Jeep Wrangler YJ & TJ Back Up Light Switch Guide (1987-2000)
If your reverse lights are out, this guide will help you choose the right replacement back up light switch for your YJ or TJ Wrangler.
- Before replacing the switch, always check the fuse (often #7 in the glove box) and the light bulbs first.
- The switch is located on the driver's side of the manual transmission and is a straightforward DIY replacement.
- Aftermarket switch quality varies; some cheap parts are known to fail quickly. Consider a reputable brand like Standard Ignition for better longevity.
- Inspect the wiring connector for damage, as it can become brittle and fail along with the switch.
Is Your Jeep's Back Up Light Switch Failing?
A bad back up light switch on a 1987-2000 Jeep Wrangler is a common issue, but it's usually an easy fix. The most obvious sign of failure is when your reverse lights don't turn on at all when you shift into reverse. Another symptom is if the lights stay on even when you're not in reverse, which can drain your battery and confuse other drivers. Sometimes the lights might just flicker or work intermittently. Before you replace the switch, it's a good idea to check two other things first: the light bulbs themselves and the fuse. On many TJ models, the backup lamp fuse is #7 in the fuse box located in the glove compartment. If the bulbs and fuse are good, the switch is the most likely culprit.
🎬 Watch this video to diagnose why your lights aren't working.Choosing the Right Aftermarket Switch for Your YJ or TJ
🎬 Watch this quick fix for YJ reverse light issues.When it comes to aftermarket back up light switches for this generation of Wrangler, quality can vary. Some owners report that cheaper, unbranded switches can fail in as little as six months. Sticking with a known brand is usually a better investment. The switch you need depends on your specific transmission (e.g., AX5, AX15, BA 10/5). Always verify the part fits your exact year and transmission type.
Aftermarket Brand Quality Tiers
| Tier | Brands | General Assessment |
|---|---|---|
| Good | Crown Automotive, Omix-Ada | These are popular, widely available brands in the Jeep community. While some users have had success, others note that quality can sometimes be inconsistent compared to OEM. They are generally considered a step up from generic, no-name parts. |
| Better | Standard Ignition (SMP) | Standard Motor Products is a well-regarded manufacturer of automotive electrical components. Their switches are known for undergoing performance testing and often provide reliable, long-term service. |
| Other Options | True Tech, Vemo | These brands are also available but have less specific feedback in Jeep forums for this particular part. They likely fall into a similar category as other standard aftermarket replacement parts. |
A Note on Wiring
On these older Jeeps, it's not just the switch that fails. The wiring and connector pigtail leading to the switch can become brittle, frayed, or corroded from years of exposure under the vehicle. In some cases, you may need to replace the connector as well as the switch.
Frequently Asked Questions (FAQ)
Where is the back up light switch located on my 1987-2000 Wrangler?
For most manual transmission models (like the AX5, AX15), the switch is screwed into the driver's side of the transmission housing. You'll need to get under the Jeep to access it. It's often located near the transmission fill plug.
Can I replace the back up light switch myself?
Yes, this is a very DIY-friendly job for most home mechanics. It typically takes less than an hour. The main challenges are safely lifting and securing the vehicle to get underneath and working in a potentially tight space.
What tools do I need to replace the switch?
You will typically need a wrench or a deep well socket to remove the old switch. A common size is 7/8-inch or 22mm. You may also need a socket wrench with an extension to reach it comfortably. No transmission fluid should leak out when you remove the switch.
Why are my reverse lights stuck on?
If your reverse lights are always on, the switch has likely failed in the 'on' position, creating a permanently closed circuit. Replacing the switch should solve this problem.
Helpful Videos
![Jeep TJ Reverse Lights Not Working? [Easy Fix]](https://img.youtube.com/vi/fiEuFen117o/mqdefault.jpg)
Technical Specifications
OEM Part Numbers: 83500629 53004522 56007163
The switch is typically a 2-pin, screw-in type sensor. It is crucial to match the part to your specific transmission (e.g., AX4, AX5, AX15, BA 10/5) as there are different switches for different gearboxes used in this year range.
