Your Guide to the 1980-1990 GMC Jimmy Brake Light Switch
Fixing common brake light problems on your classic square body Jimmy starts with this critical, easy-to-replace part.
- A faulty brake light switch is a critical safety hazard; do not drive the vehicle if your brake lights are not working.
- Replacement is a simple, fast, and inexpensive DIY job that most owners can perform with basic tools.
- Ensure you purchase the correct switch for your Jimmy's options, as models with and without cruise control may use different parts.
- Before replacing the switch, always check the simple things first: fuses and bulbs.
Is Your Jimmy's Brake Light Switch Failing?
A bad brake light switch is a serious safety risk and a common point of failure on older trucks like the 1980-1990 GMC Jimmy. Because it is a simple mechanical part that gets used every time you drive, it eventually wears out. If your brake lights don't work, other drivers won't know you're stopping. If they get stuck on, they can drain your battery and confuse drivers behind you.
Symptoms of a Bad Brake Light Switch
- Brake Lights Don't Work: The most obvious sign. Before blaming the switch, always check the bulbs and the fuse first.
- Brake Lights Stay On: The switch can fail in the closed or 'on' position, leaving the lights on even when 🎬 Watch how to fix brake lights that stay on. the truck is off and draining the battery. This can happen if the switch is broken or misaligned.
- Intermittent Brake Lights: The lights might flicker or only work when you press the pedal hard. This points to worn internal contacts.
- Cruise Control Won't Work or Disengage: On models with cruise control, a faulty brake light switch can prevent the system from working at all or, more dangerously, from turning off when you brake.
Pro Tip: On these GM trucks, brake light power runs through the turn signal switch in the steering column. If your turn signals work but your brake lights don't, the problem is often the brake light switch. However, a faulty turn signal or hazard switch can sometimes cause strange brake light issues.
Choosing the Right Aftermarket Switch
For a simple part like this, you don't need to hunt down an expensive OEM part. Quality aftermarket brands offer excellent performance and value. The key is choosing a reputable brand over the cheapest option available.
- Premium Brands (e.g., Standard Ignition): Standard Motor Products (SMP) is a well-respected manufacturer known for making parts that meet or exceed original specifications. They use quality materials like copper alloy conductors and robust designs to ensure a long service life. For a critical safety part, a brand like Standard Ignition is a reliable choice.
- Standard Tier Brands (e.g., Rostra Powertrain): Rostra is a known manufacturer of automotive electronics, including switches and sensors. They are certified and produce parts for both original equipment and the aftermarket. A Rostra switch is a solid, dependable option for a daily driver or restoration.
- Economy Brands (e.g., Skyward): Budget-friendly brands offer a low-cost alternative. While functional, they may not have the same long-term durability or rigorous testing as premium brands. For a part this inexpensive and easy to replace, most owners will benefit from the peace of mind provided by a standard or premium brand.
Cost of Brake Light Switch Replacement (1980-1990 GMC Jimmy)
| Part Type | Part Cost | Shop Labor Cost | Total Estimated Cost |
|---|---|---|---|
| New Aftermarket | $5.40 - $29.97 | $40 - $100 | $45 - $130 |
| New OEM (GM) | $18 - $40 | $40 - $100 | $58 - $140 |
Frequently Asked Questions (FAQ)
Where is the brake light switch located on my GMC Jimmy?
The brake light switch is mounted on a bracket attached to the brake pedal support, located up under the dashboard. 🎬 Learn more about brake pedal assembly and maintenance. You will see it clipped onto the brake pedal arm itself. It's in a tight space, so a flashlight will help you find it.
Is replacing the brake light switch a difficult job?
No, this is a very feasible DIY job for most owners. It typically requires no special tools, though working in the tight space under the dash can be uncomfortable. The process involves unplugging the electrical connector, removing a retaining clip, and sliding the switch off the pedal arm. 🎬 See a step-by-step guide for replacing the switch. Most people can do it in under 30 minutes.
Do I need a different switch if I have cruise control?
Yes, often. Trucks with cruise control may have a switch with additional electrical contacts or a second, separate switch for the cruise control system. It is critical to buy the correct part for your truck's specific options. Always verify the part fitment before purchasing.
My new switch is installed, but the lights still don't work. What's next?
First, double-check that you reconnected the electrical plug securely. Then, re-check the fuse and the bulbs. If those are good, the problem may be in the wiring, a bad ground, or the multifunction (turn signal) switch in the steering column, as the brake light circuit passes through it.
Were there any recalls for the 1980-1990 GMC Jimmy brake light switch?
No, searches of the National Highway Traffic Safety Administration (NHTSA) database did not show any recalls specifically for the brake light switch on the 1980-1990 GMC Jimmy. Recalls found were for much newer GM vehicles and different brake system components.
Helpful Videos
Technical Specifications
OEM Part Numbers: 15607063 15602652 93801734 12450076
The switch is a mechanical plunger-style switch that mounts to the brake pedal support bracket. It is activated by the movement of the brake pedal arm. Models with cruise control may have a switch with more terminals.
