Engine Coolant Thermostat Guide for 1978-1983 Jaguar XJ6
Preventing overheating in your classic XJ6 starts with choosing the correct engine coolant thermostat.
- You MUST use a 'bypass' style thermostat; a standard thermostat will cause overheating.
- Be extremely careful with the housing bolts, as they are famous for seizing and breaking.
- A stuck-closed thermostat is a critical failure that requires you to stop driving immediately to prevent engine damage.
- Always install the new thermostat with the jiggle pin/air bleed hole at the 12 o'clock position.
Symptoms of a Failing Thermostat
The cooling system on the Series II and Series III XJ6 is a known weak point, and a faulty thermostat is a common culprit for problems. Ignoring these signs can lead to severe engine damage. Watch for these symptoms:
- Engine Overheating: If the thermostat sticks in the closed position, coolant can't get to the radiator. The temperature gauge will climb into the red, and you may see steam from the engine bay. This is the most dangerous failure mode.
- Engine Running Too Cool: A thermostat stuck open will constantly circulate coolant, preventing the engine from reaching its proper operating temperature. The temperature gauge will stay low, fuel economy will suffer, and the heater will only blow lukewarm air.
- Erratic Temperature Gauge: 🎬 Watch: How to verify if your temperature gauge is accurate. The temperature needle may swing from cool to hot and back again. This indicates the thermostat is struggling to regulate coolant flow properly.
- Coolant Leaks: Increased pressure from a stuck-closed thermostat can force coolant out of the thermostat housing gasket or nearby hoses. You might find puddles of green or yellow fluid under the front of the car.
Choosing the Right Aftermarket Thermostat
For a sensitive engine like the Jaguar XK, not all aftermarket thermostats are created equal. The key is to use a thermostat with the correct "bypass" design. This design features a secondary plate or "foot" that closes off a coolant bypass passage as the main valve opens. Using a standard thermostat without this feature will allow hot coolant to continuously recirculate within the engine, leading to overheating, especially in traffic.
Aftermarket Brand Quality Tiers
| Tier | Brands | Assessment |
|---|---|---|
| Recommended | Gates | Gates is frequently recommended in owner forums. In a comparison of multiple brands, Gates was noted as being one of the few that opened far enough to properly block the critical bypass port 🎬 See why the bypass design is vital for cooling performance. on a similar Jaguar engine. Given the low cost of the part, it is the safer choice. |
| Standard / Use with Caution | Beck Arnley, Motorad | Beck Arnley sources parts to match OEM specifications, which is generally good, but quality can be inconsistent. Motorad is a large manufacturer that supplies many brands, but some forum users have found their products to be dimensionally different from the required Jaguar-specific design. If using these brands, verify it is the correct bypass style for the XK engine. |
A Word on Installation
While replacing the thermostat is mechanically simple, the bolts on the housing are notorious for seizing and breaking, especially the long rear bolt. It is highly recommended to soak the bolts in penetrating oil for several days before attempting removal. If a bolt breaks, it can turn a simple job into a major repair. Proceed with caution.
🎬 Watch: Pro tips for removing those stubborn, frozen housing bolts.Frequently Asked Questions (FAQ)
What temperature thermostat should I use for my 1978-1983 XJ6?
The standard and recommended thermostat temperature rating for the 4.2L XK engine is 88°C (or 190°F). Using a cooler thermostat will cause the engine to run too rich and inefficiently.
Do I need to replace the gasket when I replace the thermostat?
Yes, absolutely. Always install a new thermostat housing gasket to prevent leaks. It is also a good time to inspect the small bypass hose located under the thermostat housing, as it can be difficult to access otherwise.
What is a "jiggle pin" and why is it important?
The jiggle pin is a small valve on the thermostat's flange that allows trapped air to bleed out of the cooling system. When installing the new thermostat, this pin must be positioned at the very top (the 12 o'clock position) to be effective.
Can I just remove the thermostat completely?
No. Running without a thermostat is a bad idea. The engine will never reach its proper operating temperature, leading to poor performance, increased engine wear, and terrible fuel economy. Furthermore, on an XK engine, it leaves the coolant bypass port wide open, which can cause overheating.
Helpful Videos
Technical Specifications
Required Design: Bypass type with foot/sleeve Standard Temperature: 88°C / 190°F
