P0720 on 2011-2013 Lincoln Navigator: Sudden Downshift Causes & Fixes

What's Unique About the 2011-2013 Lincoln NAVIGATOR

The 2011-2013 Navigator uses the Ford 6R80 automatic transmission, which has a widely documented design flaw. The Output Speed Sensor (OSS) is integrated into an internal component called the 'molded lead frame.' This lead frame, a plastic and metal circuit board, is notorious for developing fatigue cracks in its internal circuitry due to heat cycles and vibration. This causes a sudden loss of the speed signal. The PCM misinterprets this as the vehicle stopping and commands a dangerous downshift to first gear, which can lock the rear wheels at highway speeds. This issue was so prevalent that it led to multiple recalls, TSBs, and extended warranty programs from Ford.

Diagnostic Flowchart

Tap your situation to follow the diagnostic path that matches what you're seeing on this vehicle.

Symptoms You May Notice

• Sudden, violent downshift to a low gear (often 1st) while driving.
• Check Engine Light and/or wrench light illuminated.
• Speedometer behaving erratically or dropping to zero.
• Odometer displaying dashes (-------) instead of mileage.
• Loss of PRNDL (gear indicator) display on the dash.
• Vehicle entering 'limp mode' with reduced power or starting off in 5th gear.
• Cruise control not working.
• Seat belt warning light may illuminate.

Most Likely Causes

1. Failed Molded Lead Frame 🔴 High Probability → Shop Transmission Valve Body This is a well-documented, widespread failure on the 6R80 transmission due to the design and materials of the original part. The internal circuitry for the OSS cracks from heat and vibration, causing signal loss. Ford acknowledged this by issuing TSBs and a warranty extension program (19N01).
   How to confirm: A professional scan tool can monitor the Output Shaft Speed (OSS) sensor data in real-time. A sudden drop to zero while the vehicle is moving confirms the sensor signal is being lost. 🎬 See how to swap the output speed sensor on this transmission. The presence of codes P0720, P0722, or P0731 is a strong indicator, as specified by Ford's own service actions.
   Typical fix: Replace the entire molded lead frame assembly inside the transmission. This involves draining the fluid, dropping the pan, and removing the valve body to access the part.
   Est. part cost: $150-$350

Rare But Worth Checking

• Wiring Harness or Connector Damage: While the lead frame is the most common culprit, damage to the main transmission external connector (bulkhead sleeve) or the wiring leading to it can cause similar signal issues. Always inspect the external wiring for corrosion or damage before condemning the internal lead frame. A leaking bulkhead sleeve is a common issue and should be replaced during the lead frame service regardless.
• Powertrain Control Module (PCM) Fault: → Shop Engine Control Module (ECM) In very rare cases, the PCM itself can fail. This should only be considered after the lead frame and all wiring have been confirmed to be in good condition. Misdiagnosing a PCM is a costly mistake, as one owner on a forum experienced when a $2,800 PCM replacement failed to fix the issue that was ultimately the lead frame.

Diagnosis Steps

1. Use an advanced OBD-II scanner to confirm the presence of P0720 and check for related codes like P0722, P0731, and P1500. The presence of these specific codes together is a strong confirmation per Ford's own TSBs.
2. Monitor the live data stream for the Output Shaft Speed (OSS) sensor while driving (if safe to do so) or with the wheels raised. Look for the speed to drop to zero unexpectedly while vehicle speed is still indicated by other sensors (like wheel speed sensors).
3. Inspect the main transmission wiring harness connector (the bulkhead connector) for fluid leaks, corrosion, or pushed-out pins. A leaking bulkhead sleeve is common and can cause electrical issues.
4. If external wiring is okay and the OSS signal is dropping out, the diagnosis points to an internal failure of the molded lead frame.
5. Drop the transmission pan and inspect the fluid. Dark, burnt fluid can indicate a more severe internal transmission problem, but clean fluid is expected if the only issue is the lead frame.
6. Proceed with replacing the molded lead frame, which requires removing the valve body. The lead frame is attached to the valve body with six T27 Torx screws, torqued to 62 in-lbs. The valve body bolts must be torqued to 71 in-lbs in the correct sequence.
🎬 Watch this video for a detailed lead frame assembly replacement guide.

