P0715 on 2010-2014 Audi S4: Input Speed Sensor 'A' Circuit Failure Causes and Fixes

What's Unique About the 2010-2014 Audi S4

The 2010-2014 Audi S4 (B8 and B8.5 generations) is equipped with the 7-speed DL501 (also known as 0B5) S-Tronic dual-clutch transmission. A widely documented issue with this specific gearbox is the failure of the internal printed circuit board (PCB) within the mechatronics unit, which houses the input speed sensors (G612, G632) and a gear position sensor (G676). Unlike a simple external sensor replacement, this fault requires removing the complex mechatronics unit from the transmission to replace the faulty sensor and circuit board assembly, which is sold as a 'repair kit'. This issue was common enough that it was part of a class-action lawsuit settlement for 2010-2012 models, which provided warranty extensions and reimbursement for some owners.

Diagnostic Flowchart

Tap your situation to follow the diagnostic path that matches what you're seeing on this vehicle.

Generation note: This range covers the B8 (2010-2012) and B8.5 (2013-2014) generations of the Audi S4. Both use the DL501 S-Tronic transmission, and the common mechatronics issue is prevalent across this entire year range and even in later models. However, there were transmission revisions during the B8.5 update which may have improved reliability for later models.

Symptoms You May Notice

• "Gearbox Malfunction: You can continue driving" message on the instrument cluster.
• Illuminated Check Engine Light or flashing PRNDS indicator.
• Vehicle enters limp-home mode, often stuck in a single gear (e.g., 1st or 2nd).
• Harsh, jerky, or delayed gear shifts, sometimes described as a "thud" or "clunk".
• Complete loss of reverse or forward gears.
• Erratic gear selection, such as only having odd or even gears available.
• Illuminated EPC (Electronic Power Control) light.

Most Likely Causes

1. Mechatronics Internal Sensor/Circuit Board Failure 🔴 High Probability The circuit board and integrated sensors inside the DL501 mechatronics unit are a known failure point, as documented in TSBs and countless owner forums. The sensors are integrated into a circuit board that can fail electronically due to thermal stress and contamination from clutch wear particles within the shared mechatronics fluid circuit.
   How to confirm: A diagnostic scan with an Audi-specific tool will show P0715, often accompanied by other speed sensor or gear selector codes like P171F, P2765, or P179F. TSB 2032211/2 requires an exact match of the DTC and its associated DFCC (Diagnostic Fault Code Counter) code for official diagnosis. The ultimate confirmation is testing the unit after removal or simply replacing it based on the strong evidence of the fault codes.
   Typical fix: Replace the mechatronics internal circuit board and sensors using an OEM repair kit. In some cases, a remanufactured or new mechatronics unit is installed. After installation, a fluid refill and basic settings adaptation procedure is mandatory.
   Est. part cost: $400-$800 for a repair kit, $2000-$4000 for a full mechatronics unit.
2. Contaminated or Low Transmission Fluid ⚪ Low Probability → Shop Transmission Assembly The DL501 has two separate oil circuits: one for the gearset (MTF) and one for the clutches and mechatronics (ATF/DSG fluid). While low fluid can cause shifting issues, it is unlikely to be the primary cause of a P0715 circuit code. More often, clutch wear debris contaminates the ATF circuit, contributing to the eventual electronic failure of the mechatronics board rather than causing the code directly.
   How to confirm: Check the transmission fluid level and condition. The fluid level check is temperature-dependent and must be done correctly. If the fluid is dark and full of debris, it indicates significant wear that has likely already damaged the sensitive electronics.
   Typical fix: Perform a full transmission fluid and filter change. However, if P0715 is present, this is unlikely to be a standalone fix and is usually done as part of the mechatronics repair.
   Est. part cost: $200-$400 for fluid and filters.
3. Damaged Wiring or Connectors ⚪ Low Probability This is much less common than internal failure. The main external transmission harness connector is robust, but damage is possible. A DIYer might damage the connector lock during removal if not careful.
   How to confirm: Visually inspect the main connector at the transmission case for corrosion or damage. Perform a continuity and resistance test on the wiring harness leading to the TCM.
   Typical fix: Repair the damaged wiring or replace the connector.
   Est. part cost: $50-$200

Rare But Worth Checking

• Failed Transmission Control Module (TCM): → Shop Transmission Assembly The TCM is the computer brain of the mechatronics unit. While the sensor circuit board is the most common failure point, the TCM itself can fail, causing this code. A repair kit will not fix a failed TCM; the entire mechatronics unit would need replacement or specialized repair. A full mechatronics unit replacement can cost between $1651 and $1706 for the part alone.

