Toyota Tercel Brake Light Switch Guide: 1980-1991 Models
Everything you need to know before replacing your 1980-1991 Toyota Tercel's brake light switch.
- Before buying a new switch, check for a broken or missing plastic stopper on the brake pedal arm; this is a common cause for brake lights staying on.
- A faulty brake light switch is a critical safety issue that should be addressed immediately.
- Replacement is simple for a DIYer, but proper adjustment of the new switch is essential for it to work correctly.
- Reputable aftermarket brands like Beck Arnley or Standard Ignition offer a reliable and cost-effective alternative to OEM for this part.
Is Your Tercel's Brake Light Switch Failing?
A brake light switch failure is a major safety concern. The symptoms are usually straightforward and easy to spot. Because this is a simple mechanical switch, failure is often sudden.
- Brake Lights Don't Turn On: This is the most dangerous symptom. The internal contacts of the switch have failed, and it can no longer complete the electrical circuit.
- Brake Lights Stay On: The switch might be stuck in the 'on' position, or the plunger may be broken. This will drain your battery and confuse drivers behind you.
- Intermittent Brake Lights: The lights may flicker or only work sometimes, indicating worn internal components.
Check This Before Buying a New Switch!
🎬 Watch: Why you should check the pedal stopper first.A common issue on older Toyota vehicles is the failure of a small plastic or rubber pad on the brake pedal arm. This pad is what makes contact with the switch's plunger. Over time, it can become brittle and crumble, falling out of place. When this happens, the plunger is no longer pressed in, and the brake lights will stay on constantly, even with the car off. Look above your brake pedal to see if a small plastic plug is missing from the metal arm where it should touch the switch. This is a much cheaper and easier fix than replacing the entire switch.
Choosing the Right Aftermarket Brake Light Switch
For a vehicle like the 1980-1991 Tercel, a high-quality aftermarket switch is a perfectly reliable and cost-effective choice. The original OEM parts can be expensive and may not offer a significant advantage for this simple component. Here’s a breakdown of available brands based on general market reputation.
- Premium Aftermarket (Recommended): Brands like Beck Arnley and Standard Ignition (SMP) have a strong reputation for quality and reliability. Beck Arnley specializes in parts for import vehicles and often sources components from OEM manufacturers. Standard Ignition is a long-standing, trusted name in automotive electronics with positive user reviews.
- Standard Aftermarket: Brands like Facet and Rostra Powertrain offer a more budget-friendly option. Facet is a large European manufacturer, and while many of their parts are reliable, some user reviews mention occasional fitment issues on other vehicle models. These brands can be a good value, but for a critical safety part, sticking with a premium aftermarket brand is often worth the small extra cost.
Brake Light Switch Replacement Cost for 1980-1991 Toyota Tercel
The cost to replace the brake light switch is very reasonable, especially if you do it yourself. The part itself is inexpensive, and labor is minimal.
| Part Type | Part Cost | Shop Labor Cost |
|---|---|---|
| New Aftermarket | $13.52 - $55.79 | $50 - $100 |
| New OEM | $40 - $65 | |
| Used OEM | $10 - $25 |
Frequently Asked Questions
Where is the brake light switch located on a 1980-1991 Tercel?
The brake light switch is located in the driver's footwell, mounted on a bracket above the brake pedal arm. You will need to look up under the dashboard to see it. It is a small, threaded sensor with an electrical connector plugged into it.
Can I replace the brake light switch myself?
Yes, this is a very DIY-friendly job for most people. It typically requires only basic hand tools, like a 14mm wrench, to loosen the lock nut. The process involves disconnecting the electrical plug, unscrewing the old switch, screwing in the new one, and adjusting it to the correct depth before tightening the lock nut. The most difficult part is often just working in the tight space under the dashboard.
🎬 See this walkthrough of a Toyota brake switch replacement.Does the new brake light switch need to be adjusted?
Yes, adjustment is critical. The switch is threaded and held in place by a lock nut. You must screw it in or out until the plunger is fully depressed when the brake pedal is not being touched, but is released immediately when you begin to press the pedal. Incorrect adjustment can cause the lights to stay on, not turn on, or turn on with a delay.
🎬 Watch: How to properly adjust your new stoplight switch.My brake lights are stuck on. Is it always the switch?
Not always. Before replacing the switch, check for a missing or broken plastic stopper on the brake pedal arm itself. This small, inexpensive part can crumble with age. If it's gone, the pedal arm won't make contact with the switch plunger, causing the lights to stay on. This is a very common problem on older Toyotas.
Helpful Videos
Technical Specifications
OEM Part Numbers: 84340-32010 84340-30040 84340-22071 84340-12021 84340-22060 84340-36030
Typically a 2-terminal, normally open plunger-style switch. It is threaded for adjustable installation depth and secured with a lock nut.
