P0716 on 2015-2018 Acura TLX V6: Input Speed Sensor Causes and Fixes

What's Unique About the 2015-2018 Acura TLX

On the 2015-2018 Acura TLX equipped with the 3.5L V6 and the ZF 9-speed automatic transmission, this code is frequently a "ghost" code triggered by a software flaw. A well-documented Acura Technical Service Bulletin (TSB B19-003) states that a software miscalculation can falsely trigger the P0716 code during certain downshifts, specifically from 8th or 9th gear. This means the first step in diagnosis is always checking the TCM software version, not immediately replacing the sensor, which is a common and costly misstep on this specific platform.

Diagnostic Flowchart

Tap your situation to follow the diagnostic path that matches what you're seeing on this vehicle. 👇

Symptoms You May Notice

• Check Engine Light is on
• Harsh, jerky, or delayed gear shifts, especially between 2nd and 3rd gear
🎬 Try this: How to reset transmission learning for smoother shifts.
• Transmission may feel like it's slipping
• Vehicle may suddenly enter "limp mode," staying in a single gear and rapidly decelerating
• Reduced fuel economy
• Cruise control may not function

Most Likely Causes

1. Transmission Control Module (TCM) Software Update Needed 🔴 High Probability → Shop Transmission Assembly Acura issued TSB B19-003 specifically for this issue on V6 models with the 9-speed automatic transmission. A software miscalculation falsely triggers P0716 during an 8th or 9th gear downshift to 7th or lower.
   How to confirm: An Acura dealer or a shop with an i-HDS tool can check the current TCM software Program ID against the numbers listed in TSB B19-003. If the ID is outdated, the update is needed.
   Typical fix: Update the TCM software using dealer-level diagnostic tools. The update takes approximately 0.2 hours of labor according to the TSB.
   Est. part cost: $0
2. Failed Input/Turbine Speed Sensor ⚪ Low Probability → Shop Automatic Transmission Input Shaft Speed Sensor While possible, this is a very low probability cause for this specific code on this platform. The sensor is internal to the transmission and less prone to failure than the software. On the ZF9, the sensor is part of the valve body assembly. 🎬 Watch: Learn how the ZF 9-speed transmission operates internally.
   How to confirm: Only after confirming the TCM software is up to date per TSB B19-003 should the sensor be suspected. Diagnosis would involve using a scan tool to monitor live data for dropouts, which is a complex task as the sensor is internal.
   Typical fix: Replacement is a major repair requiring removal of the transmission valve body. This is highly unlikely to be the correct fix if the software has not been updated first.
   Est. part cost: $50-$150
3. Low or Dirty Transmission Fluid ⚪ Low Probability → Shop Transmission Assembly The ZF 9-speed transmission can be sensitive to fluid level and condition. Owners on forums report that regular fluid changes are key to its health. However, it is unlikely to be the primary cause of a P0716 code when a specific TSB exists.
   How to confirm: Check the transmission fluid level and condition according to the manufacturer's procedure. The fluid should be at the correct level, red in color, and not smell burnt.
   Typical fix: Perform a transmission fluid drain and fill using the correct OEM-spec fluid (Acura ATF Type 3.1 or equivalent). Some dealers may try to mandate this with the software update.
   Est. part cost: $100-$200
4. Wiring or Connector Issue ⚪ Low Probability While a possibility for any sensor code, it's less likely than the known software issue. The sensor and most of its wiring are internal to the transmission, protecting them from external damage.
   How to confirm: Visually inspect the main transmission harness connector for any signs of damage, corrosion, or looseness. A continuity test on internal wires is not feasible without transmission disassembly.
   Typical fix: Repair or replace the damaged external wiring or connector.
   Est. part cost: $20-$100

Rare But Worth Checking

• Failing Transmission Control Module (TCM): → Shop Transmission Assembly While rare, if the software is up-to-date and the sensor/wiring are good, the TCM itself could have an internal fault causing it to misinterpret a valid signal. A replacement TCM is very expensive.
• Internal Transmission Failure: → Shop Transmission Assembly In very rare cases, if all other possibilities are exhausted, the code could be a symptom of a larger internal mechanical failure within the transmission. This would likely be accompanied by more severe symptoms like grinding noises or a complete loss of drive.

Diagnosis Steps

1. Connect an OBD-II scanner and confirm the presence of code P0716. Note any other codes.
2. Crucial Step for TLX V6: Have a dealer or qualified shop connect an i-HDS tool and check the TCM software version. Compare the Program ID to Acura TSB B19-003.
3. If the software is outdated, perform the TCM update. The TSB indicates this is a 0.2-hour job. Clear the codes and test drive the vehicle, attempting to replicate the conditions (downshifting from high gears) that set the code.
4. If the software is already current or the code returns, proceed with further diagnosis.
5. Check the transmission fluid level and condition. Service if low, dirty, or burnt-smelling, using Acura ATF Type 3.1.
🎬 See this step-by-step guide for changing your TLX transmission fluid.
6. Inspect the main external transmission wiring harness and connector for any visible damage, corrosion, or loose connections.
7. Use a professional scan tool to monitor the input speed sensor's data while driving. Look for dropouts, erratic readings, or values that don't make sense for the vehicle's speed and gear. This step requires expertise.
8. If the sensor signal is confirmed to be faulty despite updated software and good wiring, the issue may be the internal sensor itself or the TCM. Given the sensor is internal to the transmission, further diagnostics become highly invasive and costly.