Diagnosis Steps

1. Perform a full diagnostic scan of the Transmission Control Module (TCM) with an Audi-specific tool like VCDS or ODIS to confirm P0715 and check for other related codes and their specific DFCC numbers.
2. Before draining fluid, loosen the fill plug to ensure it is not seized.
3. Check the transmission fluid (ATF/DSG side) level and condition. The level must be checked at a specific temperature (e.g., 35-45°C).
4. Inspect the main external wiring harness and the large circular connector at the transmission for any signs of damage, corrosion, or loose connections.
5. If external checks are clear, the fault is almost certainly internal to the mechatronics unit.
6. The vehicle must be safely lifted and the undertray removed. The transmission pan is then dropped to access the mechatronics unit.
7. The mechatronics unit is carefully unbolted and removed. It's critical to ensure the gear selectors are in the neutral position before reinstallation.
8. Once removed, the mechatronics unit can be disassembled on a clean bench to replace the internal circuit board/sensor module with a repair kit.
9. After reinstallation, the transmission must be refilled with the correct fluid, and a basic settings/adaptation procedure must be performed using a diagnostic tool. This may need to be run multiple times to complete successfully.

Parts You'll Likely Need

• Mechatronics Repair Kit (OEM #0B5398009F) — This is the most common failure point. The kit contains the two new circuit boards with integrated speed sensors needed to resolve the P0715 code. The part number has been superseded multiple times (from A, B, C, D, E, to F), with later versions presumably being more robust.
  Trusted brands: Audi Genuine, VEMO
  OEM price range: $500-$800
  Aftermarket price range: $450-$650
• S-Tronic Transmission Fluid (Dual Clutch Fluid) (OEM #G052529A2) — The transmission fluid must be drained to service the mechatronics unit and must be replaced with new, correct-specification fluid. Approximately 7 liters are needed for a drain and refill.
  Trusted brands: Audi Genuine, Pentosin FFL-2, Liqui Moly 8100
  OEM price range: $25-$35 per liter
  Aftermarket price range: $18-$25 per liter
• Transmission Pan Gasket and Filter Kit

Related Codes That Often Appear With This One

• P171F — Relates to Transmission Input Speed Sensor 2 ('B'). Its appearance with P0715 strongly suggests a failure of the common sensor module inside the mechatronics unit, as both sensors are on the same circuit board. TSB 2032211/2 lists this as a key related code.
• P2765 — Relates to Input/Turbine Speed Sensor 'B' Circuit. Like P171F, this points toward a comprehensive failure of the sensor package within the mechatronics unit. This is also cited in TSB 2032211.
• P179F — Relates to a 'Drive Position Sensor Malfunction'. This sensor is also part of the same internal mechatronics assembly, and this code frequently appears alongside the speed sensor faults, as noted in TSB 2032211.
• P0700 — This is a general Transmission Control System Malfunction code. It indicates that the TCM has stored a fault, such as P0715, and is telling the main Engine Control Module (ECM) that a transmission problem exists.

Technical Service Bulletins (TSBs) & Recalls

• A351619 2032211- (and its revisions, e.g., /5, /6): This is the primary TSB. It details two scenarios for the 'Gearbox Malfunction' light. Scenario 2 lists DTC P0715 along with P0716, P171F, P2765, and others as a group of codes that, when present, point directly to the failure of the internal sensor module and circuit board, requiring replacement with the repair kit.
• TSB 10054213-2278 (FCP Euro reference): This TSB number is referenced by parts suppliers as the document creating the repair kit solution for the DL501 mechatronic failure, citing many related fault codes.

Platform-Specific Known Issues

• The DL501 (0B5) S-Tronic transmission in the B8/B8.5 S4 is known for mechatronics failures, specifically the sensor module PCB. This is a well-documented issue in enthusiast communities and is addressed by Audi TSBs.
• A class-action lawsuit was settled for 2010-2012 Audi S4 and S5 models related to defective DSG transmissions causing shuddering, rough shifting, and limp mode, which are all symptoms of this mechatronics failure.

