A Mechanic's Guide to the 1966-1974 Jeep CJ5 Ignition Contact Set
Keep your classic CJ5's engine firing reliably with the right set of ignition points.
- The ignition contact set (points) is a regular maintenance item on a 1966-1974 CJ5 and should be inspected often and replaced periodically.
- Always replace the condenser at the same time as the points; most aftermarket kits include both.
- Setting the correct point gap with a feeler gauge is absolutely critical for proper engine timing and performance.
- While quality aftermarket points work well, many owners choose to upgrade to a more reliable electronic ignition system to eliminate maintenance.
Understanding Your CJ5's Ignition Points
The ignition contact set, or points, is a critical tune-up part in the classic 1966-1974 Jeep CJ5. Unlike modern cars with fully electronic ignition, your CJ5 relies on this mechanical system to time its spark. Because the points have a rubbing block that wears down and the contacts themselves can pit or burn, they are considered a regular maintenance item. Ignoring them can lead to a host of engine problems, from a rough idle to a complete no-start situation.
🎬 See how to diagnose intermittent ignition failure in early JeepsSymptoms of Failing Ignition Points
Worn or failing ignition points will give you clear signs that they need attention. Because they control the spark, the symptoms are all related to poor engine performance.
- Hard Starting or No Start: If the points are too worn, pitted, or misaligned, they can't properly trigger the ignition coil, leaving you with a weak spark or no spark at all.
- Engine Misfires: Pitted or burned contacts create an inconsistent connection, leading to erratic spark and a misfiring or sputtering engine, especially under load.
- Rough Idle: Incorrect point gap or worn contacts can cause inconsistent timing at low speeds, making your Jeep idle poorly.
- Loss of Power: At higher RPMs, worn springs can cause "point float," where the points fail to close properly, leading to a significant loss of power.
A Note on Recalls and Service Bulletins
Searches for official recalls and Technical Service Bulletins (TSBs) for the ignition contact set on the 1966-1974 Jeep CJ5 did not yield any results. This is typical for a vehicle of this age and for a part considered a standard maintenance item. Any recalls found for Jeep ignition systems are for much newer models with electronic components.
Choosing the Right Aftermarket Ignition Contact Set
Since original Mopar parts for this system are generally unavailable, you will be choosing from aftermarket brands. Quality is key, as a cheap set of points can wear out quickly and leave you stranded. Here’s a breakdown of common brands:
- Standard Ignition (Standard Motor Products): Often considered a top-tier aftermarket replacement, Standard Ignition parts are known for their quality and durability, often meeting or exceeding original specifications. They are a reliable choice for a stock CJ5.
- Crown Automotive / Omix-Ada: These brands are very popular in the Jeep community for providing OE-style replacement parts. For a simple component like an ignition contact set, they offer a cost-effective solution that gets the job done for a daily driver or a restoration project.
- Accel: Accel is a performance-oriented brand. Their points often feature heavier springs to prevent point float at high RPMs and high-quality contact materials. While potentially overkill for a stock engine, they are a high-quality option that many builders trust.
Pro Tip: Always Replace the Condenser
The condenser is a vital part of the ignition points system. It prevents electrical arcs from jumping across the points, which causes them to burn and fail prematurely. Always replace the condenser whenever you replace the points. Most quality kits will include both parts.
Aftermarket Ignition Contact Set Cost
| Part Type | Estimated Cost |
|---|---|
| New Aftermarket Ignition Contact Set (Points & Condenser Kit) | $21.11 - $37.15 |
Frequently Asked Questions
How often do I need to replace my ignition points?
For a regularly driven CJ5, it's good practice to inspect the points during every major tune-up or oil change and replace them as needed. A typical replacement interval is every 10,000-12,000 miles. Worn rubbing blocks, pitting on the contacts, or difficulty maintaining a proper gap are all signs they need to be replaced.
What is "setting the gap" and why is it important?
Setting the gap refers to adjusting the maximum opening between the two contact points using a feeler gauge. This gap is critical for proper ignition timing. For many CJ5 engines, a common point gap is around .020 inches, but you must verify the spec for your specific engine. An incorrect gap will lead to poor performance, misfires, and premature wear.
Can I upgrade to electronic ignition instead?
Yes, and it is one of the most common and highly recommended upgrades for classic Jeeps. Electronic ignition conversion kits eliminate the points and condenser, providing a much more reliable, maintenance-free spark. While more expensive upfront, they improve reliability and performance, and you'll never have to set a point gap again.
🎬 Watch: How to install a Pertronix electronic ignition conversionWhat are common mistakes when ordering this part?
The biggest mistake is ordering a part for the wrong engine. Between 1966 and 1974, the CJ5 was available with several engines, including the Buick V6 and various AMC 🎬 Watch: Step-by-step points replacement on a Buick V6 engine inline-6 and V8 engines. These different engines used different distributors and, therefore, require a specific ignition contact set. Always verify the part is correct for your Jeep's year AND engine before ordering.
Helpful Videos
Technical Specifications
OEM Part Numbers: J0923146
Varies by engine. A common specification for the F-134 engine is a point gap of .020 inches and a cam/dwell angle of 42°. The gap for the AMC 304 V8 with points ignition is typically .032-.035 inches. Always verify the correct specification for your specific engine before installation.
