P0740 on 2005-2012 Jeep Wrangler: Torque Converter Clutch Circuit Fixes

What's Unique About the 2005-2012 Jeep WRANGLER

The 2005-2012 Wrangler spans two distinct automatic transmissions. The 2005-2011 models (late TJ and early JK) use the Chrysler 42RLE 4-speed, which is notoriously prone to solenoid pack failures that trigger P0740 and can force the vehicle into 'limp mode' (stuck in 2nd gear). The 2012 JK model switched to the more robust Mercedes-designed W5A580 (also called NAG1) 5-speed automatic. On the W5A580, while P0740 can still be caused by a solenoid, it may also relate to issues with the conductor plate (which houses speed sensors) or internal torque converter failure.

Diagnostic Flowchart

Tap your situation to follow the diagnostic path that matches what you're seeing on this vehicle.

Generation note: This range covers the end of the TJ generation (2005-2006) and the majority of the JK generation (2007-2012). The key difference is the transmission: 2005-2011 models use the Chrysler 42RLE 4-speed automatic, while 2012 models use the Mercedes W5A580/NAG1 5-speed automatic. The causes are similar, but the specific parts (solenoid pack vs. conductor plate/individual solenoids) and diagnostic procedures are different.

Symptoms You May Notice

• Check Engine Light is on
• Reduced fuel economy
• Engine RPMs fluctuate or are higher than normal at highway speeds
• Vehicle shudders or jerks at highway speeds, especially during light acceleration
• Transmission feels like it is slipping or has delayed shifts
• Transmission may get stuck in a single gear (limp mode), often 2nd gear
• Stalling when coming to a stop
• In some cases, no noticeable symptoms other than the check engine light

Most Likely Causes

1. Low or Dirty Transmission Fluid 🔴 High Probability → Shop Transmission Assembly Off-road use can lead to leaks from the pan or cooler lines, and neglected maintenance schedules are common. Both the 42RLE and W5A580 transmissions are sensitive to fluid level and quality.
   How to confirm: Check the transmission fluid dipstick for proper level and inspect the fluid's color and smell. It should be bright red and not smell burnt. If it's brown/black or has metallic particles, it's contaminated and indicates internal wear.
   Typical fix: Top off with the correct fluid (Mopar ATF+4) or perform a transmission fluid and filter change. Multiple fluid changes may be needed to flush out old, degraded fluid.
   Est. part cost: $50-$150
2. Faulty Torque Converter Clutch (TCC) Solenoid / Solenoid Pack 🔴 High Probability → Shop Automatic Transmission Torque Converter The solenoid pack on the 42RLE transmission (2005-2011) is a well-documented, common failure point that causes P0740 and limp mode. The TCC solenoid is part of this assembly.
   How to confirm: After dropping the transmission pan, test the resistance of the solenoid's electrical circuit. For the 42RLE, the resistance for the solenoids should be around 1.7 ohms, though specifications state 1-3 ohms is acceptable. This can be tested through the main harness connector. 🎬 See how to remove and test the solenoid block.
   Typical fix: Replace the TCC solenoid. On the 42RLE, this is sold as a complete solenoid pack assembly that bolts to the valve body. 🎬 Watch: Step-by-step guide to replacing the 42RLE solenoid pack.
   Est. part cost: $150-$300
3. Failed Torque Converter 🟡 Medium Probability → Shop Automatic Transmission Torque Converter The internal lock-up clutch can wear out from high mileage, heavy use, or overheating. This is a mechanical failure, but it prevents lock-up and can trigger P0740 when the computer detects excessive slip. The provided TSB #9004009 for 62TE-equipped vehicles (not this Wrangler) also notes that if the TCC solenoid is okay, the code indicates a torque converter failure, a principle that often applies here as well.
   How to confirm: A professional technician will use a scan tool to monitor 'TCC slip speed' while driving. If the computer commands lock-up (solenoid is activated) and the slip RPM remains high (e.g., over 100-200 RPM), and the solenoid/circuit are good, the converter has failed internally.
   Typical fix: Replace the torque converter. This is a major job that requires removing the transmission from the vehicle.
   Est. part cost: $250-$600
4. Damaged Wiring or Connectors ⚪ Low Probability Wiring can be damaged from off-roading (snags, debris), engine/exhaust heat, or age. The main transmission connector is a common spot for corrosion or loose pins.
   How to confirm: Visually inspect the external wiring harness to the transmission for any chafing, melting, or corrosion. Unplug the connector and check for bent or contaminated pins. Test for continuity and shorts on the TCC solenoid circuit from the TCM connector to the transmission connector.
   Typical fix: Repair the damaged section of wire or replace the faulty connector.
   Est. part cost: $20-$100