Mechanic-Grade Diagnostic Values

• Resistance of K1 Clutch Control Solenoid (N435) — expected: 15 Ohms. Failure: Significant deviation from 15 Ohms
• Resistance of K2 Clutch Control Solenoid (N439) — expected: 15 Ohms. Failure: Significant deviation from 15 Ohms
• Resistance of Main Pressure Control Solenoid (N472) — expected: 4.5 Ohms. Failure: Significant deviation from 4.5 Ohms
• Resistance of Clutch Cooling Oil Solenoid (N471) — expected: 4.5 Ohms. Failure: Significant deviation from 4.5 Ohms
• Resistance of Shift Fork Solenoids (N433, N434, N437, N438) — expected: 5 Ohms. Failure: Significant deviation from 5 Ohms

Scan Tool Commands That Help

• VCDS or ODIS: Erase counter for start and stop processes — This is the first step in the basic settings procedure after a mechatronics repair to clear old adaptation data. It must be done with the engine off.
• VCDS or ODIS: Clutch valve calibration — Performed with the engine running after repair to calibrate the new clutch valves.
• VCDS or ODIS: Distance sensor calibration — Performed with the engine running to calibrate the gear position/distance sensors. Clunking noises are normal during this process.
• VCDS or ODIS: Clutch engagement point adaptation — This procedure helps the TCM learn the 'kiss points' of the new clutches for smooth engagement. It may need to be followed by a specific test drive procedure to fully learn.

Wiring & Ground Locations

• J743 - DSG transmission Mechatronic Connector — The main external electrical connector on the driver's side of the transmission case. It is a large, 16-pin circular connector.. This is the primary connection point for all sensors and solenoids within the mechatronics unit to the vehicle's wiring harness. A poor connection or damage here can mimic internal faults.
• T16r - Pin 16 (Power) — Pin 16 on the 16-pin mechatronics connector (J743). It is a gray/yellow wire.. This pin supplies main battery power (Terminal 30) to the mechatronics unit. Loss of power here will cause a total loss of communication and multiple fault codes, including P0715.
• T16r - Pin 13 (Ground) — Pin 13 on the 16-pin mechatronics connector (J743). It is a brown wire.. This is the main ground connection for the mechatronics unit. A poor ground can cause erratic sensor readings and trigger circuit malfunction codes.

Real Owner Repair Stories

• AudiWorld Forums user (2010 Audi S4 with 35k miles) — Noticing symptoms of a dying Mechatronic unit, including a 'bang/jerk to stop' and harsh shifting from Drive to Reverse.
  ❌ Tried (didn't work) The user was exploring options and concerned about the high cost of a full mechatronics or transmission replacement.
  ✅ What actually fixed it The user referenced forum polls where replacing just the mechatronics unit or using a printed circuit repair kit were successful fixes for other owners, validating the approach of repairing the unit instead of replacing the entire transmission.
• Reddit user r/AudiS4 (2012 Audi S4 (B8) at 80k miles) — Violent jerking when shifting gears in slow, stop-and-go traffic. No warning lights were on initially.
  ❌ Tried (didn't work) Initial diagnosis from a local mechanic suspected mechatronics failure, which the dealer confirmed.
  ✅ What actually fixed it The dealer quoted nearly $5000 for the repair. After negotiation with Audi USA, the final cost was reduced to $3500. The thread confirms the high cost and commonality of the failure, with other users recommending the DIY-possible repair kits as a more affordable solution.

OEM Part Supersession History

• 0B5398009A / B / C / D / E → 0B5398009F — The multiple revisions suggest ongoing improvements to address the reliability issues of the internal circuit boards and sensors. Later revisions are considered more robust.
  Heads up: All previous versions (A-E) are superseded by 'F'. While older stock may be available, it is highly recommended to use the latest 'F' revision for the most durable repair.

Model Year Variations Within This Range

• 2013-2014 (B8.5): The B8.5 facelift models received mechanical updates to the drivetrain, including revised components in the DSG transmission that are considered less likely to fail than in early B8 models. The transmission revision was changed in 2013 and fully switched over by 2014. The B8.5 also features a different steering system (electromechanical vs. hydraulic) and a crown-gear center differential, though these do not directly relate to the P0715 fault.
