Dodge D350 Headlight Switch Guide: 1987-1993 Models
Having trouble with your 1987-1993 D350's headlights? The switch is a common problem, and this guide explains why.
- The original factory design is flawed; it runs the full headlight current through the switch, causing it to overheat and fail.
- Symptoms include non-working headlights, flickering, a burning smell, or a melted electrical connector.
- Replacing the switch requires removing the entire dash bezel for access.
- To prevent future failures, it is highly recommended to install a headlight relay harness along with the new switch.
Is Your D350 Headlight Switch Failing?
The headlight switch on the first-generation Dodge D350 is a known weak point. Because these trucks were built without headlight relays, the full electrical current for the headlights passes through the switch. Over time, this heat can cause the switch and its plastic connector to melt, leading to a variety of lighting problems. This is especially common on dually models, which have extra clearance lights that add to the electrical load.
Symptoms of a Bad Headlight Switch
- Headlights Don't Turn On: You might find that your parking lights and dash lights work, but the headlights do not. This happens because separate circuits inside the switch fail.
- Flickering or Intermittent Lights: Your lights may flicker or cut out entirely. You might have to jiggle the switch to get them to work.
- Melted Connector or Burning Smell: A visual inspection of the switch's electrical connector may reveal melted plastic. A distinct burning plastic smell when the lights are on is a serious warning sign that the switch is overheating.
- Mushy or Indistinct Clicks: A new switch has two clear click positions. A failing switch can feel mushy or have multiple, unclear positions as you pull it out.
- Strange Electrical Gremlins: A shorting headlight switch can sometimes cause other weird issues, like a sudden low idle or other unrelated lights acting up. 🎬 Watch this overview of major electrical issues and switch failure.
A Note on Recalls
While there are no specific recalls for the 1987-1993 models, Chrysler did recall 1994-1997 Ram trucks for headlight switch failures. This shows that this has been a persistent issue for Dodge trucks of this era.
Choosing the Right Aftermarket Switch
Since finding a New Old Stock (NOS) OEM part is difficult and expensive, a quality aftermarket switch is the most practical solution. The original factory design is flawed anyway due to the lack of relays.
Standard Ignition: This is a widely available and reputable aftermarket brand. Their switches are designed to meet original specifications and use quality materials like copper alloy conductors. For a vehicle like the D350, a Standard brand switch is a reliable and cost-effective choice.
Pro Tip: Install a Headlight Relay Harness
To permanently fix the problem of burning out switches, you should install a headlight relay harness. This inexpensive kit reroutes the high-amperage power directly from the battery to the headlights, using the new headlight switch only as a low-power trigger. This takes the load off the switch, prevents it from melting, and often makes your headlights noticeably brighter. 🎬 See how to install a relay harness for brighter lights. Most switch failures are caused by not having relays, so installing a new switch without this upgrade may only be a temporary fix.
Replacement Cost
| Part Type | Price Range |
|---|---|
| New Aftermarket (Standard Ignition) | $42.98 |
| Shop Labor | $150 - $250 |
| New OEM | Discontinued / Not Available |
| Used OEM | $20 - $50 (Salvage Yard) |
Frequently Asked Questions (FAQ)
Can I replace the D350 headlight switch myself?
Yes, this is a manageable DIY job for someone with basic tools. The main challenge is that you must remove the entire plastic dash bezel to access the switch. This typically involves removing several screws, carefully prying the bezel off, and possibly lowering the steering column for extra clearance. Once you can see the switch, you press a small spring-loaded button on its body to release the pull knob and shaft.
🎬 Watch this step-by-step guide to replacing your headlight switch.Why do my new aftermarket switches keep failing?
If you have replaced the switch more than once, the root cause is almost certainly the high electrical load running through it. The factory wiring design is the problem, not necessarily the quality of the switch. You must install a headlight relay harness to take the load off the switch and prevent it from burning out again.
Are the headlights fused?
No, the headlights on these trucks are not protected by a fuse in the fuse box. Instead, they rely on an internal, self-resetting circuit breaker inside the headlight switch itself. If there's a short, the headlights may flash on and off as the breaker trips and resets.
Will a new switch make my headlights brighter?
A new switch might offer a slight improvement if the old one had badly corroded contacts. However, the best way to get significantly brighter headlights is by installing a headlight relay harness. This allows the headlights to get full voltage directly from the battery instead of routing it through the old wiring and switch.
Helpful Videos
Technical Specifications
OEM Part Numbers: 56021898AB
Pull-type switch with two positions and integrated instrument panel light rheostat.
