interconnected nature of the engine and transmission cooling systems meant the engine cooling fault was likely preventing the transmission from reaching its expected operating temperature in the timeframe monitored by the TCM, triggering the P0711 performance code.
