Dodge D150 Ignition Coil Guide for 1983-1993 Models
Solve stalling, no-start, and rough running issues by choosing the right ignition coil for your classic Dodge truck.
- A failing ignition coil on a D150 commonly causes stalling, no-start conditions, or a rough idle.
- Replacement is a very simple DIY job that takes less than 30 minutes with basic tools.
- Upgrading to a performance coil from a brand like MSD is a popular and effective modification for these trucks.
- Before replacing the coil, always check for power from the ASD relay and inspect the distributor cap and rotor for wear.
Is Your Ignition Coil Failing? Common Symptoms on a D150
A bad ignition coil on these classic Dodge trucks can cause a range of frustrating problems. Because the entire engine relies on this single coil, a failure can bring everything to a halt. Watch for these signs:
- Engine Stalling: The truck may run for a few minutes and then suddenly die as the coil overheats and fails. It might restart after cooling down, only to repeat the cycle.
- No-Start Condition: You'll hear the engine crank over, but it won't fire up. This happens 🎬 Watch this diagnosis and repair of a D150 no-start condition. when the coil produces no spark at all.
- Rough Idle and Misfiring: The engine may shake, shudder, or sound uneven at a stop. This can be caused by a weak or inconsistent spark from a failing coil.
- Poor Acceleration and Power Loss: If the coil isn't delivering enough voltage, the spark will be too weak to burn the fuel efficiently, resulting in sluggish performance and trouble getting up to speed.
- Visible Weak Spark: When testing, you might see a very small, thin, blue spark instead of a bright, thick, white or blue one. A weak spark may not be enough to start the engine under compression.
Check Other Parts First
A no-spark condition on these trucks isn't always the coil. Before replacing it, check the distributor cap and 🎬 Watch this guide on replacing the distributor cap and rotor. rotor for cracks and corrosion. Also, listen for the fuel pump to prime for a couple of seconds when you turn the key to the 'On' position. A faulty Auto Shut Down (ASD) relay can also cut power to the coil and fuel pump, mimicking a coil failure.
Choosing the Right Aftermarket Ignition Coil
For a vehicle from this era, original Mopar parts are scarce and often unnecessary. The aftermarket offers excellent options that range from standard replacements to performance upgrades. The key is to choose a reputable brand.
Performance Upgrade Coils
These coils are designed to produce a higher voltage spark than the original. They are a popular upgrade for D150 owners looking for improved throttle response and a smoother idle. They are often paired with new spark plug wires and a quality distributor cap and rotor.
- MSD: The MSD Blaster series is a very common and well-regarded upgrade for this generation of Dodge truck. Owners often report a noticeable improvement in engine performance.
OEM-Quality Replacement Coils
These brands are known for producing reliable parts that meet or exceed the original factory specifications. They are a safe bet for a daily driver or a stock restoration.
- Standard Ignition (SMP): A long-trusted name in ignition components. Their 'Blue Streak' line is considered a premium, heavy-duty option.
- Delphi: A major OEM supplier with a strong reputation for quality and reliability in the aftermarket.
- Bosch: Another top-tier brand known for excellent engineering and durability.
- NGK: While famous for spark plugs, NGK also produces high-quality ignition coils that are a dependable choice.
Standard & Economy Coils
These brands offer a cost-effective solution for getting your truck back on the road. They are a good fit for budget-conscious repairs.
- DriveWire, Global Parts, Spectra, Walker Products: These brands provide functional replacements at an affordable price point. While they may not have the same long-term durability reputation as premium brands, they are a viable option.
Cost of a New Ignition Coil for a 1983-1993 Dodge D150
| Part Type | Estimated Cost |
|---|---|
| New Aftermarket (Economy) | $20 - $45 |
| New Aftermarket (OEM-Quality/Performance) | $45 - $107 |
| Shop Labor for Installation | $50 - $100 |
Easy DIY Installation
Replacing the ignition coil on a D150 is one of the easiest repairs you can do. It's typically held on by two bolts and has two simple electrical connections. The entire job can usually be done in under 30 minutes with basic hand tools like a screwdriver or a small socket set.
- Disconnect the negative battery terminal.
- Unplug the two-wire electrical connector from the coil.
- Pull the main ignition wire (the thick one going to the distributor cap) off the coil tower.
- Unscrew the two mounting bolts holding the coil to its bracket.
- Install the new coil and reconnect everything in the reverse order. Applying a small amount of dielectric grease to the inside of the coil wire boot is recommended to prevent corrosion and make future removal easier.
Frequently Asked Questions
Can I upgrade my ignition coil?
Yes, upgrading is a very common modification for the 1983-1993 D150. A performance coil like an MSD Blaster can provide a stronger spark, potentially improving idle quality and throttle response. It's a simple, bolt-on upgrade.
What is the difference between an oil-filled and an epoxy-filled coil?
Traditional coils were filled with oil to help cool the internal windings. Modern replacement coils are often filled with solid epoxy. Epoxy-filled coils are generally more durable, resistant to vibration, and can be mounted in any position, whereas oil-filled coils should be mounted upright.
How do I test my D150's ignition coil?
You can perform a basic test with a multimeter. You'll measure the resistance of the primary and secondary windings. Check a repair manual for the exact specifications for your year, but generally, the primary resistance (between the two small terminals) should be very low (around 0.7-1.7 ohms), and the secondary resistance (between the positive terminal and the high-voltage tower) should be much higher (around 7,000-13,000 ohms). A reading of infinite resistance 🎬 See how to test your ignition coil using a multimeter. on either winding means the coil is bad.
What other parts should I replace with the ignition coil?
If your ignition coil has failed, it's a good time to inspect other ignition components. Consider replacing the distributor cap, rotor, and spark plug wires if they are old. These parts work together, and a failure in one can strain the others.
Helpful Videos
![No Spark Troubleshooting [Mopar Electronic Ignition with Ballast Resistor]](https://img.youtube.com/vi/RiC8OaSXMs8/mqdefault.jpg)
Technical Specifications
OEM Part Numbers: 5222849 4419452 3874010
The 1983-1993 Dodge D150 uses a single, canister-style ignition coil, which can be either oil-filled or epoxy-filled. It features a 2-pin electrical connector and a single high-tension tower for the distributor wire. Typical primary resistance is around 0.7-1.7 ohms, with secondary resistance between 7k-13k ohms.