Rare But Worth Checking

• Faulty Powertrain/Transmission Control Module (PCM/TCM): → Shop Transmission Assembly This is very rare. The PCM/TCM should only be suspected after all other possibilities, including wiring, solenoids, and mechanical components, have been thoroughly tested and ruled out.
• Clogged Internal Transmission Passages: → Shop Transmission Assembly Debris from normal wear or a previous failure can clog the small fluid passages in the valve body, preventing the TCC from engaging. This usually requires a transmission overhaul or valve body replacement.
• Faulty Conductor Plate (2012 W5A580/NAG1 only): On the 2012 model with the 5-speed W5A580, the conductor plate houses the speed sensors and electrical connections for the solenoids. Failure of the plate's internal circuits can cause various codes, including P0740, and often results in limp mode.

Diagnosis Steps

1. Check and verify the transmission fluid level and condition. Ensure the correct fluid type (Mopar ATF+4) is being used.
2. Use an OBD-II scanner to check for any other transmission-related codes, like P0700.
3. Inspect the external transmission wiring harness and connectors for any visible damage, corrosion, or loose connections.
4. With a professional scan tool, monitor the TCC Slip Speed (RPM) while driving at a steady cruise speed (e.g., 45-55 mph). Command the TCC to lock and observe if the slip drops to near zero. If it doesn't, the problem is either hydraulic, mechanical, or the solenoid is not activating.
5. Drop the transmission oil pan to gain access to the internal components. Inspect the pan for excessive metal debris.
6. For 42RLE (2005-2011): Test the resistance of the TCC solenoid circuit at the solenoid connector or main harness. It should be between 1-3 ohms. If out of spec, the solenoid pack is bad.
7. For W5A580 (2012): Test the individual TCC solenoid. If it tests good, inspect the conductor plate for cracks or damage before suspecting the torque converter.
8. If the solenoid and wiring test good, but significant slip is still present when commanded, the torque converter has likely failed mechanically and requires replacement.

Parts You'll Likely Need

• Transmission Solenoid Pack (42RLE) (OEM #5143151AA (supersedes 04800171AA)) — This is the most common point of failure for the TCC circuit on 2005-2011 Wranglers with the 42RLE transmission.
  Trusted brands: Mopar, Rostra, Napa (Remanufactured)
  OEM price range: $250-$350
  Aftermarket price range: $150-$250
• Torque Converter — If the solenoid and electrical circuits are functioning correctly, the mechanical clutch inside the converter has likely failed.
  Trusted brands: Mopar, LuK, Transtar, Whatever the transmission shop recommends
  OEM price range: $400-$600
  Aftermarket price range: $200-$400
• Transmission Filter and Pan Gasket Kit (42RLE) (OEM #5013470AC) — Must be replaced any time the transmission pan is removed for service, such as a solenoid replacement. A popular aftermarket option is the LubeLocker LLT-A042 reusable gasket.

Related Codes That Often Appear With This One

• P0700: Transmission Control System Malfunction. This is a general code indicating the TCM has stored a fault; P0740 will be the specific fault.
• P0841, P0846, P0871: These are other pressure switch/solenoid codes for the 42RLE that may appear alongside P0740 if the solenoid pack has a widespread failure.

Technical Service Bulletins (TSBs) & Recalls

• TSB 21-011-05 (for W5A580/NAG1): While not directly for P0740, this TSB addresses a transmission shudder during TCC engagement in 3rd and 4th gear. The cause is identified as possible water contamination in the ATF (as little as 0.5%). The fix involves flushing the transmission and torque converter, replacing the filter, and sealing the transmission fill tube to prevent future water intrusion. This highlights the transmission's sensitivity to fluid contamination.

Platform-Specific Known Issues

• On 2005-2011 models with the 42RLE transmission, failure of the solenoid pack is a very common issue that can cause P0740 and put the vehicle into limp mode, where it will not shift out of second gear.
• A user on JK-Forum.com reported getting code P0740 and was told by a dealer it required a major transmission overhaul, which was covered under their lifetime warranty.
• A YouTube video by 'SomeGuyOutside' provides a detailed DIY replacement of the 42RLE solenoid pack on a JK, noting that stalling at low speeds and intermittent limp mode (especially after the vehicle is hot) are classic symptoms.

