Dodge Ramcharger Ignition Switch Guide (1979-1993): Symptoms and Replacement
Don't get stranded—here’s what to know when your Ramcharger’s ignition switch starts to fail.
- A 'no crank, no start' condition is the most common symptom of a bad ignition switch on this truck.
- This is a DIY-friendly repair that does not require replacing your keys or lock cylinder.
- Always inspect the wiring connector for melting or burn marks, as this is a common related failure.
- Choosing a quality aftermarket brand like Standard Ignition or Rostra is recommended for reliability.
Is Your Ignition Switch Failing?
On these classic Ramchargers, the ignition switch is a common failure point that can mimic other problems. Before you blame the battery or starter, check for these classic signs. A failing switch can leave you with a truck that won't start or, worse, cause it to shut off unexpectedly.
🎬 Watch: A breakdown of common ignition switch failure symptomsCommon Symptoms of a Bad Ignition Switch
- No Crank, No Start: You turn the key and get nothing but silence, or maybe a single click. All the lights on the dash might work, but the engine won't turn over. This happens when the switch fails to send power to the starter relay.
- Intermittent Electrical Issues: The radio cuts out, the dash lights flicker, or the heater fan stops working and then starts again. This points to worn internal contacts inside the switch that can't maintain a steady connection.
- Key Feels Loose or 'Jiggly': While often related to the lock cylinder, a worn switch actuator rod can cause a sloppy feeling. You might find yourself needing to jiggle the key to get accessories to work or to start the truck.
- Engine Stalls After Starting: The engine starts but dies as soon as you release the key from the 'START' to the 'ON' position. This indicates a failure in the 'run' circuit of the switch.
Check the Connector First
High electrical loads, especially from the heater's blower motor, can cause the ignition switch connector to overheat and melt over time. When you replace the switch, always inspect the wiring harness connector for signs of charring, melting, or discoloration. A damaged connector will ruin a new switch quickly.
Choosing the Right Aftermarket Ignition Switch
For a vehicle from this era, new OEM parts are generally not available. The good news is that the aftermarket offers several reliable options. The switch is located on the steering column, separate from the key and lock cylinder.
🎬 See how the switch integrates with the steering column assembly| Brand Tier | Brands | Quality & Cost Assessment |
|---|---|---|
| Good | Standard Ignition (SMP), Rostra Powertrain | These brands are well-known in the aftermarket and are considered reliable, OE-style replacements. They often feature copper conductors for better performance and are widely available. While quality control issues can occasionally happen with any brand, they represent a good balance of price and reliability. |
| Economy | Replacement (Store Brands) | These are the most budget-friendly options. They will get your truck running, but may use less robust materials, potentially leading to a shorter lifespan. If you're on a tight budget, they work, but a mid-tier brand often provides better long-term value. |
Frequently Asked Questions
Is there a recall on the ignition switch for my Ramcharger?
No, there are no active recalls specifically for the 1979-1993 Dodge Ramcharger ignition switch. A recall for overheating ignition switches was issued for the next-generation 1995 Dodge Ram, but it does not officially cover this model range. However, the symptoms described in that recall (overheating from high blower motor use) are still relevant to these older trucks.
Do I need to replace my keys or lock cylinder?
No. On the 1979-1993 Ramcharger, the ignition switch is a separate component from the lock cylinder where you insert your key. The switch is mounted further down the steering column and is activated by a metal rod connected to the lock cylinder. You will not need new keys to replace only the switch.
Is this a difficult part to replace myself?
For a DIY mechanic, this is a very manageable job. It typically takes about an hour. The main challenge is the awkward position, as you'll be working under the dashboard. The process involves removing the lower dash panels and steering column covers to access the switch, which is usually held on with a couple of Torx screws.
🎬 Follow this step-by-step walkthrough to replace the switch yourselfWhy do my radio and heater fan not work, but the truck starts?
This is a classic sign of a failing ignition switch. The switch has multiple electrical contacts inside to power different systems ('accessory,' 'run,' 'start'). It's possible for the 'run' circuit that powers your radio and heater to fail, while the 'start' circuit that cranks the engine still works, or vice-versa.
Helpful Videos
Technical Specifications
Located on the steering column, activated by a rod from the lock cylinder. Does not include lock cylinder or keys.