Parts You'll Likely Need

• TCM Software Update (OEM #B19003A (Template ID for warranty claim)) — This is the most common fix for the V6 TLX, as specified by Acura's own Technical Service Bulletin B19-003.
  OEM price range: $150-$250
  Aftermarket price range: N/A
• Input Shaft (Mainshaft) Speed Sensor (OEM #28810-RWE-003) — If the TCM software is up to date, the sensor itself is the next suspect, but it is a very unlikely failure point for this code on this platform. It is internal to the transmission.
  Trusted brands: Acura (OEM)
  OEM price range: $110-$160
  Aftermarket price range: $50-$90

Technical Service Bulletins (TSBs) & Recalls

• B19-003: States that a TCM software miscalculation is a known cause for P0716 on these vehicles during specific downshifts and that a software update is the fix.
• A19-004: A parallel TSB for 2016-17 Honda Pilots with the same 9-speed transmission and P0716 software issue, confirming this is a platform-wide problem.
• A19-124: A TSB for the Honda Odyssey with the 9-speed transmission that addresses harsh shifting and potential P0716 triggers via a software update.

Platform-Specific Known Issues

• Technical Service Bulletin B19-003: Acura explicitly states that for 2015-2018 TLX V6 models, 'During a downshift from 9th or 8th gear to 7th gear or lower, a miscalculation in the TCM software causes the MIL to come on with DTC P0716'. The corrective action is to update the TCM software.
• NHTSA Owner Complaint ODI #11218026: A 2015 Acura TLX owner reported their vehicle had diagnostic trouble code P0716, confirming the issue occurs in real-world conditions.
• Owner Forum Experience: Limp Mode: A Reddit user with a 2016 Acura MDX (a platform mate with the same transmission and issue) reported experiencing P0716, which caused the vehicle to enter limp mode and rapidly decelerate from 75 mph on a highway, highlighting the potential severity of the symptoms.
• Owner Forum Experience: Repair Costs: On Acurazine, a user reported a dealer quoting $650 for the software update, claiming a full fluid change was mandatory. Another dealer performed the update without the flush, illustrating that owners should be wary of upselling.

Mechanic-Grade Diagnostic Values

• Input Speed Sensor Signal Voltage — expected: ~0.5 V at idle, rising proportionally with engine speed to ~4.0-4.5 V at wide-open throttle.. Failure: Readings that are static, erratic, or fall outside the 0.5-4.5V range during operation suggest a sensor or circuit fault.
• Input Speed Sensor Resistance — expected: 500–1500 Ω (general specification, may vary).. Failure: Resistance outside the specified range indicates a faulty sensor.

Hidden / Shadow Codes Worth Checking

• TCM Program ID / Program P/N: This is not a trouble code, but rather the software version identifier stored in the Transmission Control Module. TSB B19-003 lists specific Program IDs and Part Numbers; comparing the vehicle's installed software version to this list is the definitive way to confirm if the P0716-related update is needed. (see via This information is accessible via the 'A/T Data List' on the Acura i-HDS (Honda Diagnostic System) dealer scan tool.)

Scan Tool Commands That Help

• Acura i-HDS (J2534 Rewrite Software): TCM Software Update — This is the primary corrective action for P0716 on this platform, as specified by TSB B19-003, to fix the software miscalculation.
• Acura i-HDS or equivalent professional scan tool: TCM Static/Dynamic Learn Procedure — This procedure is required after replacing transmission hardware, such as the valve body or the entire transmission, to allow the TCM to learn the characteristics of the new components.

Wiring & Ground Locations

• G101 — On the transmission housing, under the intake and near the top of the engine bay. It serves as a primary grounding point for multiple engine and transmission sensors.. A poor connection at this ground point can introduce electrical noise or voltage irregularities, potentially causing erratic signals from the input speed sensor and triggering a P0716 code.
• TCM Connector — The Transmission Control Module (TCM) and its connectors are typically located in the engine bay. For the ZF9 transmission, the TCM is often mounted directly to the transmission housing.. Technicians may need to access specific pins on the TCM connector to test for voltage, ground, and signal continuity from the input speed sensor circuit, especially if the software update does not resolve the code.

Real Owner Repair Stories

• Reddit user @jacktheripper14 (2016 Acura MDX (same ZF 9-speed transmission and P0716 issue)) — Vehicle entered 'limp mode' and rapidly decelerated from 75 mph on the highway, triggering code P0716.
  ✅ What actually fixed it The user, a technician, stated the fix is a TCM software update per the service bulletin. They also noted that if the update doesn't work, the issue is a hard failure requiring transmission sub-harness or full transmission replacement because the sensor is internal.

When the Usual Fixes Don't Work

• While the vast majority of P0716 instances on the 2015-2018 TLX V6 are resolved with the TCM software update from TSB B19-003, there are documented cases where this is not the final fix. In one instance involving a related Acura model with the same transmission, the code returned after the software update. The ultimate repair required replacing the entire transmission valve body, as the input speed sensor is integrated into it and not separately serviceable. This indicates that while the software update should always be the first step, a persistent P0716 code points to a genuine, albeit rare, hardware failure.

Model Year Variations Within This Range

• 2015-2018: The primary variation is the TCM software installed from the factory. TSB B19-003 provides a list of updated Program Part Numbers (P/N) that resolve the P0716 issue. For example, for a 2015-16 TLX 9AT 2WD Base/Tech, the original software might be P/N 28103-5J4-A50, while the updated version is a higher number like 28103-5J4-A70. A technician must check the installed P/N against the TSB chart to confirm if an update is required.
