Choosing the Right Headlight Switch for Your 1962-1968 Chevrolet Chevy II
Don't get left in the dark—understand the common failures and replacement options for your classic Chevy II's headlight switch.
- Flickering headlights are the #1 sign of a bad switch, caused by the internal circuit breaker failing.
- Before ordering, visually inspect your switch's connector, as GM used two different, non-interchangeable types during 1962-1968.
- For reliability, choose a Tier 1 aftermarket brand like ACDelco or Standard Ignition.
- Replacement is a simple DIY task for most owners, typically taking less than an hour.
Signs of a Failing Headlight Switch in a Classic Chevy II
The headlight switch in a 1960s GM car is a high-load mechanical part that wears out over time. Unlike modern cars, your Chevy II does not have a fuse for the headlight circuit in the fuse box. Instead, it uses a self-resetting circuit breaker built directly into the switch. When this breaker fails or the switch's internal contacts corrode, you'll experience problems.
Key Failure Symptom: Flickering Headlights
🎬 Watch this guide on troubleshooting classic car headlight issues.The most common and alarming symptom is headlights that flicker on and off by themselves while driving. This happens when the old switch overheats, causing the internal circuit breaker to trip. As it cools for a few seconds, it resets, and the lights come back on, only to repeat the cycle. This is a clear sign the switch is worn out and needs immediate replacement.
- Lights Won't Turn On: The switch may fail completely, leaving you with no headlights or taillights.
- Dash Lights Don't Work or Dim: The small coil inside the switch that controls the dash light brightness can burn out, causing your instrument panel to go dark.
- Burning Smell or Hot Switch: A burning plastic smell or a switch that is hot to the touch indicates a serious electrical problem inside the switch, creating a fire risk.
- Only Some Lights Work: You might lose only the parking lights or only the headlights, indicating a specific contact inside the switch has failed.
Choosing the Right Aftermarket Headlight Switch
For a vehicle like the Chevy II, "New OEM" parts from GM are no longer available. Aftermarket reproductions are your only option. Quality can vary, so it's important to choose a reputable brand.
| Brand Tier | Brands | Quality & Cost Assessment |
|---|---|---|
| Tier 1: OEM-Quality Replica | ACDelco, Standard Ignition | ACDelco is GM's own parts brand, and their classic car parts are generally considered high-quality reproductions made to original specifications. Standard Ignition is a long-standing, trusted aftermarket brand with a good reputation. These brands cost more but offer the best fit, finish, and longevity. Expect to pay in the $50 - $90 range. |
| Tier 2: Economy | Replacement, Store Brands (e.g., Duralast) | These are value-focused brands. While functional, they may not have the same robust feel or long-term durability as Tier 1 parts. They are a budget-friendly option that will get the job done, typically costing in the $27 - $50 range. For a car that is driven regularly, investing in a Tier 1 brand is often worth the extra cost. |
Important: Check Your Connector!
🎬 See how to identify the two different Chevy II switches.GM used two different, non-interchangeable headlight switches during this period. Early models (roughly 1962-1964) used a larger switch with a specific electrical connector pattern. Later models (roughly 1965-1968) used a smaller switch with a different pattern. Before ordering, it is critical to look at your existing switch's 8-prong connector and compare it to the photos of the replacement part to ensure you get the correct one for your dash harness. Many cars of this age may have had their wiring harnesses swapped over the years.
Frequently Asked Questions (FAQ)
Is replacing the headlight switch a difficult job? 🎬 Follow this step-by-step video to replace your GM headlight switch.
No, for someone with basic mechanical skills, this is a very doable DIY job. It involves reaching under the dash, pressing a small spring-loaded button on the switch body to release the knob and shaft, unscrewing a retaining nut on the dash, and unplugging the electrical connector. The most difficult part is often just accessing the switch under the dashboard.
Why can't I find a fuse for my headlights?
Classic GM vehicles from this era, including the Chevy II, do not use a fuse for the main headlight circuit. They rely on a circuit breaker that is built into the headlight switch itself. If the circuit overheats, the breaker trips and automatically resets as it cools, which is what causes the lights to flicker on and off.
Is it the headlight switch or the floor dimmer switch?
If your headlights work on either high or low beam but not both, the problem is likely the foot-operated dimmer switch on the floor. If your headlights flicker, don't work at all, or you have issues with dash and parking lights, the problem is almost always the main headlight switch in the dashboard.
What is "New Old Stock" (NOS)?
NOS stands for New Old Stock. These are original parts made by GM decades ago that were never sold or installed. While they are true OEM parts, they can be very expensive and hard to find. For a common replacement part like a headlight switch, a high-quality aftermarket reproduction from a brand like ACDelco or Standard Ignition is a more practical choice.
Helpful Videos
Technical Specifications
OEM Part Numbers: 1995046 1995047
8-prong male blade terminal connector. Includes internal self-resetting circuit breaker and dash light rheostat.
