Chevrolet Astro Spark Plug Wire Set Guide for 1985-1995 Models
Get your Astro van running smoothly by choosing the right spark plug wires for a reliable ignition.
- Replacing spark plug wires on an Astro is difficult due to poor engine access; plan for extra time or labor costs.
- For reliability, choose OEM-quality brands like ACDelco or NGK.
- Always replace spark plugs, distributor cap, and rotor at the same time for a complete tune-up.
- Pay close attention to wire routing and use all factory clips to prevent heat damage and misfires.
Is Your Astro Van Running Rough? It Could Be the Spark Plug Wires.
If your Chevrolet Astro is experiencing symptoms like a rough idle, hesitation when you accelerate, or a noticeable drop in power and fuel economy, the spark plug wires could be the culprit. These wires live in a harsh environment under the hood and eventually wear out. Visible signs of damage include cracks, melting, or burn marks on the wire's outer insulation. Sometimes, you can even hear a ticking or clicking noise from arcing electricity, or see a spark jump to a metal engine part in the dark.
Engine Access is a Challenge
Be aware that replacing spark plugs and wires on a Chevrolet Astro is more difficult than on many other vehicles due to tight engine bay access. The job often requires removing the interior engine cover (the "doghouse") and sometimes even the front wheels 🎬 Watch this complete walkthrough for accessing and changing Astro spark plugs. to get to all the plugs and wire routing clips. This increases labor time and cost if you're having a shop do the work.
Choosing the Right Aftermarket Spark Plug Wires
You don't need to go to a dealer for quality spark plug wires. The aftermarket offers a wide range of options, from budget-friendly replacements to high-performance upgrades. Here’s a breakdown of the brands available:
Tier 1: OEM Quality & Reliability
These brands are known for meeting or exceeding the original factory specifications. They are the go-to choice for a dependable, long-lasting repair that restores original performance.
- ACDelco: As the original equipment manufacturer for GM, ACDelco is a top choice. They offer both "Original Equipment" and "Professional" series wires. The OE parts are identical to what the van came with, while the Professional line is a high-quality aftermarket alternative. Many Astro owners recommend sticking with ACDelco for a guaranteed fit and performance. 🎬 See a comparison of the best spark plug wire brands.
- NGK: A highly respected name in ignition components, NGK wire sets are known for their quality construction and durability. They are an excellent alternative to ACDelco.
- Denso: Another top-tier OEM supplier, Denso provides excellent quality and is a reliable choice for a stock replacement.
Tier 2: Performance & Heavy-Duty
These brands are geared towards enthusiasts who may want a different look (e.g., colored wires) or are looking for enhanced durability, especially for modified or hard-working engines. They often feature thicker 8mm+ silicone jackets and lower resistance cores.
- MSD: Known for performance ignition systems, MSD wires have very low resistance, which some believe provides a stronger spark. However, for a stock Astro, the performance gain is likely negligible. Some users report issues with electronic interference or longevity compared to OEM wires.
- Taylor Cable & Granatelli: These brands offer high-performance wires, often in various colors, with thick silicone insulation to resist heat and abrasion. They are a solid choice if you're looking for something more robust than stock.
Tier 3: Standard & Economy
These brands offer a functional and affordable solution for getting your van back on the road. They are a good option for budget-conscious repairs.
- Standard Motor Products (SMP): A long-standing aftermarket brand that provides reliable, standard-replacement parts that fit and function correctly.
- Walker Products: A known aftermarket manufacturer offering budget-friendly ignition components.
Pro Tip: Replace More Than Just the Wires
It is highly recommended to replace your spark plugs, distributor cap, and rotor at the same time as the spark plug wires. These components all wear out together. Replacing them all at once ensures a complete ignition system tune-up and saves you from having to do a very similar, labor-intensive job 🎬 Watch how to replace the distributor cap and rotor properly. again in the near future.
Cost of New Spark Plug Wire Sets for 1985-1995 Chevrolet Astro
| Quality Tier | Brand Examples | Estimated Price Range |
|---|---|---|
| OEM-Quality Aftermarket | ACDelco, NGK, Denso | $45 - $75 |
| Performance Aftermarket | MSD, Taylor, Granatelli | $55 - $74 |
| Standard Aftermarket | Standard (SMP), Walker | $26 - $45 |
Frequently Asked Questions
Should I replace my spark plugs at the same time?
Yes, absolutely. The labor involved in accessing the spark plugs and wires on an Astro is significant. Since the spark plugs have a similar service life, replacing them at the same time as the wires is efficient and prevents you from having to do the same job twice.
What's the difference between 7mm and 8mm wires?
The measurement refers to the diameter of the wire's outer insulation. While factory wires are typically 7mm, many aftermarket and performance sets are 8mm or even larger. The thicker wire provides better insulation against heat and electrical arcing, making it a durable upgrade, but it may not fit in the original wire loom clips.
How do I avoid mixing up the wires during installation?
The best method is to replace one wire at a time. Remove one old wire from the distributor cap and the corresponding spark plug, match its length to a new wire from the set, and install the new wire. Repeat this process for all wires to ensure the correct firing order is maintained.
Do I need special tools to replace the spark plug wires?
A spark plug wire puller tool is highly recommended to avoid damaging the wires or leaving the boot stuck on the spark plug. You will also need a 5/8" spark plug socket with extensions and a swivel adapter to reach the spark plugs, especially on the driver's side. A set of pliers for removing old wire clips and a flashlight are also very helpful.
Helpful Videos
Technical Specifications
OEM Part Numbers: 12173579 9746KK
Engine: 4.3L V6. Wire Set includes 6 spark plug wires and 1 coil wire. Wire diameter is typically 7mm for OEM and 7mm or 8mm for aftermarket. Core material is typically spiral core or carbon core. Boot angles vary by cylinder, so a vehicle-specific set is required.
