A Guide to the 1970-1981 GMC Jimmy Automatic Transmission Detent Cable
Get your classic Jimmy to shift properly by understanding this simple but critical cable.
- A bad detent cable's main symptom is the loss of the automatic 'passing gear' when you floor the gas pedal.
- For the TH350 transmission in your Jimmy, a disconnected cable will not cause severe damage, unlike on later transmissions.
- Proper adjustment is critical for the new cable to work correctly; it must be set at wide-open throttle.
- Standard brands like ATP and Pioneer are fine for stock use, while B&M offers a more durable, performance-oriented option.
Is Your Jimmy Shifting Poorly? It Could Be the Detent Cable.
If your 1970-1981 GMC Jimmy isn’t shifting like it used to, the automatic transmission detent cable is a common and easy-to-fix culprit. This mechanical cable can stretch, break, or simply go out of adjustment over time. When it fails, you lose the "kickdown" feature for passing, and your shift timing can feel off. Since original OEM parts are virtually nonexistent for a simple wear item like this, a quality aftermarket cable is the go-to solution.
Symptoms of a Bad Detent Cable
- No Passing Gear: The most obvious sign is the truck failing to downshift when you floor the accelerator pedal.
- Incorrect Shift Points: The transmission may shift into the next gear too early and feel sluggish, or shift too late, causing the engine to rev higher than normal during gentle acceleration.
- Stiff Gas Pedal: If the cable is old, frayed, or poorly routed, it can bind and make the gas pedal feel stiff or hard to press.
A Note on Transmission Type
Your 1970-1981 Jimmy most likely has a Turbo-Hydramatic 350 (TH350) or the heavy-duty TH400 automatic transmission. This guide is specific to them. The detent cable on these transmissions is for kickdown only. It is NOT the same as a Throttle Valve (TV) cable on later transmissions like the 700R4, where improper adjustment can quickly destroy the transmission.
Choosing the Right Aftermarket Detent Cable
For a vintage truck like the Jimmy, aftermarket is your main option. The brands available fall into two main tiers:
- Standard Replacement (ATP, Pioneer Cable): These brands create direct-fit replacement cables designed to function like the original. They are affordable and typically easy to install. For a stock truck used for regular driving, a cable from ATP or Pioneer is a perfectly good choice. However, some user forums mention that quality can be inconsistent with aftermarket plastics and fittings.
- Performance / Heavy-Duty (B&M): B&M is known for performance and heavy-duty parts. Their cables are often universal, made with higher-quality materials like braided stainless steel, and are highly adjustable. A B&M cable is a great upgrade if you use your Jimmy for towing, off-roading, or have a modified engine. It may cost a bit more and require more careful initial setup than a direct-fit cable.
Typical Replacement Costs
Replacing the detent cable is an affordable repair. The part itself is inexpensive, and labor is minimal.
| Item | Estimated Cost |
|---|---|
| New Aftermarket Detent Cable | $27.94 - $47.78 |
| Shop Labor | $100 - $200 |
| Total Estimated Cost | $128 - $248 |
Pro Tip: Adjustment is Everything
Properly adjusting the new cable is just as important as installing it. The most common method for a stock-style cable is to install it, press the adjustment lock tab on the bracket, have a helper press the gas pedal all the way to the floor, and then release the tab. This ensures the cable is fully pulled only at wide-open throttle. An improperly adjusted cable will not work correctly.
Frequently Asked Questions (FAQ)
What exactly does the detent cable do?
It is a mechanical link that tells your transmission to downshift for more power when you press the gas pedal all the way down. It's also called a kickdown cable.
Can I drive my Jimmy with a broken detent cable?
Yes, you can. The transmission will still shift through its gears for normal driving. However, you will not have an automatic passing gear, and you may notice sluggish performance. You will have to downshift manually using the column shifter if you need a burst of power.
Is this a difficult part to replace myself?
No, this is a great DIY job for a beginner. It typically requires basic hand tools to unbolt the cable from the transmission and disconnect it from the carburetor linkage. The most common issue is gaining access to the connection point on the transmission. The job usually takes about an hour.
Are there any recalls for the detent cable on my GMC Jimmy?
No, there are no recalls or specific Technical Service Bulletins (TSBs) from GMC or the NHTSA for the automatic transmission detent cable on 1970-1981 models. This is a standard maintenance part that wears out over time.
Technical Specifications
The critical specification is ensuring the cable is compatible with a GM Turbo-Hydramatic 350 (TH350) or TH400 transmission. Length and bracket style must match the vehicle's engine and carburetor setup.
