Guide to the 1971-1974 Pontiac GTO Ignition Switch
Having trouble starting your GTO? The ignition switch could be the problem.
- Verify if your GTO has a tilt or non-tilt steering column before ordering, as the switches are different.
- Symptoms like 'no-crank' or 'start-and-stall' are strong indicators of a failed ignition switch.
- Aftermarket brands like Standard Ignition are a reliable choice for this part.
- A bad switch can be a safety hazard if it causes the engine to stall while driving.
Is Your GTO's Ignition Switch Failing?
The ignition switch on a classic Pontiac GTO is a mechanical part with electrical contacts that wears out over time. Heavy keychains can also speed up wear. If your GTO is having trouble starting, the ignition switch is a likely suspect, especially if the battery and starter are good. Watch for these common signs of failure.
🎬 Watch: A visual guide to signs and symptoms of failure.Top 5 Failure Symptoms
- No Crank, No Start: You turn the key and nothing happens. The starter motor is silent, though you might see the dash lights dim. This can happen when the electrical contacts inside the switch are too worn to send power to the starter.
- Starts and Immediately Stalls: The engine fires up but dies as soon as you let go of the key. This happens when the switch makes contact in the 'START' position but fails in the 'RUN' position.
- Intermittent Starting: Sometimes the car starts, sometimes it doesn't. You might have to jiggle the key to get it to work. This points to worn or loose connections inside the switch.
- Accessories Don't Work: Your radio, wipers, or heater fan might not turn on, or they may cut out while driving. This can happen if the 'Accessory' or 'RUN' circuits in the switch are failing.
- Engine Stalls While Driving: A worn ignition switch can lose connection if you hit a bump, causing the engine to shut off without warning. This is a serious safety issue.
Is It the Switch or Something Else?
Starting problems can also come from a bad neutral safety switch, a weak battery, or poor wiring connections. A common issue on these GM cars is a delay before cranking, which often points to high resistance in the wiring to the starter solenoid. If you can start the car by jumping the solenoid with the key in the 'ON' position, the ignition switch is a strong possibility.
Choosing the Right Aftermarket Ignition Switch
For a 1971-1974 GTO, you won't find a new OEM ignition switch from GM. Aftermarket is your only option for a new part. The good news is that these switches were used on many GM cars, so they are widely available and affordable. Quality can vary, so it's best to stick with a known brand.
| Brand Tier | Brands | Quality & Price Assessment |
|---|---|---|
| Better | Standard Ignition (Standard Motor Products) | Standard is a well-regarded aftermarket brand with a long history. Their parts are generally known for good fit and function. Customer reviews are mostly positive, citing good quality and value. They use copper alloy conductors for good electrical performance. |
| Good | Rostra Powertrain | Rostra produces a wide range of vehicle electronics and claims their parts meet or exceed original specifications. They also use copper alloy conductors and test their parts for reliability. While not as well-known as Standard for ignition parts, they are a solid choice. |
| Economy | Replacement / Store Brands | These are generic parts that offer the lowest price. Quality can be inconsistent. While they may work fine, some users of similar economy parts report early failure or fitment issues. They are a budget-friendly option if immediate cost is the main concern. |
Tilt vs. Non-Tilt Column
The most common ordering mistake is getting the wrong switch for your steering column. GM used different ignition switches for cars with a tilt steering wheel and those without. Always verify which column your GTO has 🎬 See this overview of older style GM column mounted switches. before ordering a new switch.
Frequently Asked Questions
Are there any recalls on the 1971-1974 GTO ignition switch?
No, there are no specific recalls from the NHTSA for the ignition switch on the 1971-1974 Pontiac GTO. Major GM ignition switch recalls in later years, like in 2014, involved much newer vehicles and different switch designs.
Is the ignition switch the same as the lock cylinder?
No. The ignition lock cylinder is the mechanical part you put your key into. The ignition switch is a separate electrical component located further down on the steering column. A rod connects the lock cylinder to the switch. Turning the key moves the rod, which activates the switch.
How difficult is it to replace the ignition switch?
For a 1970s GM car, replacing the ignition switch is usually straightforward for a DIY mechanic. It involves removing the lower dash panels to access the switch on the steering column. The switch is typically held on by two small screws. The main challenge is working in a tight space under the dashboard.
🎬 Watch: Step-by-step ignition switch replacement for 1970s GM cars.Can a bad ignition switch drain my battery?
Yes. If the switch fails to completely shut off the 'Accessory' or 'RUN' circuits when you turn the car off, it can leave systems powered on and drain the battery. A sign of this could be the 'GEN' or 'OIL' light staying on after the engine is stopped.
Helpful Videos
Technical Specifications
Actuated by a rod connected to the ignition lock cylinder. Mounts to the steering column. Available in versions for tilt and non-tilt steering columns.
