Engine Oil Pressure Switch Guide for 1990-1995 Dodge Caravan
Seeing a flickering oil light or getting strange gauge readings? Your oil pressure switch might be the culprit.
- A flickering oil light at idle is the most common symptom of a bad switch on these Caravans.
- Always check the oil level first before replacing any parts.
- The switch is an easy, 30-minute DIY replacement located near the oil filter.
- Reputable aftermarket brands like Standard Ignition and Rostra are reliable choices for this repair.
Is Your Oil Light Flickering? Understanding the Problem
A common issue on the 1990-1995 Dodge Caravan is a flickering oil light, especially when the engine is warm and idling at a stop. Another symptom is an oil pressure gauge that reads incorrectly, drops to zero intermittently, or stays pegged at maximum. While this can be alarming, it doesn't always mean your engine is in danger. Often, the problem is simply a faulty oil pressure switch. These switches can fail over time, either by sending false signals or by leaking oil. A visible oil leak from the switch itself is a clear sign it needs replacement.
🎬 Learn more about the common symptoms of a bad oil pressure sensor.Don't Ignore the Warning
While the switch is often the problem, an oil pressure warning can also signal genuine low oil pressure, which is a critical engine emergency. Always check your oil level first. If the level is correct, it's safer to assume the switch is bad, but you should address the issue immediately to be sure.
Choosing the Right Aftermarket Switch
For a vehicle from this era, new OEM (Mopar) parts can be difficult to find. Aftermarket parts are a reliable and cost-effective solution. The two main brands available are Standard Ignition (also known as Standard Motor Products or SMP) and Rostra Powertrain.
- Standard Ignition (SMP): A very well-known and generally respected aftermarket brand. They have been making quality replacement parts for decades. For a simple part like an oil pressure switch on a Caravan, their products are considered a dependable choice.
- Rostra Powertrain: Rostra specializes in powertrain electronics and is known for producing OE and aftermarket components, including sensors and switches. They are a certified manufacturer with a reputation for quality parts.
Pro Tip: For this specific part and vehicle age, there is little practical difference in quality between these two reputable aftermarket brands and an original OEM part. Both Standard and Rostra offer a reliable fix. The most important factor is ensuring the part number is correct for your Caravan's specific engine (e.g., 3.0L, 3.3L).
Cost of a New Engine Oil Pressure Switch (1990-1995 Dodge Caravan)
| Part Type | Estimated Cost |
|---|---|
| New Aftermarket | $13.07 - $48.32 |
| Shop Labor | $50 - $100 |
Cost estimates are for the part only and do not include taxes or shipping. Labor costs are estimates and can vary by location.
Frequently Asked Questions
Where is the oil pressure switch located on my Caravan?
The location varies slightly by engine. On many V6 models like the 3.0L and 3.3L, the oil pressure switch is located on the front of the engine block, right next to or just above the oil filter. This makes it accessible from underneath the vehicle.
Can I replace the oil pressure switch myself?
Yes, this is a very DIY-friendly repair. It typically involves unplugging the electrical connector, unscrewing the old switch with a special socket or wrench, and then installing the new one. You do not need to drain the engine oil, though a small amount may spill out when you remove the old switch. The entire job can usually be done in under 30 minutes.
🎬 See a step-by-step video on replacing the sensor on a 3.3L engine.Do I need a special tool?
Yes, you will likely need a special deep socket designed for oil pressure sending units. These are readily available at auto parts stores. Using a standard wrench can be difficult due to the tight space and the shape of the sensor.
Is a flickering oil light always a bad switch?
Not always, but it is the most common cause. Other potential causes include a low oil level, using the wrong type of oil, a clogged oil filter, or, in the worst-case scenario, a failing oil pump. Because a new 🎬 Watch this guide on causes for an oil light blinking at idle. switch is inexpensive and easy to install, it's often the first part to replace when troubleshooting.
Are there any recalls for this issue?
No, searches of the NHTSA database found no recalls specifically for the engine oil pressure switch on 1990-1995 Dodge Caravans. Recalls found were for transaxle oil pumps on much newer models (2015-2016).
Helpful Videos
Technical Specifications
OEM Part Numbers: 5233397 4687712 4707015 4707015AB
Typically a single-pin connector for a warning light or a multi-pin connector for a gauge. Thread size and pressure rating vary by engine.
We Have This Part in Stock
The information in this article is provided for general reference and educational purposes only. Vehicle specifications, procedures, and part compatibility can vary by production date, trim level, and region. Always consult your vehicle's factory service manual and verify part numbers before purchasing or performing repairs. Safety-critical components such as airbags, seat belts, and braking systems should be installed by a qualified professional.
