Ford Escort Headlight Switch Guide for 1981-1986 Models
If your Escort's headlights are flickering or have stopped working, the headlight switch is a likely culprit.
- A failing headlight switch is a very common problem on 1981-1986 Ford Escorts, often causing flickering or dead lights.
- Always inspect the wiring connector for melting or charring; replace it if any damage is found to protect the new switch.
- Standard Ignition and Rostra are reliable aftermarket brands for this repair.
- For a long-term fix, consider adding a headlight relay harness to take the electrical load off the dashboard switch.
Signs of a Failing Headlight Switch
On the first-generation Ford Escort, the headlight switch is a very common failure point. Because the original design routes all lighting power through the switch itself, it can overheat and fail. This can sometimes melt the switch or the plastic connector that plugs into it. Look for these classic signs of a bad switch:
- Flickering or Intermittent Lights: Your headlights, taillights, or dash lights may flicker or cut out while driving. You might be able to make them come back on by wiggling the switch.
- Total Light Failure: The most obvious symptom is when your headlights and other exterior lights do not turn on at all.
- Partial Failure: Sometimes only one function of the switch fails. For example, your headlights might work, but your dashboard lights or taillights do not.
- High Beams Don't Work Correctly: You may have trouble activating the high beams, or they might not stay engaged.
- Burning Plastic Smell: A distinct smell of hot or burning plastic from the dashboard area is a serious sign that the switch or its wiring is overheating and needs immediate attention.
- Dimmer Doesn't Work: If you can no longer adjust the brightness of your instrument panel lights, the rheostat inside the switch has likely failed.
Inspect the Wiring Connector!
When you replace the headlight switch, it is critical to inspect the plastic wiring connector that plugs into it. These are known for melting or showing signs of charring due to heat. If you see any damage, you must also replace the connector pigtail to prevent the new switch from failing prematurely.
Choosing the Right Aftermarket Headlight Switch
Since original Ford (OEM) parts for a 1981-1986 Escort are extremely rare and often only available as used or reconditioned parts, a new aftermarket switch is the most practical choice. For this specific part, quality is important because a cheap switch can fail quickly or create a fire hazard.
- Standard Ignition (Standard Motor Products): This is a well-regarded aftermarket brand known for producing reliable electronic components that meet or exceed OEM specifications. They use quality materials like copper alloy conductors to ensure good electrical performance. For an older vehicle like the Escort, Standard is a trusted, go-to option.
- Rostra Powertrain: Rostra is another established manufacturer that produces a wide range of automotive electronics, including parts for original equipment manufacturers. Their switches are also built with quality materials and are 100% tested for performance and reliability, making them a solid choice.
Pro Tip: To make your new headlight switch last longer, consider installing a headlight relay harness. This inexpensive kit reroutes the high-current power for the headlights through relays, taking the load off the new dashboard switch and preventing it from overheating.
Headlight Switch Replacement Cost
Replacing the headlight switch on a 1981-1986 Escort is an affordable repair. The parts themselves are not expensive, and if you have it done professionally, the labor time is minimal.
| Part Type | Estimated Cost |
|---|---|
| New Aftermarket Switch | $47 - $90 |
| Shop Labor | $50 - $100 |
| Total Estimated Cost | $97 - $190 |
Cost estimates are for the part and professional installation. Your final cost may vary depending on your location and the specific repair shop.
Frequently Asked Questions
Are there any recalls for the 1981-1986 Escort headlight switch?
No, a search of the National Highway Traffic Safety Administration (NHTSA) database shows no specific recalls or technical service bulletins (TSBs) for the headlight switch on the 1981-1986 Ford Escort. While Ford has issued recalls for headlight-related issues on other models, none apply to this specific vehicle and part.
Can I replace the headlight switch myself?
Yes, this is a very feasible DIY job for most home mechanics. The process typically involves removing the steering column shrouds to access the switch, disconnecting the electrical connector, and removing a few screws. The difficulty is low and it can usually be done in under an hour.
Do I need any special tools?
No special tools are required. Basic hand tools like a screwdriver set should be sufficient to perform the replacement.
My lights still flicker after replacing the switch. What else could it be?
If a new switch doesn't solve the problem, check for other common electrical issues. This includes inspecting the wiring and connector for damage, checking the headlight relay, ensuring the fuse is good, and verifying that the vehicle's grounding points are clean and secure, as Fords of this era are sensitive to bad grounds.
🎬 Watch this video for more on troubleshooting Ford electrical problems.Helpful Videos
Technical Specifications
OEM Part Numbers: E6FZ-11654-A E0AZ11654C E0AB11654CA E0SB11654BB E0SB11654BC
7-Terminal Blade-Type Switch
