Jaguar XJS Windshield Washer Pump Guide (1987-1996)
Everything you need to know before replacing the windshield washer pump on your 1987-1996 Jaguar XJS.
- Washer pump failure is common, but always check for simple clogs in the lines or jets first.
- The pump is located in the passenger-side fender; replacing it requires removing the wheel and liner.
- Aftermarket pumps from brands like URO Parts and Trico are affordable but may offer less pressure than the original.
- While the part is cheap, professional replacement costs are higher due to labor time.
Is Your Windshield Washer Pump Failing?
When a washer pump fails on the XJS, the symptoms are usually obvious. You push the button to wash your windshield and nothing happens. If you don't hear the familiar humming or buzzing sound of the pump motor, the pump itself has likely failed. However, sometimes the pump runs, but you only get a weak dribble of fluid, or nothing at all.
Check for Clogs First
Before you replace the pump, it's wise to check for other common issues. The washer system in the XJS has several points where clogs can happen. The small filter screen on the pump's intake can get blocked with sludge from old washer fluid. The washer jets on the cowl 🎬 Watch: How to clear and fix blocked washer jets and the plastic tubing can also get clogged with debris. The plastic hoses and connectors become very brittle over time and can crack or break, causing leaks.
Choosing a New Aftermarket Washer Pump
For the 1987-1996 Jaguar XJS, you have a choice between budget-friendly aftermarket pumps and more expensive original equipment (OEM) parts. Since this is an older vehicle, finding a new OEM pump can be difficult and costly.
Aftermarket Brand Quality: Trico vs. URO Parts
Aftermarket pumps are a practical and affordable solution. Brands like Trico and URO Parts are widely available for your XJS.
- URO Parts: This brand offers a direct-fit replacement that promises quiet operation and durability. They are a common choice for European car repairs and generally provide a balance of affordability and acceptable quality.
- Trico: Known primarily for wiper blades, Trico also offers universal and direct-fit washer pumps. They are marketed as being easy to install and are typically among the most budget-friendly options.
An Honest Assessment: Some XJS owners have reported that certain aftermarket pumps provide weak pressure, leading to a disappointing spray on the windshield. 🎬 Watch: Simple steps to fix low pressure washer sprayers This can be due to the long distance the fluid must travel. While an aftermarket pump will restore function and is an easy DIY replacement, it may not have the same power as the original factory part. Given the low cost of the part, trying an aftermarket brand is a low-risk first step.
Windshield Washer Pump Replacement Cost
The cost of the pump itself is low, but professional installation can be expensive because of the labor involved to access it.
| Part Type | Estimated Cost |
|---|---|
| New Aftermarket Pump | $11 - $32 |
| Remanufactured OEM Pump | $100 - $120 |
| Shop Labor | $134 - $197 |
| Total Professional Replacement | $145 - $230 (Aftermarket) / $234 - $317 (OEM) |
Frequently Asked Questions
Where is the washer pump located on my XJS?
The windshield washer reservoir and pump are hidden. You will find them inside the front passenger-side fender area. To get to them, you must remove the front right wheel and the plastic inner fender liner.
Is replacing the washer pump a DIY job?
Yes, this is a feasible DIY project for someone comfortable with basic tools. It involves safely jacking up the car, removing the wheel and fender liner, and then swapping the pump. The pump itself just pushes into a rubber grommet on the reservoir. The most difficult part is accessing its location.
My pump runs but no fluid comes out. What's wrong?
If you can hear the pump motor, the problem is likely a blockage or a leak. Check for clogged washer jets, pinched or cracked hoses, or a blocked one-way valve in the system. Also, the filter on the pump itself, located inside the reservoir, 🎬 See how to clean out a dirty washer fluid reservoir can get clogged with slime.
Does my XJS have one or two washer pumps?
Your XJS has a dedicated pump for the windshield washers. If your car is equipped with the optional headlamp washers, it will have a second, separate pump for that system. This guide is for the windshield washer pump only.
Helpful Videos
Technical Specifications
OEM Part Numbers: JLM20122 DAC4571
12V electric pump, push-fit installation into washer reservoir.