Parts You'll Likely Need

• Transmission Molded Lead Frame (Conductor Plate) (OEM #AL3Z-7G276-D) — This is the component that houses the faulty Output Speed Sensor and is the root cause of the P0720 code and sudden downshifting in over 99% of cases for this vehicle. The -D suffix is a revision of earlier parts.
  Trusted brands: Motorcraft, Dorman (P/N: 926-149)
  OEM price range: $200-$350
  Aftermarket price range: $150-$250
• Mercon LV Automatic Transmission Fluid (OEM #XT-10-QLVC) — The transmission must be drained to perform the repair. Approximately 9-10 quarts are needed for a pan drop and fill after this service.
  Trusted brands: Motorcraft
  OEM price range: $80-$120
  Aftermarket price range: $70-$100
• Transmission Filter Kit (with Pan Gasket) — The filter should always be replaced whenever the transmission pan is removed.
  Trusted brands: Motorcraft, Wix, ATP
  OEM price range: $30-$50
  Aftermarket price range: $20-$40
• Transmission Bulkhead Connector Sleeve (OEM #6L2Z-7G276-AA) — This seal for the main electrical connector is prone to leaking and should be replaced as a preventative measure while the valve body is out. It is an inexpensive part that prevents future leaks and electrical problems.
  Trusted brands: Motorcraft, Dorman (P/N: 917-138)
  OEM price range: $20-$30
  Aftermarket price range: $15-$25

Related Codes That Often Appear With This One

• P0722 — Stands for 'Output Speed Sensor Circuit No Signal.' This code often appears with P0720 as it indicates a complete loss of the signal, which is what happens when the lead frame connection fails. Both are listed in Ford's service programs for this issue.
• P0731 — Stands for 'Gear 1 Incorrect Ratio.' This code is set when the PCM detects a mismatch between engine speed and output shaft speed for first gear. It's a direct result of the transmission being forced into first gear at an inappropriate speed and is also listed as a key diagnostic code in Ford's program 19N01.
• P1500 — This manufacturer-specific code can be related to vehicle speed sensor intermittent failures, and is cited alongside P0720, P0722, and P0731 in Ford's Customer Satisfaction Program 19N01 as a primary indicator for lead frame replacement.

Technical Service Bulletins (TSBs) & Recalls

• 19N01-S3: Mentions that an OSS failure may result in an illuminated MIL/wrench light and DTCs P0720, P0722, P0731, and/or P1500, requiring lead frame replacement.
• TSB 13-6-8: Describes symptoms of starting in 5th gear, speedometer at zero, and odometer dashes, with possible P0720/P0722 codes, for vehicles built before 4/8/2013. The fix is to replace the molded leadframe.
• TSB 13-2-3: Addresses engagement in 5th gear from a start or intermittent harsh downshifts, with symptoms including an illuminated wrench light and speedometer at zero, for 2012-2013 Navigators.

Platform-Specific Known Issues

• Ford Safety Recall 16S19 (NHTSA 16V-248) was issued for 2011-2012 Navigators. The fix was a PCM reprogram to prevent the downshift to 1st gear but did not replace the failing hardware.
• Customer Satisfaction Program 19N01 extended the warranty on the molded lead frame to 10 years or 150,000 miles for 2012-2013 Navigators built between April 11, 2011, and August 19, 2013. This program covered a one-time replacement if codes P0720, P0722, P0731, or P1500 were present. This coverage has now expired for all affected vehicles.
• Ford Technical Service Bulletin (TSB) 13-6-8 also addresses this issue, noting symptoms like starting in 5th gear, speedometer at zero, and codes P0720/P0722, recommending lead frame replacement for vehicles built before 4/8/2013.
• An NHTSA investigation (RQ17-010) was opened in 2018 to review complaints of downshifting on vehicles not covered by the original recall, indicating the problem was more widespread than initially acknowledged.

