Chrysler New Yorker Rack and Pinion Bellows Kit Guide (1988-1996)
Protect your steering rack from expensive damage by replacing torn or cracked bellows boots.
- The bellows kit is a cheap part that protects the very expensive steering rack.
- If you see power steering fluid leaking from the boot, the rack is already damaged and needs replacement.
- For this job, spending slightly more on a premium aftermarket brand like Beck Arnley or Delphi may be worth it for better material quality.
- A wheel alignment is highly recommended after replacement to prevent uneven tire wear.
Is Your Steering Rack at Risk?
The rack and pinion bellows, often called steering rack boots, are simple but critical parts on your 1988-1996 Chrysler New Yorker. Their only job is to protect the expensive steering rack assembly from contamination. When a boot tears, it creates an opening for dirt and moisture to get inside. This contamination grinds away at seals and metal parts, eventually destroying the entire steering rack. Replacing a bellows kit is cheap insurance against a four-figure steering rack replacement job.
A Note on Power Steering Fluid
The bellows boots do NOT hold power steering fluid. If you see fluid leaking from a torn boot, it means the internal seals of your steering rack have already failed. At this point, replacing only the boot is not enough; the entire steering rack assembly will need to be replaced or rebuilt.
Symptoms of a Failing Bellows Boot
Inspecting the bellows should be part of any oil change or under-car service. You are looking for simple visual clues.
- Visible Damage: The most obvious sign is a cracked, split, or torn boot. The rubber or plastic becomes brittle over time and can be damaged by road debris.
- Grease or Grime Buildup: If a boot has a small tear, the grease that lubricates the inner tie rod joint can begin to seep out and collect dirt.
- Loose Clamps: The boots are held in place by clamps. If these are loose or missing, the boot can't do its job, even if it's not torn.
Symptoms like stiff steering, clunking noises, or a loose feeling in the wheel are not signs of a bad boot, but rather signs of a damaged steering rack, which can be a result of a bad boot that was ignored.
Choosing the Right Aftermarket Bellows Kit
For a vehicle like the 1988-1996 Chrysler New Yorker, new OEM parts are likely discontinued or very hard to find. The aftermarket is your most practical source. For a simple part like a bellows boot, most aftermarket options are sufficient. The main difference is often the quality and durability of the rubber or plastic material.
Here’s a general breakdown of the brands available:
- Premium Aftermarket (Beck Arnley, Delphi): These brands often have a reputation for higher quality materials and better quality control. Beck Arnley, in particular, is known for sourcing parts from manufacturers that supply the original automakers. For a part that requires significant labor to access, spending a few extra dollars on a premium boot can be a wise investment.
- Standard Aftermarket (Mevotech, Dorman): These brands offer a balance of value and quality. They are a popular choice for many repairs. While Dorman has a mixed reputation in online forums, Mevotech is often considered a decent, budget-friendly option. For a daily driver, these brands are typically adequate.
Pro Tip: Most kits come with new clamps or zip ties. While the included zip ties often work, many mechanics prefer to use proper metal boot clamps for a more secure and long-lasting seal.
Typical Replacement Costs
The cost to replace a rack and pinion bellows kit is mostly labor. The part itself is inexpensive.
| Item | Estimated Cost |
|---|---|
| New Aftermarket Bellows Kit | $13 - $43 |
| Shop Labor | $100 - $200 |
| Total Estimated Cost | $113 - $243 |
| Optional: Wheel Alignment | $80 - $120 |
Costs are estimates and can vary based on your location and the specific repair shop. A wheel alignment is highly recommended after this repair.
Frequently Asked Questions
Do I need a wheel alignment after replacing the bellows?
It is highly recommended. The procedure requires removing the outer tie rod end from the inner tie rod. Even if you are careful to mark the position and count the threads, it's nearly impossible to get it back to the exact same spot. Driving with an incorrect alignment will cause premature tire wear.
Can I replace just one boot if only one is torn?
Yes, you can. However, if one boot has failed due to age, the other is likely not far behind. Since the cost of the part is low and the labor is similar for both sides, many owners choose to replace both at the same time to save on future labor costs and a second wheel alignment.
What kind of grease should I use?
Before installing the new boot, it's a good idea to pack some lithium grease around the inner tie rod joint to ensure it stays lubricated. Do not fill the entire boot with grease, as this is not necessary.
Are there any recalls for the steering bellows on my New Yorker?
No. Searches of the National Highway Traffic Safety Administration (NHTSA) database show no recalls or specific investigations for the rack and pinion bellows on the 1988-1996 Chrysler New Yorker. Any steering-related recalls for Chrysler vehicles from that era or newer models pertain to different components.
Technical Specifications
Kit typically includes one or two bellows boots and retaining clamps or zip ties. Material is usually rubber or thermoplastic.
