1970-1974 Chevrolet Impala Headlight Switch Guide
Don't get left in the dark—understand the symptoms of a failing headlight switch and how to choose the right replacement for your classic Impala.
- Symptoms like flickering headlights or dead dash lights strongly point to a failing headlight switch.
- This is a DIY-friendly repair; the main trick is finding the small release button on the switch body to remove the knob and shaft.
- Always inspect the wiring connector for melting or corrosion when replacing the switch.
- If only high or low beams are out, check the floor-mounted dimmer switch before replacing the main headlight switch.
Is Your Impala's Headlight Switch Failing?
A faulty headlight switch on a classic car like the 1970-1974 Impala can cause confusing and dangerous problems. Because these switches handle a significant electrical load, they can wear out over time. The internal contacts can corrode or burn, leading to poor connections and unpredictable behavior. Here are the most common signs that your switch needs attention:
🎬 Watch this guide to help diagnose a failing headlight switch.- Flickering or Intermittent Headlights: Your headlights may flash on and off while driving. This is often caused by a worn-out internal circuit breaker in the switch overheating from high resistance or a short.
- Headlights Don't Turn On: You might get parking lights but no headlights, or no lights at all. This can point to a completely failed switch.
- Dashboard Lights Don't Work or Dim: If your instrument panel is dark, the dimmer part of the switch (the part that twists) may have failed. Sometimes, wiggling or turning the knob might make them flicker, which points to a bad switch.
- Dome Light Issues: The dome light may stay on constantly or not turn on at all when you rotate the switch knob.
- Burning Smell: A faint plastic or electrical burning smell when you use the lights is a serious warning sign that the switch is overheating and could be a fire hazard.
Safety First: Headlight Failure is Critical
If your headlights are not working or are cutting out while you drive, the vehicle is not safe to operate at night or in poor visibility conditions. This is a critical safety issue that should be addressed immediately.
Choosing the Right Aftermarket Headlight Switch
For a 1970-1974 Impala, you won't find a new "Chevrolet" branded part at a dealership. Your options are New Old Stock (NOS), used parts, or new aftermarket parts. Aftermarket parts are the most common and reliable choice. Here’s a breakdown of the typical brand tiers available:
Brand Quality Tiers
- Premium Aftermarket (ACDelco, Standard Ignition):
- ACDelco: Often considered the original equipment (OE) supplier for GM vehicles or the closest equivalent. For a classic car, an ACDelco part is generally a top-tier choice that aims to meet original specifications.
- Standard Ignition (Standard Motor Products): A well-respected brand in the aftermarket industry known for producing quality electrical components that are reliable. Many professional mechanics trust and use their parts.
- Standard/Value (Replacement):
- Replacement: This brand typically offers the most budget-friendly option. While functional, the materials and internal components may not be as robust as premium brands, potentially leading to a shorter lifespan. For a part like a headlight switch that sees frequent use, investing in a premium brand is often worth the small extra cost.
Pro Tip: Inspect the Connector
When you replace your headlight switch, always inspect the wiring connector that plugs into it. If the old switch was overheating, it may have melted the plastic connector or corroded the metal terminals. A bad connector will cause the new switch to fail prematurely. Replace the connector if it shows any signs of damage.
Known Issues, Recalls, and Bulletins
A search of the National Highway Traffic Safety Administration (NHTSA) database and other records shows no specific recalls or Technical Service Bulletins (TSBs) for the headlight switch itself on the 1970-1974 Chevrolet Impala. However, issues with the floor-mounted dimmer switch are common on cars of this era and can sometimes be mistaken for a bad headlight switch. If your headlights work on one setting (low or high beam) but not the other, the dimmer switch is the more likely culprit.
🎬 Check this video if your classic car headlights aren't working.Headlight Switch Replacement Cost
The cost for a new aftermarket headlight switch for a 1970-1974 Impala is very reasonable. The installation is also a straightforward job that many owners can do themselves.
| Part/Service | Estimated Cost |
|---|---|
| New Aftermarket Headlight Switch | $27.74 - $68.71 |
| Shop Labor | $75 - $150 |
Frequently Asked Questions (FAQ)
Can I replace the headlight switch myself?
Yes, this is a very DIY-friendly job for most home mechanics. The process involves disconnecting the battery, removing the switch knob and shaft (which requires pressing a small release button on the switch body under the dash), unscrewing a retaining nut, unplugging the electrical connector, and then reversing the process. No special tools are usually required beyond a screwdriver or a tool to loosen the retaining nut.
Why do my dash lights work but not my headlights?
The headlight switch has separate internal circuits for different functions. It's possible for the part of the switch that controls the headlights to fail while the part that controls the dash lights still works, or vice-versa. This is a clear sign that the switch itself is the problem.
Do I need to replace the knob and shaft too?
No, most new aftermarket switches do not come with the pull knob and shaft. You will reuse your original one. To remove it, you must press a small, spring-loaded button on the body of the switch from under the dashboard while pulling the knob out.
🎬 See how to remove the headlight knob on a classic Impala.Are flickering headlights always a bad switch?
Not always, but it's the most common cause on these cars. The internal circuit breaker in the switch is designed to cycle the lights if it detects an overload or excessive heat. Other potential causes include a poor ground connection or a short in the wiring elsewhere in the car, but the switch itself is the first place to look.
Helpful Videos
Technical Specifications
OEM Part Numbers: 1995222 1995276
Pull-style switch with integrated instrument panel light rheostat (dimmer) and dome light switch. Typically features 7 or 8 terminals.
