A Guide to Alternators for the 1969-1975 Chevrolet Blazer
Keep your classic Blazer's electrical system running strong with the right new alternator.
- First, confirm if your Blazer needs an externally or internally regulated alternator; this is the most common ordering mistake.
- Consider upgrading to a high-output alternator (100+ amps) if you have added modern electronics like electric fans or a winch.
- When replacing, ensure the new alternator has the correct pulley type (V-belt) to match your existing belts.
- Replacing the alternator is a DIY-friendly job for most owners, typically taking about an hour with basic hand tools.
Is Your Alternator Failing? Common Symptoms
An alternator rarely fails without warning. For 1969-1975 Blazer owners, the signs are usually straightforward. Look out for these common symptoms:
- Dimming or Flickering Lights: Headlights that dim at idle and brighten when you rev the engine are a classic sign of a weak alternator.
- Battery Warning Light: That 'GEN' or 'BATT' light on your dash means the charging system has a problem. While it can be a battery issue, it often points to the alternator.
- Weak or Dead Battery: If you've replaced the battery but it keeps dying, the alternator is likely not recharging it properly.
- Strange Noises: A grinding or whining sound from the engine bay can indicate worn-out bearings inside the alternator.
- Electrical Problems: Slow power windows, a radio that cuts out, or other electrical gremlins can happen when the alternator can't provide consistent power.
- Difficulty Starting or Stalling: The alternator provides power to the ignition system. If it's failing, the engine may struggle to start or even stall while driving. 🎬 Watch this quick video to learn how to test your alternator.
External vs. Internal Regulator: The Most Important Choice
Before buying an alternator for your Blazer, you must know which type you have. GM switched from externally regulated alternators to internally regulated ones around 1973.
- Externally Regulated (1969-1972, some 1973): These systems use a separate box, usually mounted on the firewall or fender, to control the alternator's output. The alternator itself will have a square two-prong plug.
- Internally Regulated (some 1973, 1974-1975): The voltage regulator is built directly into the alternator. The plug is typically a flat, rectangular two-prong connector on the side.
It is critical to order the correct type for your vehicle's wiring. Many owners of earlier models upgrade to an internally regulated alternator for improved reliability, but this requires a wiring modification or a conversion harness.
🎬 See how easy it is to convert to an internal regulator.Choosing the Right Aftermarket Alternator
The original alternators in these Blazers were made by Delco-Remy, which is now part of ACDelco. Aftermarket parts offer a range of options from direct replacements to high-performance upgrades.
Brand Tiers for Your Blazer
- OEM-Style Replacements (Good): For a stock restoration, brands like ACDelco and Remy are excellent choices. They are built to original specifications and are a natural fit for a GM vehicle.
- Quality Aftermarket (Better): Brands like Bosch and WAI Global are known for solid engineering and quality control. WAI Global, for instance, often includes individual test results with their new units.
- Performance & High-Output Upgrades (Best for Modified Trucks): If you've added accessories like electric fans, a powerful stereo, or off-road lights, a high-output alternator is a smart upgrade. Powermaster is a very popular choice in the classic truck community for high-amperage alternators (100 amps or more) that provide more power at idle. Proform also offers performance-oriented options.
- Value-Oriented Options: Brands like BBB Industries and MPA often provide remanufactured units that offer a cost-effective solution for a daily driver.
What is a One-Wire Alternator?
Many performance alternators, like some from Powermaster, are sold as "one-wire" units. These simplify the wiring by only requiring a single wire connection from the alternator's battery post to the battery. This is a popular modification for custom builds and engine swaps, but it's important to follow the manufacturer's instructions for proper installation.
🎬 Follow this walkthrough for a clean one-wire alternator installation.Cost of a New Aftermarket Alternator
The price you pay will depend on the brand, amperage, and whether the part is new or remanufactured.
| Part Type | Estimated Cost |
|---|---|
| New Aftermarket | $39.60 - $262.86 |
| Remanufactured Aftermarket | $40 - $150 |
| High-Output Aftermarket | $150 - $265+ |
| Shop Labor for Installation | $100 - $200 |
Frequently Asked Questions
Do I need a high-output alternator?
If your Blazer is mostly stock, a standard-output alternator (around 63 amps) is fine. However, if you have added modern electrical accessories like an electric cooling fan, a winch, powerful off-road lights, or a high-wattage sound system, a high-output alternator (100 amps or more) is highly recommended to keep up with the demand and prevent battery drain.
How do I know for sure if I have an external or internal regulator?
Look for the voltage regulator. It's a small metal box (about 3x4 inches) with a wiring plug, typically mounted on the firewall on the passenger side. If you have this box, you have an externally regulated system. If you don't, and the wiring goes directly to the alternator, it's internally regulated. The plug shape on the alternator itself is also a key identifier.
Should I buy a new or remanufactured alternator?
New alternators contain all-new components. Remanufactured units are disassembled, inspected, and have their worn components replaced. For a classic vehicle, a quality remanufactured unit from a reputable brand like ACDelco or Bosch is often a perfectly reliable and cost-effective choice. High-performance brands like Powermaster and WAI Global typically offer new units.
Is replacing the alternator a DIY job?
Yes, for most owners with basic tools. The alternator on these Blazers is usually mounted on the top of the engine and is easy to access. The process involves disconnecting the battery, loosening the belt tension, removing a couple of bolts, and swapping the unit. It's considered a straightforward repair.
Helpful Videos
Technical Specifications
OEM Part Numbers: Delco-Remy 10DN (External Regulator) Delco-Remy 10SI (Internal Regulator) Delco-Remy 12SI (Internal Regulator)
Voltage: 12V, Amperage: 37-63 Amps (Stock), Regulator: External (pre-1973) or Internal (1973+), Pulley: Single V-Groove
