A Guide to Universal Joints for the 1967-1981 Chevrolet Camaro
That clunking noise or vibration from your classic Camaro could be a bad U-joint; here's how to choose the right replacement.
- A clunk when shifting or a vibration at speed are the most urgent signs your Camaro's U-joints need replacement.
- Dana Spicer is the most recommended brand for durability; ACDelco is a reliable choice for a standard daily driver.
- You must verify your U-joint series (likely 1310 or 1330) by measuring before ordering to avoid getting the wrong part.
- Replacing both U-joints at the same time is the best practice for a reliable, long-lasting repair.
Signs of a Failing Universal Joint
A worn-out U-joint will give you clear warning signs. Because failure can be catastrophic, it's important to address these symptoms as soon as they appear. A U-joint that breaks while driving can disconnect the driveshaft, causing a loss of power and potentially severe damage to the underside of your car.
- Clunking or Banging Noise: The most common symptom is a sharp 'clunk' when you shift into Drive or Reverse. This is the sound of excessive slack in the worn joint being taken up as the driveshaft begins to turn.
- Vibration While Driving: A vibration that you can feel through the floor or seats, which often gets worse at higher speeds, is a classic sign of a bad U-joint. The worn joint throws the driveshaft out of balance, causing the shaking.
- Squeaking Noise: A rhythmic squeaking that matches your wheel speed, especially at lower speeds, points to a dry or dying U-joint. The needle bearings inside the joint have lost their lubrication and are failing.
- Visible Rust Dust: If you inspect the U-joint and see a fine, reddish-brown dust around the bearing caps, it's a sign that the needle bearings inside have turned to dust from wear and lack of grease.
Choosing the Right Aftermarket U-Joint
For a classic car like the 1967-1981 Camaro, aftermarket parts are the most common and accessible option. Original OEM parts are long discontinued, and New Old Stock (NOS) parts are rare and expensive. The quality of aftermarket U-joints varies, so it's important to choose based on your car's use and your budget.
Brand Quality Tiers
Based on owner experiences and mechanic recommendations, aftermarket brands for your Camaro can be grouped into tiers.
| Tier | Brands | Description |
|---|---|---|
| Premium / Heavy-Duty | Dana Spicer, Moog (use with caution) | Dana Spicer is widely considered the gold standard for U-joints, often exceeding original quality and providing excellent durability. They are the top choice for performance applications or if you want maximum longevity. Moog was once in this category, but recent quality has become inconsistent; check the country of origin before buying. |
| OEM Quality / Daily Driver | ACDelco, SKF | ACDelco is GM's official parts brand and offers reliable, good-quality replacements that are perfect for a stock or daily-driven Camaro. SKF is another reputable brand that provides dependable performance for standard use. |
| Standard / Value | GMB | Brands like GMB offer a functional replacement at a lower cost. They are suitable for light-duty cars or if budget is the primary concern, but may not have the lifespan of premium brands. |
| Performance / Racing | Yukon Gear, Lakewood | These brands specialize in high-strength components for racing and extreme performance. They are often overkill for a street car but are built to handle high horsepower and abusive conditions. |
Pro Tip: Greasable vs. Non-Greasable. Non-greasable (sealed) U-joints are generally stronger because the cross body isn't drilled for a grease channel. Many high-quality brands like Spicer are sealed and lubricated for life. Greasable joints allow you to flush out contaminants but require regular maintenance. If you choose a greasable joint, one with the fitting on the end of the cap is often easier to service than one with the fitting on the body.
Known Issues for 1967-1981 Camaros
While there are no specific recalls for U-joints on this generation of Camaro, one Technical Service Bulletin (TSB) is worth noting.
- TSB 67-T-30 (1967 Models): Chevrolet issued a bulletin for 1967 Camaros with 327 and 350 engines and 4-speed transmissions that experienced severe "rear wheel hop" under hard acceleration. This condition puts extreme stress on the entire driveline, including the U-joints. The fix involved adding a traction bar. If you have an affected '67 model, ensuring this issue is addressed can prevent premature U-joint failure.
Frequently Asked Questions (FAQ)
How many U-joints does my Camaro have?
Your 1967-1981 Camaro has a simple, one-piece driveshaft with two universal joints: one at the transmission end (front) and one at the rear differential end (rear). 🎬 See how to replace the rear U-joint and pinion seal. It is highly recommended to replace both at the same time.
What U-joint size (series) do I need?
This is the most common ordering mistake. Camaros of this era used a few different U-joint sizes. The most common are the 1310 and 1330 series. Some later models may have used the GM 3R series. The only way to be certain is to measure your existing U-joint's width and bearing cap diameter. If your car has a non-original driveshaft or rear end, you may even need a combination joint that uses two different sizes (e.g., 1310 on one axis and 1330 on the other).
Can I replace U-joints myself?
Yes, this is a DIY-feasible job for someone with mechanical experience, but it can be difficult without the right tools. You will need to safely raise the vehicle, remove the driveshaft, and then use a heavy-duty bench vise or a ball joint/U-joint press tool to push the old joints out and press the new ones in. Doing it incorrectly can damage the new joint's needle bearings or bend the driveshaft yoke.
🎬 Watch this step-by-step guide to replacing Camaro U-joints.What's the difference between outside and inside clips?
Your Camaro uses U-joints with 'outside' snap rings or clips that fit into a groove on the outside of the yoke ears. Some factory original joints from this era were installed using injected nylon retainers instead of clips. These must be melted out with a torch before the joint can be pressed out. All aftermarket replacements will use snap rings.
Helpful Videos
Technical Specifications
Driveshaft contains two universal joints. Common series for this generation are 1310, 1330, and GM 3R. Measurement of the original parts is required for positive identification. Replacements use external snap rings to retain the bearing caps.