Mechanic-Grade Diagnostic Values

• OSS Circuit Resistance at PCM Connector — expected: Less than 5 ohms. Failure: Greater than 5 ohms or an open circuit (infinite resistance) indicates a break in the wiring or a failure within the molded lead frame.
• Valve Body-to-Case Bolt Torque — expected: 8 Nm (71 lb-in). Failure: Incorrect torque or sequence can lead to internal transmission leaks and shifting problems.
• Molded Lead Frame-to-Valve Body Bolt Torque — expected: 53-62 in-lbs (Varies slightly by source, 53 in-lbs is a common video reference). Failure: Improper torque can damage the lead frame or cause poor connections to the solenoids.

Scan Tool Commands That Help

• Ford IDS, FORScan: Clear Transmission Adaptive Tables / Reset All Adaptations — This must be performed after replacing the molded lead frame or valve body. It erases the old, learned shift pressures and timings, allowing the PCM to relearn the characteristics of the new components. Failure to do this often results in harsh or erratic shifting.
• Ford IDS, FORScan: Transmission Characterization Update / Solenoid Body Strategy Programming — If the entire valve body with solenoids is replaced, the new solenoid strategy and ID number (which comes on a tag with the new part) must be programmed into the PCM. This ensures the PCM's commands match the hydraulic characteristics of the specific solenoids.

Wiring & Ground Locations

• PCM Connector C175T, Pin 25 — This is one of the main connectors at the Powertrain Control Module (PCM), which is typically located in the engine bay.. This pin, with a Yellow-Orange wire, is the signal circuit for the Output Shaft Speed (OSS) sensor. Technicians can test for continuity and voltage here to diagnose a circuit fault without having to access the transmission directly.
• Transmission Bulkhead Connector (C1616) — The main external electrical connector on the passenger side of the 6R80 transmission case.. This is the primary connection point between the internal lead frame (which contains the OSS) and the vehicle's wiring harness. A common point of failure is the connector sleeve seal, which can leak fluid and contaminate the connection, causing codes like P0720.
• Thermal Bypass Valve — Sits in a bore in the transmission case, located near the front corner, and is held in place by the valve body.. This is not an electrical part, but it often falls out when the valve body is removed for lead frame service. If not reinstalled correctly (spring first, then valve with small tip up), it can block transmission cooler flow, leading to overheating.

Real Owner Repair Stories

• YouTube channel 'Home Built 86' (2015 Ford F-150 (with 6R80 transmission, applicable to 2011-2013 Navigator)) — Initially, the truck would not downshift properly from a stop. Later, it experienced very hard downshifts and stored code P0720.
  ❌ Tried (didn't work) The owner proceeded directly to the most likely cause based on research.
  ✅ What actually fixed it The owner replaced the molded lead frame, transmission filter, and fluid. The repair resolved all symptoms. He noted that metallic debris can short the spade terminals on the lead frame where they connect to the solenoids, which is a known issue.

OEM Part Supersession History

• AL3Z-7G276-A, AL3Z-7G276-B → AL3Z-7G276-D — The -D revision is the updated version of the molded lead frame designed to be more robust and less prone to the circuit cracks that cause P0720.
  Heads up: While older revisions might be found, the 'D' version is the correct and most reliable service part to use.

Model Year Variations Within This Range

• 2011+: The 2011 and newer 6R80 transmissions moved away from the previous design where the Transmission Control Module (TCM) was integrated with the lead frame. The 2011+ design uses a separate PCM to control the transmission, and this is the version that suffers from the widespread lead frame failure causing P0720.