Mechanic-Grade Diagnostic Values

• 42RLE Solenoid Pack Resistance — expected: 1.7 ohms (acceptable range 1-3 ohms). Failure: A reading of infinite resistance (open) or near zero (shorted).
• TCM Ground Circuit Resistance (42RLE) — expected: Less than 1.0 Ohm. Failure: Resistance higher than 1.0 Ohm indicates a poor ground connection that can cause erratic TCM behavior.
• Scan Tool TCC Slip Speed (RPM) — expected: Near 0 RPM when TCC is commanded to lock at cruising speed.. Failure: Sustained slip of over 100-200 RPM when lockup is commanded indicates a mechanical/hydraulic failure in the torque converter or its apply circuit.

Scan Tool Commands That Help

• wiTECH (or other professional scan tool): TCC System Test / Solenoid Activation Test — This bidirectional command allows a technician to manually activate the TCC solenoid while monitoring the system. It helps isolate whether the fault is electrical (solenoid/wiring) or mechanical/hydraulic (converter/valve body).
• wiTECH: Quick Learn Procedure — This procedure is required after replacing the solenoid pack or transmission to allow the TCM to relearn clutch fill volumes and shift points. It should be performed after repairs are complete.

Wiring & Ground Locations

• TCM Ground (Pin 24) — On the Transmission Control Module (TCM) connector. The TCM is located in the engine compartment.. A poor ground at the TCM can cause a variety of erratic issues and false codes, including P0740. Verifying this ground has less than 1.0 ohm of resistance is a key electrical check.
• Transmission Solenoid/Pressure Switch Assembly Connector (42RLE) — On the transmission case, connecting the main vehicle harness to the internal transmission wiring and solenoids.. This is the primary connector to inspect for corrosion, fluid intrusion, or damaged pins. The TCC solenoid circuit passes through this connector. A wiring diagram for a 2007 Wrangler identifies the TCC solenoid wire as T54.
• Ground G100 — On the battery cable.. As a primary ground for the powertrain system, corrosion or a loose connection at G100 can cause widespread electrical issues, including problems with the transmission control system.

Real Owner Repair Stories

• JK-Forum.com user (2008 JKU with 175k miles) — P0740 code present for a long time with no noticeable driving issues, but failed smog test. Eventually, experienced shuddering going uphill.
  ❌ Tried (didn't work) Driving with the code for an extended period.
  ✅ What actually fixed it A transmission shop diagnosed a bad Torque Converter and TCC solenoids. The owner was advised to rebuild the transmission due to the high mileage, but the root cause of the P0740 was identified as the torque converter and its control solenoid.
• YouTube video (Chrysler 300 with 42RLE) (2010 Chrysler 300 (same 42RLE transmission)) — P0740 code appeared, and continued driving until the transmission would no longer shift gears.
  ❌ Tried (didn't work) Continued driving after the code appeared.
  ✅ What actually fixed it Replaced the solenoid pack, transmission filter, and fluid. The repair was successful and the transmission worked for over a year with no issues. The video notes the importance of having the gear selector in the correct position (low) when removing/installing the valve body.

OEM Part Supersession History

• 04800171AA → 5143151AA — Updated/revised part for the 42RLE transmission solenoid pack.
  Heads up: Some sources state 5143151AA was replaced by 4800171AA, while most retail and parts sites show the opposite. 5143151AA is the most commonly sold and referenced part number for replacement.
• 52108308AB, 68021352AA → 52108308AC — Updated part for the W5A580/NAG1 transmission conductor plate.
  Heads up: These part numbers are often listed together for the same component. 52108308AC is the most current OEM replacement number.

Model Year Variations Within This Range

• 2005-2006 vs 2007-2011 (42RLE): In 2007, the 42RLE transmission was changed from a static line pressure system to a Variable Line Pressure (VLP) system. Pre-2007 models had a constant line pressure, while 2007-2011 models vary the pressure based on engine load for smoother shifts. This can affect diagnostics and aftermarket components, as some controllers (like the ATS Co-Pilot) are designed specifically for the 2007-2011 VLP system. There are also different part numbers for a 2007 vs a 2008-2011 42RLE transmission, though the specific differences are not well-documented.
